Rated Load
| System Name | Capacity | Availability in Power |
|---|---|---|
| Horn relay | DC 12V 200mA (Inductive load) | B+ |
| Hazard relay | DC 12V 200mA (Inductive load) | B+ |
| Key hole illumination lamp | DC 12V 1.4W (LAMP) | B+ |
| Defogger relay | DC 12V 200mA (Inductive load) | B+ |
| Deicer relay | DC 12V 200mA (Inductive load) | B+ |
| Central unlock relay | DC 12V 200mA (Inductive load) | B+ |
| Central lock relay | DC 12V 200mA (Inductive load) | B+ |
| Drive door unlock relay | DC 12V 200mA (Inductive load) | B+ |
| Power window enable relay | DC 12V 200mA (Inductive load) | B+ |
| Front fog relay | DC 12V 200mA (Inductive load) | B+ |
| Rear fog relay | DC 12V 200mA (Inductive load) | B+ |
| Tail lamp relay | DC 12V 200mA (Inductive load) | B+ |
| Head lamp relay | DC 12V 200mA (Inductive load) | IG2 |
| Front wiper relay | DC 12V 200mA (Inductive load) | IG2 |
| Drive seat belt indicator lamp | DC 12V 1.2W (LED) | IG1 |
| Trunk unlock relay | DC 12V 200mA (Inductive load) | B+ |
| Key solenoid | DC 12V 1A (Inductive load) | B+ |
| Atm solenoid | DC 12V 200mA (Inductive load) | B+ |
RATED LOAD
Scheme 41
Scheme 42
Terminal Voltage
| Function | Pin Name | State | Voltage Level | |
|---|---|---|---|---|
| Low Level | High Level | |||
| Analog Input | B+ | 8V ~ 16V | ||
| Auto Light Sig | 0V ~ 5V | |||
| IntT | 0V ~ 5V | |||
| IGN1 | 8V ~ 16V | 2V Below | 6V Over | |
| AltL | 8V ~ 16V | 5V Below | 10V Over | |
| ACC | 8V ~ 16V | 2V Below | 6V Over | |
| IGN2 | 8V ~ 16V | 2V Below | 6V Over | |
| Logic Input | Washer Switch | OPEN/ON | 2.5V Below | 8V Over |
| Wiper Int Switch | OPEN/ON | 2.5V Below | 8V Over | |
| Mist Switch | OPEN/ON | 2.5V Below | 8V Over | |
| Key in Switch | OPEN/ON | 2.5V Below | 6V Over | |
| Trunk Switch | OPEN/ON | 2.5V Below | 6V Over | |
| Driver Door Unlock Switch | OPEN/ON | 2.5V Below | 6V Over | |
| Assist Door Unlock Switch | OPEN/ON | 2.5V Below | 6V Over | |
| RR Door Switch | OPEN/ON | 2.5V Below | 6V Over | |
| RL Door Switch | OPEN/ON | 2.5V Below | 6V Over | |
| Driver Door Switch | OPEN/ON | 2.5V Below | 6V Over | |
| Assist Door Switch | OPEN/ON | 2.5V Below | 6V Over | |
| Driver Door Key Lock Switch | OPEN/ON | 2.5V Below | 6V Over | |
| Driver Door Key Unlock Switch | OPEN/ON | 2.5V Below | 6V Over | |
| Assist Door Key Lock Switch | OPEN/ON | 2.5V Below | 6V Over | |
| Assist Door Key Unlock Switch | OPEN/ON | 2.5V Below | 6V Over | |
| Pwdw Door Lock Switch | OPEN/ON | 2.5V Below | 6V Over | |
| Pwdw Door Unlock Switch | OPEN/ON | 2.5V Below | 6V Over | |
| Defogger Switch | OPEN/ON | 2.5V Below | 6V Over | |
| Deicer Switch | OPEN/ON | 2.5V Below | 6V Over | |
| Driver Seat Belt Switch | OPEN/ON | 2.5V Below | 6V Over | |
| Auto Light Switch | OPEN/ON | 2.5V Below | 6V Over | |
| Head Lamp Switch | OPEN/ON | 2.5V Below | 6V Over | |
| Head Lamp High Switch | OPEN/ON | 2.5V Below | 6V Over | |
| Tail Switch | OPEN/ON | 2.5V Below | 6V Over | |
| Rear Fog Switch | OPEN/ON | 2.5V Below | 6V Over | |
| Front Fog Switch | OPEN/ON | 2.5V Below | 6V Over | |
| Key Inter Lock Switch | OPEN/ON | 2.5V Below | 6V Over | |
| Push Start Switch | OPEN/ON | 2.5V Below | 6V Over | |
| Inhibit D | OPEN/ON | 2.5V Below | 8V Over | |
| Inhibit P | OPEN/ON | 2.5V Below | 8V Over | |
| Inhibit N | OPEN/ON | 2.5V Below | 8V Over | |
| Inhibit R | OPEN/ON | 2.5V Below | 8V Over | |
| Speed sensor | OPEN/ON | 2.5V Below | 6V Over | |
| Frequency | CAN H | OPEN/ON | ||
| CAN L | OPEN/ON | |||
| Communication | Crash Input | OPEN/ON | ||
| CODE SAVE | OPEN/ON | |||
| K LINE | OPEN/ON | |||
BCM CONNECTOR TERMINAL VOLTAGE REFERENCE CHART
