Electronically Controlled Clutch Jeep Compass I facelift

Scheme 43

1. Raise vehicle on a hoist.
2. Remove the rear propeller shaft. Refer to «Removal»(/jeep/compass/i-facelift-2010-2013/remont/driveshaft-universal-joints/#propeller-shaft) .
3. Remove the exhaust system up to the catalytic converter. Refer to «MUFFLER, Exhaust, Removal»(ref-462494-S22346038582012040500000).
4. Remove the ECC wire routing bracket bolt and bracket.
5. Disconnect ECC breather hose.
6. Unplug the electrical connector (3).
7. Remove the four ECC mounting bolts (1).
8. Slide ECC from rear axle and lower.
9. Remove all old gasket material on the mating surfaces of the ECC and RDA. Remove wave washer.

INSTALLATION

1. Apply RTV to the EEC mounting surface.
2. Install wave washer.
3. Slide ECC into rear axle.
4. Install the four ECC mounting bolts and tighten to 68 N.m (50 ft. lbs.).
5. Plug the electrical connector (3) in.
6. Connect the breather hose to EEC.
7. Install the EEC Harness routing bracket bolt and tighten to 14 N.m (124 in. lbs.).
8. Install the rear propeller shaft. Refer to «Installation»(/jeep/compass/i-facelift-2010-2013/remont/driveshaft-universal-joints/#propeller-shaft__installation) .
9. Install the exhaust system. Refer to «MUFFLER, Exhaust, Installation»(ref-462494-S41184946632012040500000).
