FLUID - CAPACITIES & RECOMMEND
| Component | Fluids, Lubricants and Genuine Parts |
|---|
| Engine Coolant | Mopar ® Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Additive Technology) or equivalent. |
| Engine Oil | Use API Certified SAE 5W-20 Engine Oil. Refer to your engine oil filler cap for correct SAE grade meeting DaimlerChrysler Material Standard MS-6395. |
| Engine Oil Filter | Mopar ® 04884900AB or equivalent. |
| Spark Plugs | ZFR5F-11 (Gap 0.043") |
| Fuel Selection | 87 Octane (R + M)/2 |
| Component | Fluids, Lubricants and Genuine Parts |
|---|
| Engine Coolant - Gasoline Engines | Mopar ® Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Additive Technology) or equivalent. |
| Engine Coolant - Diesel Engine | Glysantin G 30-91 Antifreeze/Coolant, 5 Year/150,00 Mile Formula (ASTM D3306) |
| Engine Oil (Gasoline Engines) - Non ACEA Categories | Use API Certified SAE 5W-20 engine oil, meeting the requirements of DaimlerChrysler Material Standard MS-6395. Refer to your engine oil filler cap for correct SAE grade. SAE 5W-30 engine oil approved to MB 229.31 or MB 229.51 may be used when SAE 5W-20 engine oil is not available. |
| Engine Oil (Gasoline Engines) - ACEA Categories | For countries that use the ACEA European Oil Categories for Service Fill Oils, use engine oils meeting the requirements of ACEA C3, and approved to MB 229.31 or MB 229.51. SAE 5W-30 engine oil approved to MB 229.31 or MB 229.51 may be used when SAE 5W-20 engine oil is not available. |
| Engine Oil - Diesel | Use only synthetic SAE 5W-30, SAE 0W-40, SAE 5W-40, SAE 10W-40, or SAE 15W-40, engine oil meeting the requirements of ACEA C3 and approved to VW 507.00. |
| Engine Oil Filter - Gasoline Engines | Mopar ® 04884900AB or equivalent. |
| Engine Oil Filter - Diesel Engine | Mopar ® 68001297AA Cartridge. |
| Spark Plugs | ZFR5F-11 (Gap 0.043"). |
| Fuel Selection - Gasoline Engines | 91 Research Octane Number (RON) |
| Fuel Selection - Diesel Engines | 50 Cetane or higher (Less than 15 ppm Sulfur). |
| Component | Fluids, Lubricants and Genuine Parts. |
|---|
| Automatic Transaxle Fluid | Mopar ® CVTF+4 |
| Manual Transaxle Fluid | Mopar ® ATF+4 MS9602 |
| Rear Drive Assembly (RDA) | Mopar ® Gear & Axle Lubricant SAE 80W-90 API GL 5 or equivalent non-synthetic product. |
| Power Transfer Unit (PTU) | Mopar ® Gear & Axle Lubricant SAE 80W-90 API GL 5 or equivalent non-synthetic product. |
| Brake Master Cylinder | Mopar ® DOT 3, SAE J1703 should be used. If DOT 3, SAE J1703 brake fluid is not available, then DOT 4 is acceptable. Use only recommended brake fluids or equivalent. |
| Power Steering Reservoir | Mopar ® Power Steering Fluid+4 or Mopar® ATF+4 Automatic Transmission Fluid. |
| DESCRIPTION | U.S. | Metric |
|---|
| Fuel (Approximate) | 13.5 Gallons | 51.0 Liters |
| Engine Oil-With Filter |
| All Gasoline Engines (Use API Certified SAE 5W-20 Engine Oil.) | 4.5 Quarts | 4.26 Liters |
| Cooling System * |
| Mopar ® Antifreeze/Coolant 5 Year/100,000 Miles Formula, or equivalent. | 7.2 Quarts | 6.8 Liters |
| Automatic Transaxle |
| Automatic Transaxle - Estimated Service Fill | 4.0 Quarts | 3.8 Liters |
| Automatic Transaxle - Overhaul Fill Capacity with Torque Converter Empty | 8.6 Quarts | 8.1 Liters |
| Power Transfer Unit |
| Power Transfer Unit - (PTU) | 1.1 Pints | 540ml |
| Rear Drive Assembly |
| Rear Drive Assembly - (RDA) | 1.1 Pints | 540ml |
| Manual Transaxle |
| Manual Transaxle - NV T355 | 2.5 - 2.8 Quarts | 2.4 - 2.7 Liters |
| Manual Transaxle - BG6 | 2.1 Quarts | 2.0 Liters |
| * Includes heater and coolant recovery bottle filled to MAX level. |
| DESCRIPTION | U.S. | Metric |
|---|
| Fuel (Approximate) | 13.5 Gallons | 51.0 Liters |
| Engine Oil-With Filter |
| All Gasoline Engines (Mopar ® or an equivalent oil approved to MB 229.31 or MB229.51.) | 4.5 Quarts | 4.26 Liters |
| Diesel Engine (Synthetic Diesel engine oils conforming to the most current version of ACEA C3, that are approved to VW 507.00). | 4.2 Quarts | 4.0 Liters |
| Cooling System * |
| All Gasoline Engines use Mopar® Antifreeze/Coolant 5 Year/100,000 Miles Formula, or equivalent. | 7.2 Quarts | 6.8 Liters |
| 2.0L Diesel | 8.0 Quarts | 8.5 Liters |
| Automatic Transaxle |
| Automatic Transaxle - Estimated Service Fill | 4.0 Quarts | 3.8 Liters |
| Automatic Transaxle - Overhaul Fill Capacity with Torque Converter Empty | 8.6 Quarts | 8.1 Liters |
| Power Transfer Unit |
| Power Transfer Unit - (PTU) | 1.1 Pints | 540ml |
| Rear Drive Assembly |
| Rear Drive Assembly - (RDA) | 1.1 Pints | 540ml |
| Manual Transaxle |
| Manual Transaxle - NV T355 | 2.5 - 2.8 Quarts | 2.4 - 2.7 Liters |
| Manual Transaxle - BG6 | 2.1 Quarts | 2.0 Liters |
| * Includes heater and coolant recovery bottle filled to MAX level. |
Scheme 7
Scheme 7: FUSE LOCATIONS & TYPES
An Integrated Power Module (IPM) is located in the engine compartment near the air cleaner assembly. This center contains cartridge fuses and mini-fuses. A label that identifies each component may be printed on the inside of the cover. Refer to "Engine Compartment" in the Owner's Manual for the underhood location of the IPM.
| Cavity | Cartridge Fuse | Mini-Fuse | Description |
|---|
| 1 | Empty | | Empty |
| 2 | | 15 Amp Lt Blue | AWD/4WD ECU Feed |
| 3 | | 10 Amp Red | CHMSL Brake Switch Feed |
| 4 | | 10 Amp Red | Ignition Switch Feed |
| 5 | | 20 Amp Yellow | Trailer Tow |
| 6 | | 10 Amp Red | IOD Sw/Pwr Mir/OCM Steering Cntrl Sdar/Hands-Free Phone |
| 7 | | 30 Amp Green | IOD Sense1 |
| 8 | | 30 Amp Green | IOD Sense2 |
| 9 | 40 Amp Green | | Power Seats |
| 10 | | 20 Amp Yellow | CCN Power Locks |
| 11 | | 15 Amp Lt Blue | Power Outlet |
| 12 | | 20 Amp Yellow | Ign Run/ACC Inverter |
| 13 | | 20 Amp Yellow | Pwr run/ACC Outlet RR |
| 14 | | 10 Amp Red | IOD CCN/ Interior Lighting |
| 15 | 40 Amp Green | | RAD Fan Relay Battery Feed |
| 16 | | 15 Amp Lt Blue | IGN Run/ACC Cigar Ltr/Sunroof |
| 17 | | 10 Amp Red | IOD Feed Mod-Wcm |
| 18 | 40 Amp Green | | ASD Relay Contact PWR Feed |
| 19 | | 20 Amp Yellow | PWR Amp 1 & Amp 2 Feed |
| 20 | | 15 Amp Lt Blue | IOD Feed Radio |
| 21 | | 10 Amp Red | IOD Feed Intrus Mod/Siren |
| 22 | | 10 Amp Red | IGN RUN Heat/AC/Compass Sensor |
| 23 | | 15 Amp Lt Blue | ENG ASD Relay Feed 3 |
| 24 | | 15 Amp Lt Blue | Power Sunroof Feed |
| 25 | | 10 Amp Red | Heated Mirror |
| 26 | | 15 Amp Lt Blue | ENG ASD Relay Feed 2 |
| 27 | | 10 Amp Red | IGN RUN Only ORC Feed |
| 28 | | 10 Amp Red | IGN RUN ORC/OCM Feed |
| 29 | | | Hot Car (No Fuse Required) |
| 30 | | 20 Amp Yellow | Heated Seats |
| 31 | | 10 Amp Red | Headlamp Washer Relay Control |
| 32 | 30 Amp Pink | | ENG ASD Control Feed 1 |
| 33 | | 10 Amp Red | ABS MOD/J1962 Conn/PCM |
| 34 | 30 Amp Pink | | ABS Valve Feed |
| 35 | 40 Amp Green | | ABS Pump Feed |
| 36 | 30 Amp Pink | | Headlamp/Washer Control/Smart Glass |
| 37 | | 25 Amp Natural | 110 Inverter |
| CAUTION | When installing the IPM cover, it is important to ensure the cover is properly positioned and fully latched. Failure to do so may allow water to get into the IPM, and possibly result in an electrical system failure. |
| CAUTION | When replacing a blown fuse, it is important to use only a fuse having the correct amperage rating. The use of a fuse with a rating other than indicated may result in a dangerous electrical system overload. If a properly rated fuse continues to blow, it indicates a problem in the circuit that must be corrected. |
