Inspection
- Check the trip computer's outside ambient temperature input resistance.
| ITEM | Connector Pin | Input signal | Reference |
|---|---|---|---|
| Compass | Embedded | ||
| Range | |||
| Elapsed time | 1 | PULSE | |
| Average Fuel Consumption | 3, 8 | ECU | |
| Outside Ambient Temperature | 10 | Ambient temperature | Check the input resistance |
TRIP COMPUTER TABLE
* Outside ambient temperature & display logic
| Temperature | Tolerance | Resistance | ||
|---|---|---|---|---|
| 40°C | 40°F | ± 4°C | ± 7°F | 68.86 kohms |
| 20°C | 4°F | ± 2°C | ± 4°F | 21.66 kohms |
| 0°C | +32°F | ± 2°C | ± 4°F | 7.83 kohms |
| +20°C | +68°F | ± 2°C | ± 4°F | 3.11 kohms |
| +40°C | +104°F | ± 4°C | ± 7°F | 1.34 kohms |
| +60°C | +140°F | ± 4°C | ± 7°F | 0.63 kohms |
AMBIENT TEMPERATURE INPUT RESISTANCE TABLE
* AFC : Average Fuel Consumption
OAT : Outside Ambient Temperature
ECU : Engine Control Unit
Scheme 20
Scheme 21
Scheme 22
- Disconnect the negative (-) battery terminal.
- Remove the lens and open the sunglass case cover from the overhead console then remove the 2 screws holding the overhead console. And disconnect the connector then remove the overhead console lamp assembly from the headliner.
- Remove the trip computer (A) mounting screws (3 EA), and then disconnect from the overhead console.
- Installation is the reverse of removal.
