Oil Change Indicator System - If Equipped
The oil change indicator system will remind you that it is time to take your vehicle in for scheduled maintenance.
On Electronic Vehicle Information Center (EVIC) equipped vehicles "Oil Change Required" will be displayed in the EVIC and a single chime will sound, indicating that an oil change is necessary.
On Non-EVIC equipped vehicles "Change Oil" will flash in the instrument cluster odometer and a single chime will sound, indicating that an oil change is necessary.
Based on engine operation conditions the oil change indicator message will illuminate, this means that service is required for your vehicle. Have your vehicle serviced as soon as possible, within the next 500 miles (805 km).
- The oil change indicator message will not monitor the time since the last oil change. Change your vehicles oil if it has been 2 years since your last oil change even if the oil change indicator message is NOT illuminated.
- Change your engine oil every 15 000 km if you drive your vehicle off-road for an extended period of time.
- Under no circumstances should oil change intervals exceed (30,000 km) or 2 years, whichever occurs first.
Your dealer will reset the oil change indicator message after completing the scheduled oil change. If a scheduled oil change is performed by someone other than your dealer, the message can be reset by referring to the steps described below.
SEVERE DUTY
If your vehicle is operated under the Severe Duty conditions listed below change your engine oil and filter every 3,000 miles (5 000 km) or 3 months as indicated in the Maintenance Schedule.
- Stop and go driving.
- Driving in dusty conditions.
- Short trips of less than 16 km (10 miles).
- Trailer towing.
- Taxi, police, or delivery service (commercial service).
- Off-road or desert operation.
SCHEDULE A
| Kilometers | 12 000 | 24 000 | 36 000 | 48 000 | 60 000 |
|---|---|---|---|---|---|
| (Miles) | (7,500) | (15,000) | (22,500) | (30,000) | (37,500) |
| [Months] | [6] | [12] | [18] | [24] | [30] |
| Change engine oil and engine oil filter. | X | X | X | X | X |
| Rotate tires. | X | X | X | X | X |
| Check spare tire for proper pressure and correct stowage. | X | X | X | X | X |
| Inspect brake linings. | X | ||||
| Replace engine air cleaner filter. | X | ||||
| Replace spark plugs. | X | ||||
| Replace climate control air filtration filter (if equipped). | X | X | X | X | X |
| Kilometers | 72 000 | 84 000 | 96 000 | 108 000 | 120 000 | 132 000 |
|---|---|---|---|---|---|---|
| (Miles) | (45,000) | (52,500) | (60,000) | (67,500) | (75,000) | (82,500) |
| [Months] | [36] | [42] | [48] | [54] | [60] | [66] |
| Change engine oil and engine oil filter. | X | X | X | X | X | X |
| Change Rear Drive Assembly (RDA) fluid. | X | |||||
| Change Power Transfer Unit (PTU) fluid. | X | |||||
| Rotate tires. | X | X | X | X | X | X |
| Check spare tire for proper pressure and correct stowage. | X | X | X | X | X | X |
| Flush and replace engine coolant at 60 months, regardless of mileage. | X | |||||
| Inspect brake linings. | X | X | ||||
| Replace engine air cleaner filter. | X | |||||
| Replace spark plugs. | X | |||||
| Inspect PCV valve, replace as necessary. | X | |||||
| Replace climate control air filtration filter (if equipped). | X | X | X | X | X | X |
| Kilometers | 144 000 | 156 000 | 160 000 | 168 000 | 181 000 | 192 000 |
|---|---|---|---|---|---|---|
| (Miles) | (90,000) | (97,500) | (100,000) | (105,000) | (112,500) | (120,000) |
| [Months] | [72] | [78] | [84] | [90] | [96] | |
| Change engine oil and engine oil filter. | X | X | X | X | X | |
| Rotate tires. | X | X | X | X | X | X |
| Change Rear Drive Assembly (RDA) fluid. | X | |||||
| Change Power Transfer Unit (PTU) fluid. | X | |||||
| Check spare tire for proper pressure and correct stowage. | X | X | X | X | X | |
| Flush and replace engine coolant, if not done at 60 mos. | X | |||||
| Inspect brake linings. | X | X | ||||
| Replace engine air cleaner filter. | X | X | ||||
| Replace spark plugs. | X | X | ||||
| Inspect PCV valve, replace as necessary. | X | X | ||||
| Replace the Accessory Drive Belt. | X | |||||
| Replace climate control air filtration filter (if equipped). | X | X | X | X | X |
Inspection and service should also be performed anytime a malfunction is observed or suspected. Retain all receipts.
SCHEDULE B
Follow schedule "B" if you usually operate your vehicle under one or more of the following conditions.
- Day or night temperatures are below 0° C (32° F).
- Stop and go driving.
- Extensive engine idling.
- Driving in dusty conditions.
- Short trips of less than 16 km (10 miles).
- More than 50% of your driving is at sustained high speeds during hot weather, above 32° C (90° F).
- Trailer towing.
- Taxi, police, or delivery service (commercial service).
- Off-road or desert operation.
Note. If ANY of these apply to you then change your engine oil every 3,000 miles (5 000 km) or 3 months, whichever comes first and follow schedule "B" of the " MAINTENANCE SCHEDULES " .
Note. If ANY of these apply to you then change your coolant every 160 000 km (100,000 miles) or 60 months, whichever comes first and follow schedule "B" of the " MAINTENANCE SCHEDULES " .
| Kilometers | 5 000 | 10 000 | 14 000 | 19 000 | 24 000 |
|---|---|---|---|---|---|
| (Miles) | (3,000) | (6,000) | (9,000) | (12,000) | (15,000) |
| Change engine oil and engine oil filter, or at 3 months whichever comes first. | X | X | X | X | X |
| Rotate tires. | X | X | |||
| Check spare tire for proper pressure and correct stowage. | X | X | |||
| Inspect engine air cleaner filter, replace if necessary. | X | ||||
| Replace climate control air filtration filter (if equipped). | X |
| Kilometers | 29 000 | 34 000 | 38 000 | 43 000 | 48 000 |
|---|---|---|---|---|---|
| (Miles) | (18,000) | (21,000) | (24,000) | (27,000) | (30,000) |
| Change engine oil and engine oil filter, or at 3 months whichever comes first. | X | X | X | X | X |
| Rotate tires. | X | X | X | ||
| Check spare tire for proper pressure and correct stowage. | X | X | X | ||
| Inspect brake linings. | X | ||||
| Replace engine air cleaner filter. | X | ||||
| Replace spark plugs. | X | ||||
| Inspect PCV valve, replace as necessary. | X | ||||
| Replace climate control air filtration filter (if equipped). | X |
| Kilometers | 53 000 | 58 000 | 62 000 | 67 000 | 72 000 |
|---|---|---|---|---|---|
| (Miles) | (33,000) | (36,000) | (39, 000) | (42,000) | (45,000) |
| Change engine oil and engine oil filter, or at 3 months whichever comes first. | X | X | X | X | X |
| Rotate tires. | X | X | |||
| Check spare tire for proper pressure and correct stowage. | X | X | |||
| Inspect brake linings. | X | ||||
| Inspect engine air cleaner filter, replace if necessary. | X | ||||
| Replace climate control air filtration filter (if equipped). | X |
| Kilometers | 77 000 | 82 000 | 86 000 | 91 000 | 96 000 |
|---|---|---|---|---|---|
| (Miles) | (48,000) | (51,000) | (54,000 ) | (57,000 ) | (60,000) |
| Change engine oil and engine oil filter, or at 3 months whichever comes first. | X | X | X | X | X |
| Change Automatic Transaxle (CVT) Fluid and Filter. | X | ||||
| Change Manual Transaxle Fluid. | X | ||||
| Change Rear Drive Assembly (RDA) fluid. | X | ||||
| Change Power Transfer Unit (PTU) fluid. | X | ||||
| Rotate tires. | X | X | X | ||
| Check spare tire for proper pressure and correct stowage. | X | X | X | ||
| Inspect brake linings. | X | ||||
| Replace engine air cleaner filter, replace if necessary. | X | ||||
| Replace spark plugs. | X | ||||
| Inspect PCV valve, replace as necessary. | X | ||||
| Flush and replace engine coolant at 60 months, or 160 000 km (100,000 miles) whichever comes first. | |||||
| Replace climate control air filtration filter (if equipped). | X | X |
| Kilometers | 101 000 | 106 000 | 110 000 | 115 000 | 120 000 |
|---|---|---|---|---|---|
| (Miles) | (63,000) | (66,000) | (69,000) | (72,000) | (75,000) |
| Change engine oil and engine oil filter, or at 3 months whichever comes first. | X | X | X | X | X |
| Rotate tires. | X | X | |||
| Check spare tire for proper pressure and correct stowage. | X | X | |||
| Inspect brake linings. | X | ||||
| Inspect engine air cleaner filter, replace if necessary. | X | ||||
| Replace climate control air filtration filter (if equipped). | X |
| Kilometers | 125 000 | 130 000 | 134 000 | 139 000 | 144 000 |
|---|---|---|---|---|---|
| (Miles) | (78,000) | (81,000) | (84,000) | (87,000) | (90,000) |
| Change engine oil and engine oil filter, or at 3 months whichever comes first. | X | X | X | X | X |
| Rotate tires. | X | X | X | ||
| Check spare tire for proper pressure and correct stowage. | X | X | X | ||
| Inspect brake linings. | X | ||||
| Replace engine air cleaner filter. | X | ||||
| Replace spark plugs. | X | ||||
| Inspect PCV valve, replace as necessary. | X | ||||
| Replace climate control air filtration filter (if equipped). | X |
| Kilometers | 149 000 | 154 000 | 158 000 | 160 000 | 163 000 |
|---|---|---|---|---|---|
| (Miles) | (93,000) | (96,000) | (99,000) | (100,000) | (102,000) |
| Change engine oil and engine oil filter, or at 3 months whichever comes first. | X | X | X | X | |
| Change Manual Transaxle Fluid. | X | ||||
| Rotate tires. | X | X | |||
| Check spare tire for proper pressure and correct stowage. | X | X | |||
| Flush and replace engine coolant, if not done at 60 months. | X | ||||
| Replace climate control air filtration filter (if equipped). | X |
| Kilometers | 168 000 | 173 000 | 178 000 | 182 000 | 187 000 | 192 000 |
|---|---|---|---|---|---|---|
| (Miles) | (105,000) | (108,000) | (111,000) | (114,000) | (117,000) | (120,000) |
| Change engine oil and engine oil filter, or at 3 months whichever comes first. | X | X | X | X | X | X |
| Change Automatic Transaxle (CVT) fluid and filter. | X | |||||
| Change Rear Drive Assembly (RDA) fluid. | X | |||||
| Change Power Transfer Unit (PTU) fluid. | X | |||||
| Rotate tires. | X | X | X | |||
| Check spare tire for proper pressure and correct stowage. | X | X | X | |||
| Inspect brake linings. | X | |||||
| Replace engine air cleaner filter. | X | X | ||||
| Replace spark plugs. | X | |||||
| Inspect PCV valve, replace as necessary. | X | |||||
| Replace the Accessory Drive Belt. | X | |||||
| Replace climate control air filtration filter (if equipped). | X | X |
Inspection and service should also be performed anytime a malfunction is observed or suspected. Retain all receipts.
| WARNING | You can be badly injured working on or around a motor vehicle. Do only that service work for which you have the knowledge and the right equipment. If you have any doubt about your ability to perform a service job, take your vehicle to a competent mechanic. |
TRAILER TOWING
In this article you will find safety tips and information on limits to the type of towing you can reasonably do with your vehicle. Before towing a trailer, carefully review this information to tow your load as efficiently and safely as possible.
To maintain warranty coverage, follow the requirements and recommendations in this service information concerning vehicles used for trailer towing.
Common Towing Definitions
The following trailer towing related definitions will assist you in understanding the information
Gross Vehicle Weight Rating (GVWR)
The GVWR is the total allowable weight of your vehicle. This includes driver, passengers, cargo and tongue weight. The total load must be limited so that you do not exceed the GVWR.
Gross Trailer Weight (GTW)
The gross trailer weight (GTW) is the weight of the trailer plus the weight of all cargo, consumables and equipment (permanent or temporary) loaded in or on the trailer in its "loaded and ready for operation" condition. The recommended way to measure GTW is to put your fully loaded trailer on a vehicle scale. The entire weight of the trailer must be supported by the scale.
Gross Combination Weight Rating (GCWR)
The gross combination weight rating (GCWR) is the total permissible weight of your vehicle and trailer when weighed in combination.
Note. The GCWR ratings include a 150 lbs (68 kg) allowance for the presence of a driver.
Gross Axle Weight Rating (GAWR)
The GAWR is the maximum capacity of the front and rear axles. Distribute the load over the front and rear axles evenly. Make sure that you do not exceed either front or rear GAWR.
| WARNING | It is important that you do not exceed the maximum front or rear GAWR. A dangerous driving condition can result if either rating is exceeded. You could lose control of the vehicle and have an accident. |
Tongue Weight (TW)
The Tongue Weight is the downward force exerted on the hitch ball by the trailer. In most cases it should not be less than 10% or more than 15% of the trailer load. You must consider this as part of the load on your vehicle.
Frontal Area
The frontal area is the maximum height and maximum width of the front of a trailer.
Trailer Sway Control
The trailer sway control is a telescoping link that can be installed between the hitch receiver and the trailer tongue that typically provides adjustable friction associated with the telescoping motion to dampen any unwanted trailer swaying motions while traveling.
Weight-Carrying Hitch
A weight-carrying hitch supports the trailer tongue weight, just as if it were luggage located at a hitch ball or some other connecting point of the vehicle. These kind of hitches are the most popular on the market today and they're commonly used to tow small- and medium-sized trailers.
Weight-Distributing Hitch
A weight-distributing system works by applying leverage through spring (load) bars. They are typically used for heavier loads, to distribute trailer tongue weight to the tow vehicle's front axle and the trailer axle(s). When used in accordance with the manufacturers' directions, it provides for a more level ride, offering more consistent steering and brake control, thereby enhancing towing safety. The addition of a friction/hydraulic sway control also dampens sway caused by traffic and crosswinds and contributes positively to tow vehicle and trailer stability. Trailer sway control and a weight distributing (load equalizing) hitch are recommended for heavier Tongue Weights (TW) and may be required depending on Vehicle and Trailer configuration/loading to comply with Gross Axle Weight Rating (GAWR) requirements.
| WARNING | An improperly adjusted weight-distributing hitch system may reduce handling, stability, and braking performance, and could result in an accident. Weight-Distributing Systems may not be compatible with Surge Brake Couplers. Consult with your hitch and trailer manufacturer or a reputable Recreational Vehicle dealer for additional information. |
Trailer Hitch Classification
Your vehicle may be factory equipped for safe towing of trailers weighing over 2,000 lbs (907 kg) with the optional Trailer Tow Prep Package. See your authorized dealer for package content.
The following chart provides the industry standard for the maximum trailer weight a given trailer hitch class can tow and should be used to assist you in selecting the correct trailer hitch for your intended towing condition. Refer to the Trailer Towing Weights (Maximum Trailer Weight Ratings) chart below for the maximum GTW towable for your given drivetrain.
| Trailer Hitch Classification | |
|---|---|
| Class | Max. GTW (Gross Trailer Wt.) |
| Class I - Light Duty | 2,000 lbs. (907 kg) |
| Class II - Medium Duty | 3,500 lbs. (1 587 kg) |
| Class III - Heavy Duty | 5,000 lbs. (2 268 kg) |
| Class IV - Extra Heavy Duty | 10,000 lbs. (4 540 kg) |
All trailer hitches should be professionally installed on your vehicle.
Trailer Towing Weights (Maximum Trailer Weight Ratings)
The following chart provides the maximum trailer weight ratings towable for your given drivetrain.
| Engine/Transmission | Frontal Area | Max. GTW (Gross Trailer Wt.) | Max. Tongue Wt. (See Note Below ) |
|---|---|---|---|
| 2.4L Auto/Man | 22 sq ft (2.04 sq m) | 1000 lbs (453 kg) | 150 lbs (68 kg) |
| 2.4L Auto/Man with Trailer Tow Prep Package (AHC) | 32 sq ft (3.0 Sq. m) | 2000 lbs (907 kg) | 225 lbs (102 kg) |
| Refer to local laws for maximum trailer towing speeds. | |||
Note. The trailer tongue weight must be considered as part of the combined weight of occupants and cargo, and should never exceed the weight referenced on the Tire and Loading Information placard. Refer to the TIRES/WHEELS - SERVICE INFORMATION article for Tire-Safety Information.
Trailer and Tongue Weight
Always load a trailer with 60% to 65% of the weight in the front of the trailer. This places 10% to 15% of the Gross Trailer Weight (GTW) on the tow hitch of your vehicle. Loads balanced over the wheels or heavier in the rear can cause the trailer to sway severely from side-to-side which will cause loss of control of the vehicle and trailer. Failure to load trailers heavier in front is the cause of many trailer accidents.
Never exceed the maximum trailer tongue weight stamped on your bumper or trailer hitch.
Scheme 10
Consider the following items when computing the weight on the rear axle of the vehicle
- The trailer tongue weight of the trailer.
- The weight of any other type of cargo or equipment put in or on your vehicle.
- The weight of the driver and all passengers.
Note. Remember that everything put into or on the trailer adds to the load on your vehicle. Also, additional factory-installed options, or authorized dealer-installed options, must be considered as part of the total load on your vehicle. Refer to the TIRES/WHEELS - SERVICE INFORMATION article for Tire and Loading Information placard in the Tire Safety Information for the maximum combined weight of occupants and cargo for your vehicle.
Towing Requirements
To promote proper break-in of your vehicle drivetrain components, the following guidelines are recommended
| CAUTION | Avoid towing a trailer for the first 500 mi (805 km) of vehicle operation. Doing so may damage your vehicle. During the first 500 mi (805 km) of trailer towing, limit your speed to 50 mph (80 km/h). |
Perform the maintenance listed in the " MAINTENANCE SCHEDULES ." . When towing a trailer, never exceed the GAWR, or GCWR, ratings.
| WARNING | Improper towing can lead to an injury accident. Follow these guidelines to make your trailer towing as safe as possible: Make certain that the load is secured in the trailer and will not shift during travel. When trailering cargo that is not fully secured, dynamic load shifts can occur that may be difficult for the driver to control. You could lose control of your vehicle and have an accident. |
- When hauling cargo or towing a trailer, do not overload your vehicle or trailer. Overloading can cause a loss of control, poor performance or damage to brakes, axle, engine, transmission, steering, suspension, chassis structure or tires.
- Safety chains must always be used between your vehicle and trailer. Always connect the chains to the frame or hook retainers of the vehicle hitch. Cross the chains under the trailer tongue and allow enough slack for turning corners.
- Vehicles with trailers should not be parked on a grade. When parking, apply the parking brake on the tow vehicle. Put the tow vehicle automatic transmission in PARK. Always block or "chock" the trailer wheels.
- GCWR must not be exceeded.
- Total weight must be distributed between the tow vehicle and the trailer such that the following four ratings are not exceeded: GVWR GTW GAWR Tongue weight rating for the trailer hitch utilized (This requirement may limit the ability to always achieve the 10% to 15% range of tongue weight as a percentage of total trailer weight).
Towing Requirements - Tires
- Do not attempt to tow a trailer while using a compact spare tire.
- Proper tire inflation pressures are essential to the safe and satisfactory operation of your vehicle. Refer to the «TIRES/WHEELS - SERVICE INFORMATION»(ref-304327) article for information on Tire Pressures for proper tire inflation procedures.
- Also, check the trailer tires for proper tire inflation pressures before trailer usage.
- Check for signs of tire wear or visible tire damage before towing a trailer. Refer to the «TIRES/WHEELS - SERVICE INFORMATION»(ref-304327) article for information on Tread Wear Indicators for the proper inspection procedure.
- When replacing tires refer to the «TIRES/WHEELS - SERVICE INFORMATION»(ref-304327) article for information on Replacement Tires for proper tire replacement procedures. Replacing tires with a higher load carrying capacity will not increase the vehicle's GVWR and GAWR limits.
Towing Requirements - Trailer Brakes
- Do not interconnect the hydraulic brake system or vacuum system of your vehicle with that of the trailer. This could cause inadequate braking and possible personal injury.
- An electronically actuated trailer brake controller is required when towing a trailer with electronically actuated brakes. When towing a trailer equipped with a hydraulic surge actuated brake system, an electronic brake controller is not required.
- Trailer brakes are recommended for trailers over 1,000 lbs (454 kg) and required for trailers in excess of 2,000 lbs (907 kg).
| CAUTION | If the trailer weighs more than 1,000 lbs (454 kg) loaded, it should have its own brakes and they should be of adequate capacity. Failure to do this could lead to accelerated brake lining wear, higher brake pedal effort, and longer stopping distances. |
| WARNING | Do not connect trailer brakes to your vehicle's hydraulic brake lines. It can overload your brake system and cause it to fail. You might not have brakes when you need them and could have an accident. Towing any trailer will increase your stopping distance. When towing you should allow for additional space between your vehicle and the vehicle in front of you. Failure to do so could result in an accident. |
Towing Tips
Before setting out on a trip, practice turning, stopping and backing the trailer in an area away from heavy traffic.
Towing Tips - Automatic Transmission
The automatic transmission fluid and filter should be changed if you REGULARLY tow a trailer for more than 45 minutes of continuous operation. Refer to the " MAINTENANCE SCHEDULES " for transmission fluid change intervals.
Check the automatic transmission fluid level before towing.
Towing Tips - Electronic Speed Control (if equipped)
- Don't use in hilly terrain or with heavy loads.
- When using the speed control, if you experience speed drops greater than 10 mph (16 km/h), disengage until you can get back to cruising speed.
- Use speed control in flat terrain and with light loads to maximize fuel efficiency.
Towing Tips - Cooling System
To reduce potential for engine and transmission overheating, take the following actions
- City Driving - When stopped for short periods of time, put transmission in Neutral and increase engine idle speed.
- Highway Driving - Reduce speed.
- Air Conditioning - Turn off temporarily.
- Refer to «COOLING»(ref-304343) for more information.
