Lubrication & Maintenance: Maintenance Jeep Compass I

BRAKE FLUID

The brake fluid used in this vehicle must conform to DOT 3 specifications and SAE J1703 standards. No other type of brake fluid is recommended or approved for usage in the vehicle brake system. Use only Mopar® Brake Fluid or equivalent from a tightly sealed container.

POWER STEERING FLUID

The recommended fluid for the power steering system is Mopar® Power Steering fluid + 4 or Mopar® ATF+4 Automatic Transmission Fluid. Both Fluids have the same material standard specifications (MS-9602).

Mopar® ATF+4 (and Mopar® Power Steering fluid + 4), when new, is red in color. ATF+4 is dyed red so it can be identified from other fluids used in the vehicle such as engine oil or antifreeze. The red color is not permanent and is not an indicator of fluid condition. As the vehicle is driven, ATF+4 will begin to look darker in color and may eventually become brown. THIS IS NORMAL . ATF+4 also has a unique odor that may change with age. Consequently, odor and color cannot be used to indicate the fluid condition or the need for a fluid change.

The power steering system is filled-for-life at the factory and requires no regular maintenance. Although not required at specific intervals, the fluid level may be checked periodically. Check the fluid level anytime there is a system noise or fluid leak suspected. Refer to STANDARD PROCEDURE .

TRANSMISSION - PTU AND RDA FLUIDS

Mopar ® CVT+4 is required in the CVT automatic transaxles.

Mopar ® CVT+4 when new is green in color. As the vehicle is driven, the ATF will begin to look darker in color and may eventually become brown. This is normal. A dark brown/black fluid accompanied with a burnt odor and/or deterioration in shift quality may indicate fluid deterioration or transmission component failure.

BG6 and T355 Manual transaxles require the use of Mopar ® ATF+4 (Automatic Transmission Fluid).

PTU and RDA use Mopar ® Gear & Axle Lubricant SAE 80W-90 API GL 5 or equivalent non-synthetic product.

FLUID ADDITIVES

DaimlerChrysler strongly recommends against the addition of any fluids to the transmission, other than those automatic transmission fluids listed above. Exceptions to this policy are the use of special dyes to aid in detecting fluid leaks.

Various "special" additives and supplements exist that claim to improve shift feel and/or quality. These additives and others also claim to improve converter clutch operation and inhibit overheating, oxidation, varnish, and sludge. These claims have not been supported to the satisfaction of DaimlerChrysler and these additives must not be used . The use of transmission "sealers" should also be avoided, since they may adversely affect the integrity of transmission seals.

FLUID FILL/CHECK LOCATIONS

The fluid check/fill point locations are located in each applicable service information article .

LUBRICATION POINTS

Lubrication point locations are located in each applicable article.

OIL CHANGE INDICATOR - RESET

Your vehicle is equipped with an engine oil change indicator system. The "Oil Change Required" message will flash in the EVIC display for approximately 10 seconds after a single chime has sounded to indicate the next scheduled oil change interval. The engine oil change indicator system is duty cycle based, which means the engine oil change interval may fluctuate dependent upon your personal driving style.

Unless reset, this message will continue to display each time you turn the ignition switch to the ON/RUN position. To turn off the message temporarily, press and release the Menu button. To reset the oil change indicator system (after performing the scheduled maintenance) perform the following procedure

1. Turn the ignition switch to the "ON" position (Do not start the engine).
2. Fully depress the accelerator pedal slowly three times within 10 seconds.
3. Turn the ignition switch to the "LOCK" position.

Note. If the indicator message illuminates when you start the vehicle, the oil change indicator system did not reset. If necessary repeat this procedure.

At Each Stop for Fuel

1. Check the engine oil level and add as required.
2. Check the windshield washer solvent and add if required.

Once a Month

1. Check the tire pressure and look for unusual wear or damage.
2. Inspect the battery and clean and tighten the terminals as required.
3. Check the fluid levels of coolant reservoir, brake master cylinder, power steering, and transaxle, and add as needed.
4. Check all lights and all other electrical items for correct operation.

At Each Oil Change

1. Replace the engine oil filter at each oil change.
2. Inspect the exhaust system.
3. Inspect brake linings, hoses, and calipers.
4. Inspect the CV joints and suspension components.
5. Check the coolant level, hoses, and clamps.
6. Inspect engine accessory drive belt(s).

Required Maintenance Intervals

<-- Performing the engine oil change indicator system reset procedure described under CHANGE OIL INDICATOR allows for a 15 000 km service interval for engine oil and filter changes. The oil change indicator system allows for up to a 30 000 km service interval for engine oil and filter changes when your vehicle is serviced by your authorized dealer.

MAINTENANCE SCHEDULES - EXPORT GASOLINE - EUROPE, UK, MID EAST

To help you have the best driving experience possible, the manufacturer has identified the specific vehicle maintenance service intervals that are required to keep your vehicle operating properly and safely.

DaimlerChrysler recommends that these maintenance intervals be performed at your selling dealer. The technicians at your dealership know your vehicle best, and have access to factory trained information, genuine Mopar parts, and specially designed electronic and mechanical tools that can help prevent future costly repairs.

The maintenance intervals shown in this article should be performed as indicated .

Note. Under no circumstances should oil change intervals exceed 7,500 miles (12 000 km) or 12 months, whichever comes first.

At Each Stop for Fuel

1. Check the engine oil level about five minutes after a fully warmed engine is shut off. Checking the oil level while the vehicle is on level ground will improve the accuracy of the oil level reading. Add oil only when the level is at or below the ADD or MIN mark.
2. Check the windshield washer solvent and add if required.

Once a Month

1. Check tire pressure and look for unusual wear or damage.
2. Inspect the battery and clean and tighten the terminals as required.
3. Check the fluid levels of coolant reservoir, brake master cylinder, power steering and transmission and add as needed.
4. Check all lights and other electrical items for correct operation.

At Each Oil Change

1. Change the engine oil filter.
2. Inspect the brake hoses and lines.
3. Check the Manual Transmission fluid level.

MAINTENANCE SCHEDULES - EXPORT GASOLINE - REST OF WORLD

There are two maintenance schedules that show the required service for your vehicle.

First is Schedule "A." It lists all the scheduled maintenance to be performed under "normal" (if none of the conditions in SCHEDULE B apply to you) operating conditions.

Second is Schedule "B" . It is a schedule for vehicles that are operated under the conditions listed below.

Follow SCHEDULE B if you usually operated you vehicle under one or more of the following conditions.

1. Day or night temperatures are below 0° C (32° F).
2. Stop and go driving.
3. Extensive engine idling.
4. Driving in dusty conditions.
5. Short trips of less than 16 km (10 miles).
6. More than 50% of your driving is at sustained high speeds during hot weather, above 32° C (90° F).
7. Trailer towing.
8. Taxi, police, or delivery service (commercial service).
9. Off-road or desert operation.

Note. If ANY of these apply to you then change your engine oil every 5 000 km (3,000 miles) or 3 months, whichever comes first and follow SCHEDULE B .

Note. If ANY of these apply to you then change your coolant every 160 000 km (100,000 miles) or 60 months, whichever comes first and follow SCHEDULE B .

Note. Most vehicles are operated under the conditions listed for SCHEDULE B .

Use the schedule that best describes your driving conditions. Where time and mileage are listed, follow the interval that occurs first.

At Each Stop for Fuel

1. Check the engine oil level about 5 minutes after a fully warmed engine is shut off. Checking the oil level while the vehicle is on level ground will improve the accuracy of the oil level reading.
2. Check the windshield washer solvent and add if required.

Once a Month

1. Check tire pressure and look for unusual wear or damage.
2. Inspect the battery and clean and tighten the terminals as required.
3. Check the fluid levels of coolant reservoir, brake/clutch master cylinder, and add as needed.
4. Check all lights and all other electrical items for correct operation.

At Each Oil Change

1. Change the engine oil filter.
2. Inspect the exhaust system.
3. Inspect the brake hoses.
4. Inspect the CV joints (if equipped) and front suspension components.
5. Check the automatic transmission fluid level.
6. Visually check manual transaxle for leakage. Add fluid, if necessary, to maintain the proper fluid level.
7. Check the coolant level, hoses, and clamps.

MAINTENANCE SCHEDULES - NAFTA - KOREAN GAS

The oil change indicator system will remind you that it is time to take your vehicle in for scheduled maintenance.

On Electronic Vehicle Information Center (EVIC) equipped vehicles, "Oil Change Required" will be displayed in the EVIC and a single chime will sound, indicating that an oil change is necessary.

On Non-EVIC equipped vehicles, "Change Oil" will flash in the instrument cluster odometer and a single chime will sound, indicating that an oil change is necessary.

Based on engine operation condition, the oil change indicator message will illuminate; this means that service is required for your vehicle. Have your vehicle serviced as soon as possible, within the next 500 mi (805 km).

Note. The oil change indicator message will not monitor the time since the last oil change. Change your vehicles oil if it has been six months since your last oil change and even if the oil change indicator message is NOT illuminated. Change your engine oil more often if you drive your vehicle off-road for an extended period of time. Under no circumstances should oil change intervals exceed 6,000 mi (10 000 km) or six months, whichever comes first.

Your authorized dealer will reset the oil change indicator message after completing the scheduled oil change. If this scheduled oil change is performed by someone other than your authorized dealer, the message can be reset by referring to the steps described below.

Your vehicle is equipped with an engine oil change indicator system. The "Oil Change Required" message will flash in the EVIC display for approximately 10 seconds after a single chime has sounded to indicate the next scheduled oil change interval. The engine oil change indicator system is duty cycle based, which means the engine oil change interval may fluctuate dependent upon your personal driving style.

Unless reset, this message will continue to display each time you turn the ignition switch to the ON/RUN position. To turn off the message temporarily, press and release the Menu button. To reset the oil change indicator system (after performing the scheduled maintenance) perform the following procedure

1. Turn the ignition switch to the "ON" position (Do not start the engine).
2. Fully depress the accelerator pedal slowly three times within 10 seconds.
3. Turn the ignition switch to the "LOCK" position.

Note. If the indicator message illuminates when you start the vehicle, the oil change indicator system did not reset. If necessary repeat this procedure.

At Each Stop for Fuel

1. Check the engine oil level about five minutes after a fully warmed engine is shut off. Checking the oil level while the vehicle is on level ground will improve the accuracy of the oil level reading. Add oil only when the level is at or below the ADD or MIN mark.
2. Check the windshield washer solvent and add if required.

Once a Month

1. Check the tire pressure and look for unusual wear or damage.
2. Inspect the battery and clean and tighten the terminals as required.
3. Check the fluid levels of coolant reservoir, brake master cylinder, power steering and transmission and add as needed.
4. Check all lights and other electrical items for correct operation.

At Each Oil Change

1. Change the engine oil filter.
2. Inspect the brake hoses and lines.
3. Check the manual transmission fluid level.

Scheme 1

Refer to Owner's Manual provided with vehicle for proper emergency jacking procedures.

When properly positioned, a floor jack can be used to lift the vehicle and support the raised vehicle with jack stands.

A floor jack or any lifting device, must never be used on any part of the underbody other then the described areas.
