Wiring diagram: Air conditioning — Automatic a/c circuit Kia Carnival III
All systems
- Air conditioning 2
- Anti-lock brakes 2
- Anti-theft 3
- Body control modules 2
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers 2
- Electronic power steering
- Engine performance 3.3l
- Exterior lights 2
- Ground distribution
- Headlights 4
- Horn
- Instrument cluster 3
- Interior lights 2
- Memory systems 2
- Navigation 5
- Power distribution
- Power door locks
- Power mirrors 3
- Power seats 8
- Power top/sunroof
- Power windows 4
- Radio 5
- Shift interlock
- Starting/charging 3
- Supplemental restraints
- Transmission
- Trunk, tailgate, fuel door 3
- Warning systems
- Wiper/washer 2
Automatic a/c circuit (1 of 5) — Air conditioning Kia Carnival III
Components on the diagram
Automatic a/c circuit (2 of 5) — Air conditioning Kia Carnival III
Components on the diagram
Automatic a/c circuit (3 of 5) — Air conditioning Kia Carnival III
Components on the diagram
Automatic a/c circuit (4 of 5) — Air conditioning Kia Carnival III
Components on the diagram
Automatic a/c circuit (5 of 5) — Air conditioning Kia Carnival III
Components on the diagram
Components on these wiring diagrams
Click a component to highlight it on every diagram it appears on.
