| A/C Compressor Mounting Bolts | 20 (27) |
| Camshaft Non - Oiled Sprocket Bolt | 90 (122) |
| Connecting Rod Cap Bolts |
| Step 1 | 20 (27) |
| Step 2 | Tighten 90 Degrees |
| Counterbalance Shaft Retaining Bolt | 21 (28) |
| Crankshaft Damper Bolt | 129 (175) |
| Crankshaft Main Bearing Cap/Bedplate Bolt/Stud (1) |
| Step 1 (Bolts 1D, 1G, 1F) | Hand Tighten Until Bedplate Seats |
| Step 2 (Bolts 1A-1J) | 40 (54) |
| Step 3 (Bolts 1-8) | 6 (7) |
| Step 4 (Bolts 1-8) | Additional 90 Degrees |
| Step 5 (Bolts A-E) | 20 (27) |
| Cylinder Head Bolt (2) |
| Step 1 (Bolts 1-8) | 20 (27) |
| Repeat Step 1 Without Loosening Bolts | 20 (27) |
| Step 2 (Bolts 9-12) | 10 (14) |
| Step 3 |
| Bolts (1-8) | Tighten 90 Degrees |
| Repeat Bolts (1-8) | Another 90 Degrees |
| Bolts (9-12) | 19 (26) |
| Engine Mount Bolts (Front) | 45 (61) |
| Engine Mount Bolts (Rear) |
| Support Bracket to Transmission | 34 (46) |
| Cushion To Support Bracket | 55 (75) |
| Crossmember To Sill Bolts | 30 (41) |
| Exhaust Manifold Bolts | 18 (25) |
| Exhaust Manifold Heat Shield Bolts | N/A |
| Flexplate Bolts | 70 (95) |
| Generator Mounting Bolt |
| M8 | 21 (28) |
| M10 | 40 (54) |
| Hydraulic Tensioner Bolts | 21 (28) |
| Oil Drain Plug | 25 (34) |
| Oil Pan Bolts (4) | 11 (15) |
| Oil Pickup Tube Bolt & Nut | 21 (28) |
| Oil Pump/Primary Timing Chain Tensioner Bolt | 21 (28) |
| Power Steering Pump |
| Bracket To Pump Bolt | 21 (28) |
| Bracket To Engine Bolt | 35 (47) |
| Pump Flow Control Valve Fitting | 55 (75) |
| Pressure Line Fitting | 21 (28) |
| Spark Plug | 20 (27) |
| Starter Bolts | 40 (54) |
| Structural Cover Bolts (5) |
| Step 1 | Loosely Install 3 Bolts |
| Step 2 | 40 (54) |
| Timing Chain Cover Bolts | 43 (58) |
| Timing Chain Idler Sprocket Bolt | 25 (34) |
| Timing Chain Guide Bolts | 21 (28) |
| Timing Chain Primary Tensioner Bolts | 21 (28) |
| Timing Chain Tensioner Arm Bolt | 21 (28) |
| Vibration Damper Bolt | 129 (175) |
| Water Pump Bolts | 43 (58) |
| INCH Lbs. (N.m) |
| Camshaft Bearing Cap Bolt (6) | 97 (11) |
| Cylinder Head Cover Bolts | 106 (12) |
| Exhaust Manifold Heat Shield Nuts |
| Step 1 | 71 (8) |
| Step 2 | Loosen 45 Degrees |
| Intake Manifold Bolt/Stud (7) | 106 (12) |
| Oil Fill Tube Bolts | 106 (12) |
| Oil Pump Cover Bolts | 106 (12) |
| Thermostat Housing Bolts | 106 (12) |
| Throttle Body Bolt | 106 (12) |
| Valve Cover Bolt | 106 (12) |
| (1) Tighten bolts/studs in sequence. see scheme 175 (2) Tighten bolts in sequence. see scheme 176 (3) Tighten bolts in sequence. see scheme 177 (4) Tighten bolts in sequence. see scheme 178 (5) Tighten bolts in sequence. see scheme 179 (6) Tighten bolts in sequence. see scheme 180 (7) Manufacturer does not supply tightening sequence. |
