Interior lights
# Instrument illumination circuit
# Instrument illumination circuit (1 of 3)
Components on the diagram
# Instrument illumination circuit (2 of 3)
Components on the diagram
# Instrument illumination circuit (3 of 3)
Components on the diagram
Components on these wiring diagrams 48
Click a component to highlight it on every diagram it appears on.
