SPECIFICATIONS - SPARK PLUGS
| Engine | Spark Plug | Electrode Gap | Thread Size |
|---|
| 2.0, 2.4L | ZFR5F-11 | 1.1 mm (0.043 in.) | M14 X 1.25 |
SPECIFICATIONS - TORQUE
| DESCRIPTION | N.m | Ft. Lbs. | In. Lbs. |
|---|
| Camshaft Position Sensor Screw | 9 | | 79.5 |
| Crankshaft Position Sensor Screw | 9 | | 79.5 |
| Coolant Temp. Sensor | 18.6 | | 165 |
| Ignition Coil Bolt | 9 | | 79.5 |
| Ignition Coil Capacitor Bolt | 10 | | 88.5 |
| Ignition Switch Mounting Screw | 2 | | 18 |
| Knock Sensor Bolt | 22 | | 195 |
| Lock Cylinder to Column | 12 | | 110 |
| Spark Plugs | 27 | 20 | |
| Variable Valve Timing Solenoid | 12 | 9 | |
| SKREEM/WCM | 2.5 | | 22 |
Scheme 31
Scheme 32
Scheme 32: CAPACITOR-IGNITION
- Disconnect and isolate negative battery cable at battery.
- Remove electrical connector (1).
- Remove mounting bolt (3) and ignition capacitor (2).
