Air conditioning — Manual a/c circuit Jeep Wrangler II

Components on these wiring diagrams 29

Click a component to highlight it on every diagram it appears on.

• 16 4 Ect Sensor Sens Ground
• 19 31 A/C Pressure Signal
• 2.4L
• 22 23 A/C Request Signal A/C Select Input
• 4.0L
• A/C Compressor Clutch Relay
• A/C Heater Control
• A/C High Pressure Switch
• A/C Low Pressure Switch
• A/C Pressure
• Blend Door Actuator
• Blower Motor
• Blower Motor Relay
• Blower Motor Resistor Block
• Engine Coolant Temperature Sensor
• Fuse 1 Fuse 21
• Fuse 11
• Fuse 7
• Fuse 8
• High Vent Norm Heat Max Mix Off Defrost
• Low Speed Radiator Fan Relay
• Powertrain Control Module
• Radiator Fan Motor
• Radiator Fan Motor Circuit Breaker
• Radiator Fan Relay
• Sensor — Ground
• Transducer
• Vacuum/ Electric Mode Switch
• Vent Vent Heat Norm Norm Heat Max Max Mix Mix Off Off Defrost Defrost
