Multi Function Switch: Specifications Kia Optima II

Steering Column Switches 4 illustrations

SPECIFICATIONS

ItemsSpecifications
Rated voltageDC 12V
Operating temperature range30°C-+80°C (-22-+176°F)
Rated loadDimmer & passing switchHigh: 1A (Relay load) Low: 1A (Relay load) Passing: 1A (Relay load)
Lighting switchLighting: 1A (Relay load)
Turn signal & lane change switch6.6+/-0.5A (Lamp load)
Front fog lamp switch1A (Relay load)
Wiper & mist switchLow, High: 4A (Motor load) Intermittent: 0.22+/-0.05A (Relay load) Lock: Max. 23A (Motor load) Mist: 4A (Motor load)
Washer switch4A (Motor load)
Variable intermittent volume switchMax. 25mA

VOLTAGE SPECIFICATIONS CHART

Scheme 1

Scheme 1: COMPONENTS
Scheme 1: COMPONENTS

Scheme 2

Scheme 2: REPLACEMENT
Scheme 2: REPLACEMENT

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4
  1. Disconnect the negative (-) battery terminal.
  2. Remove the steering column upper and lower shrouds (A) after removing 3 screws.
  3. Remove the light switch (A) by pushing the lock pin (B) after disconnecting the connector.
  4. Remove the wiper switch (A) by pushing the lock pin (B) after disconnecting the connector.
  5. Installation is the reverse of removal.
