MASTER POWER WINDOW SWITCH
Turn ignition switch to OFF position. Disconnect master power window switch harness connector. Using an ohmmeter, check for continuity between specified switch terminals while operating switch. See MASTER POWER WINDOW SWITCH CONTINUITY table. (Scheme 3) If continuity is not as specified, replace master power window switch. Retest system.
| Application & Switch Position | Continuity Between Terminals No. | |
|---|---|---|
| Left Front | ||
| UP | 1 & 11; 2 & 10 | |
| OFF | 1, 2 & 10 | |
| DOWN | 1 & 10; 2 & 11 | |
| Right Front | ||
| UP | 3 & 11; 5 & 10 | |
| OFF | 3, 5 & 10 | |
| DOWN | 3 & 10; 5 & 11 | |
| Right Rear | ||
| UP | 11 & 13; 10 & 14 | |
| OFF | 10, 13 & 14 | |
| DOWN | 10 & 13; 11 & 14 | |
| Left Rear | ||
| UP | 9 & 11; 10 & 12 | |
| OFF | 9, 10 & 12 | |
| DOWN | 9 & 10; 11 & 12 | |
MASTER POWER WINDOW SWITCH CONTINUITY
Scheme 3
PASSENGER POWER WINDOW SWITCHES
Turn ignition off. Disconnect appropriate passenger power window switch harness connector. Using an ohmmeter, check for continuity between specified switch terminals while operating switch. See PASSENGER POWER WINDOW SWITCH CONTINUITY. (Scheme 4) Replace passenger power window switch if continuity is not as specified.
| Switch Position | Continuity Between Terminals No. |
|---|---|
| UP | 1 & 3; 4 & 8 |
| OFF | 1 & 3; 6 & 8 |
| DOWN | 3 & 4; 6 & 8 |
PASSENGER POWER WINDOW SWITCH CONTINUITY
