Lighting System: Specifications Kia Carnival III

Exterior Lights 4 illustrations

Specification

ItemsBulb Watt (W)
Head lamp (High)55
Head lamp (Low)55
Front turn signal lamp28
Front position lamp8
Front side marker lamp5
Front fog lamp35
Rear stop/tail lamp21/5
Back up lamp16
Rear turn signal lamp27
License plate lamp5
Room lamp10
Overhead console lamp10 x 2
High mounted stop lampLED
Glove box lamp5
Luggage room lamp5
Door courtesy lamp5

LIGHTING SYSTEM SPECIFICATION

Scheme 1

Scheme 1: Component Location
Scheme 1: Component Location

Scheme 2

Scheme 2: Replacement
Scheme 2: Replacement

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4
  1. Disconnect the negative (-) battery terminal.
  2. Loose the mounting bolts (2 EA).
  3. Remove the head lamp assembly after disconnecting the lamp connectors. NOTE: Take care that holding clip (A) is not to be damaged.
  4. Remove the head lamp rear cover and pulling up head lamp bulb fixing wire clip.
  5. Replace the bulb.
  6. Installation is the reverse of removal.
