VEHICLE CHECKS
Before making wheel alignment adjustments, check and adjust the following items
- Tire pressure must be inflated to manufacturer's specifications. Tires should be equal in size and type. Runout must not be excessive. Tires and wheels should be in balance.
- Wheel bearings must be properly adjusted. Steering linkage and suspension must not have excessive wear and/or looseness.
- Steering gear box must not have excessive play. Check and adjust to manufacturer's specifications.
- Vehicle must be level with floor. Bounce front and rear of vehicle several times to allow vehicle to settle to normal ride height.
- Ensure steering wheel is centered and front wheels are in straight-ahead position. Adjust toe-in if necessary. Ensure wheel lug nuts are tightened to specifications. See «TORQUE SPECIFICATIONS»(/jeep/wrangler/i-1986-1995/remont/wheel-alignment/#wheel-alignment-specifications-procedures) .
CAMBER MEASUREMENT
Note. Camber is not adjustable. Check camber to determine if any components are bent or damaged. If camber angle is not to specification, components causing the problem must be replaced. See ALIGNMENT SPECIFICATIONS .
CASTER ADJUSTMENT
Check caster angle. See ALIGNMENT SPECIFICATIONS. If caster is not to specifications, adjustment can be made by adding or removing shims at rear of lower control arms on Cherokee, Comanche and Wagoneer models and between front axle pads and spring brackets on Grand Wagoneer and Wrangler models. (Scheme 1)and (Scheme 2).
Scheme 1
Scheme 2
Note. On 4WD vehicles, shim adjustment will change caster angle and front drive shaft angle. If both angles cannot be adjusted to specifications, drive shaft angle has priority and should be adjusted for its specified angle. See the appropriate article in the DRIVE AXLES section.
Cherokee, Comanche & Wagoneer
- Set front wheels straight-ahead. Measure toe and compare to specifications. See «ALIGNMENT SPECIFICATIONS»(/jeep/wrangler/i-1986-1995/remont/wheel-alignment/#wheel-alignment-specifications-procedures).
- Center steering wheel by counting the turns required to hit left and right steering stops. Center steering wheel mid-way between stops. Loosen drag link adjustment sleeve clamp bolts. (Scheme 3) Rotate sleeve with appropriate tool to adjust right wheel toe to specification. Position clamp bolts so threaded bolt ends face upward and to rear of vehicle. Tighten drag link sleeve bolts to specification. See «TORQUE SPECIFICATIONS»(/jeep/wrangler/i-1986-1995/remont/wheel-alignment/#wheel-alignment-specifications-procedures).
- Loosen clamp bolts at each end of tie rod. Rotate tie rod with appropriate tool to adjust left wheel to toe specification. See «ALIGNMENT SPECIFICATIONS»(/jeep/wrangler/i-1986-1995/remont/wheel-alignment/#wheel-alignment-specifications-procedures). When adjustment is complete, position sleeve as described earlier and tighten to specifications. See «TORQUE SPECIFICATIONS»(/jeep/wrangler/i-1986-1995/remont/wheel-alignment/#wheel-alignment-specifications-procedures).
Scheme 3
Grand Wagoneer & Wrangler
- Center front wheels straight-ahead and lock steering wheel in centered position. Measure toe and compare to specifications. See «ALIGNMENT SPECIFICATIONS»(/jeep/wrangler/i-1986-1995/remont/wheel-alignment/#wheel-alignment-specifications-procedures).
- Loosen tie rod adjustment sleeve clamp bolts. (Scheme 4)and (Scheme 5). Rotate sleeve with appropriate tool to adjust toe to specification. See «ALIGNMENT SPECIFICATIONS»(/jeep/wrangler/i-1986-1995/remont/wheel-alignment/#wheel-alignment-specifications-procedures). After adjustment, position clamp bolts so threaded ends face rearward and are angled upward. Tighten sleeve clamp to specification. See «TORQUE SPECIFICATIONS»(/jeep/wrangler/i-1986-1995/remont/wheel-alignment/#wheel-alignment-specifications-procedures).
- If necessary, steering wheel can be centered by adjusting the drag link adjustment sleeve. When adjustment is complete, position sleeve as described earlier and tighten to specifications. See «TORQUE SPECIFICATIONS»(/jeep/wrangler/i-1986-1995/remont/wheel-alignment/#wheel-alignment-specifications-procedures).
Scheme 4
Scheme 5
Grand Wagoneer Vehicles
Check outside wheel turning angle and compare to specifications. See ALIGNMENT SPECIFICATIONS . To adjust, loosen lock nuts on turning angle adjustment screws. Using a turntable to measure angle, adjust screws to obtain correct outside turning angle for each wheel. Tighten adjustment screw lock nuts.
| Application | Fraction | Decimal |
|---|---|---|
| Camber (Degrees) | 0 ± 1/2 | (0.0 ± 0.5) |
| Caster (Degrees) | 6 ± 1 | (6.0 ± 1.0) |
| Toe-in (Inches) | 0 ± 1/32 | (0.0 ± .031) |
| Toe-out (Inches) | 0 ± 1/32 | (0.0 ± .031) |
| Outside Wheel Turn Angle Degrees (1) | 32-33 | (32.0-33.0) |
| (1) Steering stops are not adjustable. | ||
| (1) | Steering stops are not adjustable. |
WHEEL ALIGNMENT SPECIFICATIONS (CHEROKEE, COMANCHE & WAGONEER)
| Application | Fraction | Decimal | |
|---|---|---|---|
| Camber (Degrees) | 0-1/2 | (0.0-0.5) | |
| Caster (Degrees) | 4-5 | (4.0-5.0) | |
| Toe-in | |||
| Inches | 0-5/32 | (0.0-.16) | |
| Degrees | 0-11/32 | (0.0-.34) | |
| Outside Wheel Turn Angle Degrees (1) | 36-37 | (36.0-37.0) | |
| (1) Steering stops are not adjustable. | |||
| (1) | Steering stops are not adjustable. |
WHEEL ALIGNMENT SPECIFICATIONS (GRAND WAGONEER)
| Application | Fraction | Decimal | |
|---|---|---|---|
| Camber (Degrees) | 0 ± 1/2 | (0.0 ± 0.5) | |
| Caster (Degrees) | |||
| Manual Transmission | 8 ± 1/2 | (8.0 ± 0.5) | |
| Automatic Transmission | 6 1/2 ± 1/2 | (6.5 ± 0.5) | |
| Toe-in (Inches) | 0-1/2 | (0.0-.031) | |
| Outside Wheel Turn Angle Degrees (1) | 32-33 | (32.0-33.0) | |
| (1) Steering stops are not adjustable. | |||
| (1) | Steering stops are not adjustable. |
WHEEL ALIGNMENT SPECIFICATIONS (WRANGLER)
TORQUE SPECIFICATIONS (CHEROKEE, COMANCHE & WAGONEER)
| Application | Ft. Lbs. (N.m) |
|---|---|
| Drag Link Sleeve Clamp Bolts | 14 (19) |
| Lower Control Arm Nuts | 133 (180) |
| Tie Rod Sleeve Clamp Bolts | 36 (49) |
| Wheel Lug Nut | 102 (75) |
TORQUE SPECIFICATIONS (CHEROKEE, COMANCHE & WAGONEER)
TORQUE SPECIFICATIONS (GRAND WAGONEER)
| Application | Ft. Lbs. (N.m) |
|---|---|
| Drag Link Sleeve Clamp Bolts | 30 (41) |
| Spring Bracket "U" Bolt Nut | 100 (136) |
| Tie Rod Sleeve Clamp Bolts | 30 (41) |
| Wheel Lug Nut | 102 (75) |
TORQUE SPECIFICATIONS (GRAND WAGONEER)
TORQUE SPECIFICATIONS (WRANGLER)
| Application | Ft. Lbs. (N.m) |
|---|---|
| Drag Link Sleeve Clamp Bolts | 36 (49) |
| Spring Bracket "U" Bolt Nut | 90 (122) |
| Tie Rod Sleeve Clamp Bolts | 14 (19) |
| Wheel Lug Nut | 102 (75) |
TORQUE SPECIFICATIONS (WRANGLER)
