Wiring diagram: Starting/charging — Charging circuit Jeep Compass I facelift 2
All systems — 30 systems
- Air conditioning
- Anti-lock brakes
- Anti-theft
- Body control modules
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers
- Engine performance 2.0l
- Engine performance 2.4l
- Exterior lights 3
- Ground distribution
- Headlights
- Horn
- Instrument cluster 2
- Interior lights
- Navigation 3
- Power distribution
- Power door locks
- Power mirrors 2
- Power seats 2
- Power top/sunroof
- Power windows
- Radio 3
- Shift interlock 4
- Starting/charging 2
- Supplemental restraints
- Transmission 3
- Warning systems 2
- Wiper/washer
Components on these wiring diagrams 10
Click a component to highlight it on every diagram it appears on.
