Specifications
| Items | Specifications | |
|---|---|---|
| Rated voltage | DC 12V | |
| Operating temperature range | 30°C ~ +80°C (-22 ~ +176°F) | |
| Rated load | Dimmer & passing switch | High : 1A (Relay load) Low : 1A (Relay load) Passing : 1A (Relay load) |
| Lighting switch | Lighting : 1A (Relay load) | |
| Turn signal & lane change switch | 6.6±0.5A (Lamp load) | |
| Front fog lamp switch | 1A (Relay load) | |
| Wiper & mist switch | Low, High : 4A (Motor load) Intermittent : 0.22±0.05A (Relay load) Lock : Max. 23A (Motor load) Mist: 4A (Motor load) | |
| Washer switch | 4A (Motor load) | |
| Variable intermittent volume switch | Max. 25mA | |
MULTIFUNCTION SWITCH SPECIFICATIONS
Scheme 1
Scheme 2
Scheme 3
- Disconnect the negative (-) battery terminal.
- Remove the steering column upper and lower shrouds (A) after removing 3 screws.
- Remove the light switch (A) by pushing the lock pin (B) after disconnecting the connector.
- Remove the wiper switch (A) by pushing the lock pin (B) after disconnecting the connector.
