GENERAL SPECIFICATIONS
| DESCRIPTION | SPECIFICATION | |
|---|---|---|
| Type | In-Line OHV, DOHC | |
| Number of Cylinders | 4 | |
| Firing Order | 1-3-4-2 | |
| Compression Ratio | 9.5:1 | |
| Max. Variation Between Cylinders | 25% | |
| Metric | Standard | |
| Displacement | 2.4 Liters | 148 cu. in. |
| Bore | 87.5 mm | 3.445 in. |
| Stroke | 101.0 mm | 3.976 in. |
| Compression Pressure | 1172-1551 kPa | 170-225 psi |
GENERAL SPECIFICATIONS
SPECIFICATIONS - TORQUE
| Description | N.m | Ft. Lbs. | In. Lbs. |
|---|---|---|---|
| Bolts, Balance Shaft Carrier to Block | 54 | 40 | |
| Fastener - Double Ended, Balance Shaft Gear Cover | 12 | 105 | |
| Bolt, Balance Shaft Sprocket | 28 | 250 | |
| Bolts, Balance Shaft Chain Tensioner | 12 | 105 | |
| Bolts, Balance Shaft Carrier Cover | 12 | 105 | |
| Bolt, Camshaft Sprocket | 115 | 85 | |
| Bolts, Connecting Rod Cap | 27 +1/4 turn | 20 + 1/4 turn | |
| Bolts, Crankshaft Main Bearing Cap/Bedplate M8 Bolts M11 Bolts | 28 75 | 55 | 250 |
| Crankshaft Damper | 136 | 100 | |
| Bolts, Cylinder Head | (Refer to INSTALLATION - CYLINDER HEAD ) | ||
| Bolts, Cylinder Head Cover | 12 | 105 | |
| Flex Plate to Crankshaft | 95 | 70 | |
| Flywheel Mounting Bolts | 81 | 60 | |
| Bolts, Engine Mount Bracket Right | 61 | 45 | |
| Bolts, Engine Mounting | (Refer to ENGINE MOUNTING ) | ||
| Bolts, Exhaust Manifold to Cylinder Head | 23 | 200 | |
| Bolts, Exhaust Manifold Heat Shield | 12 | 105 | |
| Bolts, Intake Manifold - Lower | 28 | 250 | |
| Oil Filter | 20 | 15 | |
| Bolts, Oil Pan | 12 | 105 | |
| Plug, Oil Pan Drain | 27 | 20 | |
| Bolts, Oil Pump to Block | 28 | 250 | |
| Bolts, Oil Pump Cover Plate | 12 | 105 | |
| Bolt, Oil Pump Pick-up Tube | 28 | 20 | |
| Cap - Oil Pump Relief Valve | 41 | 30 | |
| Spark Plugs | 28 | 20.6 | |
| Bolts, Timing Belt Covers - Front Covers to Rear Covers - Rear Cover | 12 12 | 105 105 | |
| Bolts, Timing Belt Tensioner Assembly | 61 | 45 | |
TORQUE SPECIFICATIONS
