Windshield Wiper/washer: Overview Kia Optima I рестайлинг

Scheme 1

Scheme 2

SPEED OPERATION CHECK

1. Remove the connector from the wiper motor.
2. Attach the positive (+) lead from the battery to terminal 4 and the negative (-) lead to terminal 1.
3. Check that the motor operates at low speed.
4. Connect the positive (+) lead from the battery to terminal 4 and the negative (-) lead to terminal 2.
5. Check that the motor operates at high speed.

Scheme 3

AUTOMATIC STOP OPERATION CHECK

1. Operate the motor at low speed.
2. Stop the motor operation anywhere except at the off position by disconnecting terminal 1.
3. Connect terminals 1 and 5
4. Connect the positive (+) lead from the battery to terminal 4 and the negative (-) lead to terminal 3.
5. Check that the motor stops running at the off position.

Scheme 4

Scheme 5

Scheme 6

1. Install three wiper motor mounting bolts on wiper motor and link assembly.
2. Install wiper motor and link assembly. Attach wiper motor ball joint to wiper link assembly. Install and tighten two mounting bolts. Connect wiper motor harness connector.
3. Place cowl vent in position and install nuts and fasteners.
4. Connect negative battery cable.

Scheme 7

1. Before removal check that wiper has stopped at its off position.
2. Remove nut cover and then wiper arm nut.
3. Check that arms are marked "Dr" (Driver Side) and "As" (Passenger Side). If not, mark them before removal.
4. Remove wiper arms.

Scheme 8

Scheme 9

1. Remove wiper arms and blades. Refer to "Windshield Wiper/Washer System" in this section.
2. Remove nuts and fasteners from cowl vent.
3. Remove wiper motor and wiper link assembly. Disconnect wiper motor harness connector. Remove two mounting bolts from assembly.
