Continuously Variable Transmission (Cvt) - Electrical Diagnostics: Diagnosis Jeep Compass I

Diagnostic Test

1. CHECK FOR OTHER TRANSMISSION DTCS With the scan tool, check for other transmission DTCs. Are there any TCC, gear ratio and/or speed sensor DTCs present in addition to P0219? Yes Refer to the appropriate Transmission DTC and repair as necessary. If speed sensor DTCs are present, perform their respective tests first. No Go to 2 .
2. CHECK FOR ENGINE DTCS With the scan tool, check for engine DTCs. Are there any engine DTCs present? Yes Refer to the appropriate Engine ELECTRICAL DIAGNOSTICS article and repair as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go to 3 .
3. CHECK IF DTC RESETS With the scan tool erase transmission DTCs. Test drive the vehicle and try to duplicate the setting conditions. Pick the answer that best describes your findings: DTC resets with a speed sensor DTC Refer to the appropriate Transmission DTC and repair as necessary. DTC resets without a speed sensor DTC Replace or repair the CV Transmission as necessary per the Service Information. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go to 4 .
4. INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test Complete.

Scheme 1

1. CHECK FOR RELATED CHARGING SYSTEM DTCS With the scan tool, read the Engine DTCs. Are there any Charging System related DTCs present? Yes Refer to the appropriate Engine ELECTRICAL DIAGNOSTICS article and repair any Charging System DTCs before proceeding. After repairing the Charging System DTCs, perform the Transmission Verification test to verify the transmission and or controller was not damaged. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go To 2 .
2. CHECK FOR TIPM DTCS NOTE: Generator, battery, and charging system must be fully functional before performing this test. With the scan tool, read TIPM DTCs. Are there any TIPM TCM Power Control Circuit DTCs present also? Yes Refer to the appropriate Transmission DTC and repair as necessary. No Go To 3 .
3. CONDITION P0563 PRESENT With the scan tool, read Transmission DTCs. Is the status active for this DTC? Yes Go To 4 . No Go To 5 .
4. CHECK IF THE VEHICLE WAS JUMP-STARTED Was the vehicle jump-started improperly (in series) or connected to a 24 volt or higher electrical system? Yes Go To 5 . No Using the schematics as a guide, check the Transmission Control Module (TCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. If no problems are found, replace and program the TCM per the Service Information. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) .
5. INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test Complete.

1. CHECK IF THE DTC IS ACTIVE With the scan tool, read Transmission DTCs. Is the status Active for this DTC or is the STARTS SINCE SET counter 2 or less? Yes Go To 2 . No Go To 4 .
2. CHECK FOR ENGINE BRAKE SWITCH DTCS With the scan tool, check for engine brake switch DTCs. With the scan tool, check if the brake switch changes when the brake pedal is pressed. Are there any engine brake switch DTCs present or is the brake switch not registering any change on the scan tool? Yes Refer to the appropriate Engine ELECTRICAL DIAGNOSTICS article and perform the appropriate symptom. If no DTCs are present and the brake switch does not seem to function, diagnose the brake switch as though a valid DTC is present. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go To 3 .
3. CHECK OTHER CONTROLLERS FOR BRAKE SWITCH DTCS With the scan tool check other controllers for Brake Switch DTCs. Do any other controllers report a Brake Switch DTC? Yes Refer to the appropriate Engine ELECTRICAL DIAGNOSTICS article and perform diagnostics for P0571 as though the DTC is active. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Using the schematics as a guide, check the Transmission Control Module (TCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for any Service Bulletins for possible causes that may apply. If no problems are found, replace the TCM per the Service Information. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) .
4. INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test Complete.

1. CHECK FOR CAN BUS DTCS With the scan tool, check for CAN BUS DTCs. Are there any CAN BUS DTCs present? Yes Refer to the Communication information and perform the appropriate symptom. Refer to «DIAGNOSIS AND TESTING»(ref-304334-S10935475992008110700000) . Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go To 2 .
2. CHECK IF CONTROLLER WAS REPLACED Has the Transmission Control Module been recently replaced? Yes Go To 3 . No Go To 5 .
3. CHECK IF CONTROLLER WAS PROGRAMED Was the Transmission Control Module flashed? Yes Go To 4 . No Flash the control module with the proper part number for the vehicle. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) .
4. CHECK FOR OTHER DTCS With the scan tool, check Transmission DTCs. Are the DTCs P0602 and U140F Active and P161B and P1729 Stored? Yes Check the Controller part number coincides with the vehicle setup such as engine size or with or without All wheel Drive (AWD). This is an indication of an improper vehicle configuration. Verify all configurations to the Vehicle Identification Number (VIN) and reprogram as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go To 5 .
5. CHECK THE FCM FOR PROPER PROGRAMING OF TIRE SIZE With the scan tool, check the TIPM/FCM for proper tire size programing. Is the tire size properly programed in the TIPM/FCM? Yes Using the schematics as a guide, check the Transmission Control Module (TCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for any Service Bulletins for possible causes that may apply. If no problems are found, replace the TCM per the Service Information. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Program the TIPM/FCM with the proper tire size. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) .

1. CHECK IF THE DTC IS ACTIVE With the scan tool, read Transmission DTCs. Is the status Active for this DTC? Yes Go To 2 . No Go To 4 .
2. CHECK THE TIPM Has the TIPM been reprogrammed (tire size) or replaced without being programed? Yes Program the TIPM if not programed. If the tire size was changed, with the scan tool perform a Initialize CVT procedure. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go To 3 .
3. CHECK THE TCM Has the TCM been recently replaced with a new or used controller? Yes With the scan tool perform a TCM relearn. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Using the schematics as a guide, check the Transmission Control Module (TCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for any Service Bulletins for possible causes that may apply. If no problems are found, replace the TCM per the Service Information. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) .
4. INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test Complete.

Scheme 2

1. CHECK TO SEE IF THE DTC IS ACTIVE With the scan tool, read Transmission DTCs. Is the status Active for this DTC or is the STARTS SINCE SET counter 2 or less? Yes Go To 2 . No Go To 5 .
2. CHECK THE TRS READINGS ON THE SCAN TOOL SHIFT LEVER POSITION TO TRS SWITCH STATE PARK REVERSE NEUTRAL DRIVE LOW T41 CLOSED T42 CLOSED T4 CLOSED T3 CLOSED T1 CLOSED Ignition on, engine not running. With the scan tool, read the TRS states while moving the shift lever to all positions note any circuits may close at the same time. NOTE: Vehicles equipped with the AutoStick feature will not have a low range shift position. Did one or more than one TRS Sense circuit show being closed at the same time? Yes Go To 3 . No Check the Shift Lever Cable for proper adjustment and binding per the Service Information. If no problems are found, using the schematics as a guide, check the Transmission Control Module (TCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for any Service Bulletins for possible causes that may apply. If again no problems are found, replace the TCM per the Service Information Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) .
3. CHECK THE TRS SENSE CIRCUIT FOR A SHORT TO VOLTAGE Turn the ignition off to the lock position. Disconnect the TRS harness connector. NOTE: The possibility of erroneous DTCs may set due to disconnection of the TRS harness connector. Disregard any additional DTCs that may set. Ignition on, engine not running. Using the scan tool, read the TRS Sense circuit states. Do any of the TRS Sense circuits read closed? Yes Repair the identified TRS Sense circuit for a short to voltage. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go To 4 .
4. CHECK THE TRS SENSE CIRCUIT FOR A SHORT TO ANOTHER TRS SENSE CIRCUIT Turn the ignition off to the lock position. Disconnect the TCM C1 and C2 harness connectors. Measure the resistance between the two identified TRS Sense circuits in the second step. Is the resistance below 5.0 ohms? Yes Repair the identified TRS Sense circuits for a short to each other. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Replace the TRS Assembly per the Service Information. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) .
5. INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test Complete.

1. CHECK FOR ENGINE CAM OR CRANK SENSOR DTCS With the scan tool, read transmission DTCs. Is the DTC P0717-Input Speed Sensor 1 Circuit No Signal also present? Yes Refer to the Symptom list and perform diagnostics for «P0717-INPUT SPEED SENSOR 1 CIRCUIT NO SIGNAL»(ref-304346-S05445442942008110700000) . No Go to 2 .
2. REPAIR INTERNAL TRANSMISSION This DTC indicates an internal transmission problem. Check for the following possible causes but not limited to these: Step motor Shift Valve sticking CVT Belt slipping Hydraulic control circuit including the Valve Body Repair Replace or repair the CV Transmission per the Service Information. Refer to «REMOVAL»(ref-304401-S36790110272008110700000) . Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) .

1. CHECK TO SEE IF THE DTC IS ACTIVE With the scan tool, erase Transmission DTCs. Start the vehicle and check Transmission Fluid Level per the Service Information and adjust as necessary. Test drive the vehicle to a constant speed greater than 40 Km/h (25 mph) for the period of at least 30 seconds. NOTE: This can not be performed on a hoist, actual road conditions must be present for proper results. Did the DTC reset (one trip) during the road test? Yes Replace or repair the CV Transmission as necessary. Note the components related to the Torque Converter Clutch (TCC) such as the TCC Solenoid, control valves, valve body leakage or the TCC. Refer to the Service Information. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go To 2 .
2. INTERMITTENT CONDITION The conditions necessary to set this DTC are not present at this time. Refer to an Technical Service Bulletins that may apply. It may be necessary to Test Drive the vehicle again trying different conditions that may cause the DTC to reset. Were there any problems found or did the DTC reset? Yes Repair as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test Complete.

Scheme 3

1. CHECK IF THE DTC IS ACTIVE With the scan tool, read Transmission DTCs. Is the status Active for this DTC or is the STARTS SINCE SET counter 2 or less? Yes Go To 2 . No Go To 7 .
2. CHECK LINE PRESSURE Approximate Engine rpm to Line pressure readings Engine rpm Line Pressure Idle 750 kPa (108.8 psi) ± 400 kPa (58 psi) 2.0L - 2500 to 3000 rpm 5300 - 5700 kPa (768.5 - 826.5 psi) ± 400 kPa (58 psi) 2.4L - 2600 to 3100 rpm Start the engine and warm the transmission to 50 - 80° C (122 - 174° F). Turn the ignition off to the lock position. Install an appropriate pressure gauge in the Line Pressure test port per the Service Information. WARNING: The CV Transmission can generate a line pressure up to 1800 psi. Failure to use recommended test equipment referred to by the Service Information can result in personal injury or death. With the scan tool, erase Transmission DTCs. WARNING: Apply the parking brake. Failure to follow these instructions can result in personal injury or death. With the brakes firmly applied, start the engine allow to idle and shift the transmission into Reverse, Drive and Low while recording the scan tool Line pressure reading and the pressure gauge reading in each shift lever position. With the brakes still firmly applied, raise the engine rpm between 2700 - 3250 rpm and shift the transmission into Reverse, Drive and Low while recording the scan tool line pressure reading and the pressure gauge reading in each shift lever position. CAUTION: Do not hold the engine rpm between 2700 - 3250 rpm for more than 5 seconds in any given shift position. If the 5 second threshold is exceeded, transmission damage can occur. Allow to idle in neutral between shifts for at least 15 to 20 seconds to allow transmission fluid to cool. Do the gauge readings fall into the desired pressure ranges? Yes Go To step 4 . No Go To step 3 .
3. VERIFY PROBLEM Possible causes to conditions detected ENGINE RPM LINE PRESSURE CONDITION DETECTED POSSIBLE CAUSES BUT NOT JUST LIMITED TO THESE Idle speed Low for all shift lever positions Oil Pump Wear Pressure Regulator Valve for plug sticking or spring fatigue Oil filter, oil pump, pressure regulator valve passage oil leak Engine idle speed too low Only low for a specific position Oil pressure leak in a passage or component related to the position after the pressure is distributed by the manual valve High TP or APP sensor signal malfunction CVT fluid temperature sensor malfunction Line pressure solenoid sticking in the off state, filter plugged, cut line Pressure regulator valve or plug sticking Engine rpm between 2700 and 3250 rpm Line pressure does not rise above the line pressure at idle TP or APP sensor signal malfunction Line pressure solenoid sticking in the on state, filter plugged Pressure regulator valve or plug sticking Transmission Control Module (TCM) Oil pump weak or worn Line Pressure rises but does not reach desired level TP or APP sensor signal malfunction Line pressure solenoid sticking in the off state, filter plugged, cut line Pressure regulator valve or plug sticking Oil pump weak or worn Line pressure is low in only one shift lever position Oil pressure leak in a passage or component related to the position after the pressure is distributed by the manual valve Use the above chart to help identify the possible cause. NOTE: There may be other possible causes besides those listed on the above chart. Review any Service Bulletins and refer to the Service Information for any additional possible causes that may apply. View repair Repair Replace or repair the CV Transmission as necessary per the Service Information Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) .
4. CHECK THE SECONDARY PRESSURE Turn the ignition off to the lock position. Disconnect the pressure gauge from the Line Pressure test port and reinstall the test port plug. Install the pressure gauge in the Secondary Pressure test port per the Service Information. With the scan tool, erase Transmission DTCs. WARNING: Apply the parking brake. Failure to follow these instructions can result in personal injury or death. With the brakes firmly applied, start the engine allow to idle and shift the transmission into Reverse, Drive and Low while comparing the Secondary Pressure gauge reading to the scan tool Secondary Pressure reading in each shift lever position and record your findings. With the brakes still firmly applied, raise the engine rpm between 2700 - 3250 rpm and shift the transmission into Reverse, Drive and Low while comparing the gauge Secondary Pressure to the scan tool Secondary Pressure in each shift lever position and record your findings. CAUTION: Do not hold the engine rpm between 2700 - 3250 rpm for more than 5 seconds in any given shift position. If the 5 second threshold is exceeded, transmission damage can occur. Allow to idle in neutral between shifts for at least 15 to 20 seconds to allow transmission fluid to cool. Does the Secondary Pressure gauge readings match the scan tool readings in all of the above procedures? Yes Replace or repair the CV Transmission as necessary per the Service Information for components related to the Secondary Pressure Control System. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go To step 5 .
5. CHECK THE SECONDARY PRESSURE SENSOR Turn the ignition off to the lock position. Disconnect the pressure gauge from the Secondary Pressure test port and reinstall the test port plug. Disconnect the Transmission Solenoid/Pressure Switch Assembly harness connector. Connect a jumper wire between the (T50) Secondary Pressure Sensor Signal circuit and the (T72) 5-volt Supply circuit in the Transmission Solenoid/Pressure Switch Assembly harness connector. Ignition on, engine not running. With the scan tool read the Secondary Pressure voltage. Is the voltage between 4.5 and 5.5 volts? Yes Replace the CVT or the Secondary Pressure Sensor (Valve Body) per the Service Information. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go To step 6 .
6. CHECK THE (T21) PRIMARY PRESSURE SENSOR SIGNAL CIRCUIT FOR HIGH RESISTANCE Turn the ignition off to the lock position. Disconnect the TCM C2 harness connector. Connect a jumper wire between the B(+) and the (T21) Primary Pressure Sensor Signal circuit in the Transmission Solenoid/Pressure Switch harness connector. Using a 12-volt test light connected to ground, check the (T21) Primary Pressure Sensor Signal circuit in the TCM C2 harness connector. NOTE: The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly? Yes Using the schematics as a guide, check the Transmission Control Module (TCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for any Service Bulletins for possible causes that may apply. If no problems are found, replace the TCM per the Service Information. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Repair the (T21) Primary Pressure Sensor Signal circuit for an open (high resistance). Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) .
7. INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test Complete.

Scheme 4

1. CHECK IF THE DTC IS ACTIVE Ignition on, engine not running. With the scan tool, check Transmission DTCs. Are there any Speed Sensor or Transmission Range Sensor DTCs present? Yes Refer to the appropriate Transmission DTC and repair as necessary. No Go to 2 .
2. CHECK IF THE DTC IS ACTIVE Ignition on, engine not running. With the scan tool, check TIPM DTCs. Is the status Active for this DTC? Yes Go to 3 . No Go to 6 .
3. CHECK THE (T16) TRANSMISSION CONTROL OUTPUT CIRCUIT SHORT TO GROUND Turn the ignition off Disconnect the TIPM C8 harness connector. Disconnect the TCM C1 harness connector. Measure the resistance between ground and the (T16) Transmission Control Output circuit. Is the resistance below 5.0 ohms? Yes Repair the (T16) Transmission Control Output circuit for a short to ground. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go to 4 .
4. CHECK THE (T16) TRANSMISSION CONTROL OUTPUT CIRCUIT FOR AN OPEN Turn the ignition off to the lock position. Reconnect the TIPM C8 harness connector. Ignition on, engine not running. Using the scan tool under the TIPM Actuators, actuate the Transmission. Using a 12-volt test light connected to ground, check the (T16) Transmission Control Output circuits. NOTE: The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly at all the (T16) Transmission Control Output circuits? Yes Go To 5 . No Repair the (T16) Transmission Control Output circuit for an open. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) .
5. TOTALLY INTEGRATED POWER MODULE Using the schematics as a guide, inspect the wire harness and connectors. Check the TIPM harness connector terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Were any problems found? Yes Repair as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Replace and program the TIPM per Service Information. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) .
6. INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. While monitoring the scan tool data relative to this circuit, wiggle test the wiring and connectors. Look for the data to change or for the DTC to reset during the wiggle test. Were any problems found? Yes Repair as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test complete.

1. CHECK IF THE DTC IS ACTIVE Ignition on, engine not running. With the scan tool, read TIPM DTCs. Is the status Active for this DTC? Yes Go to 2 . No Go to 4 .
2. (T16) TRANSMISSION CONTROL OUTPUT CIRCUIT SHORT TO VOLTAGE Turn the ignition off to the lock position. Disconnect the TIPM C10 harness connector. Disconnect the TCM C1 harness connector. Ignition on, engine not running. Measure the voltage of the (T16) Transmission Control Output circuit. Is the voltage above 10.0 volts? Yes Repair the (T16) Transmission Control Output circuit for a short to voltage. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go to 3 .
3. TOTALLY INTEGRATED POWER MODULE Using the schematics as a guide, inspect the wire harness and connectors. Check the TIPM harness connector terminals for corrosion, damage, or terminal push out Pay particular attention to all power and ground circuits. Were there any problems found? Yes Repair as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Replace the Totally Integrated Power Module per Service Information. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) .
4. INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. While monitoring the scan tool data relative to this circuit, wiggle test the wiring and connectors. Look for the data to change or for the DTC to reset during the wiggle test. Were any problems found? Yes Repair as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test complete.

1. CHECK IF THE DTC IS ACTIVE Ignition on, engine not running. With the scan tool, select View DTCs. Is the status Active for this DTC? Yes Go to 2 . No Go to 4 .
2. CHECK THE (T16) TRANSMISSION CONTROL OUTPUT CIRCUIT FOR AN OPEN Turn the ignition off to the lock position. Disconnect the TCM C1 harness connector. Ignition on, engine not running. Using the scan tool under the TIPM Actuators, actuate the Transmission. Using a 12-volt test light connected to ground, check the (T16) Transmission Control Output circuits. NOTE: The test light must illuminate brightly. Compare the brightness to that of a direct connection to the battery. Does the test light illuminate brightly? Yes Go To 3 . No Repair the (T16) Transmission Control Output circuit for an open. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) .
3. TOTALLY INTEGRATED POWER MODULE Using the schematics as a guide, inspect the wire harness and connectors. Check the TIPM harness connector terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Were any problems found? Yes Repair as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Replace and program the TIPM per Service Information. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) .
4. INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. While monitoring the scan tool data relative to this circuit, wiggle test the wiring and connectors. Look for the data to change or for the DTC to reset during the wiggle test. Were any problems found? Yes Repair as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test complete.

1. CHECK IF THE DTC IS ACTIVE Ignition on, engine not running. With a scan tool, read TIPM DTCs. Is the DTC active at this time? Yes Go To 2 . No Go To 4 .
2. CHECK IF THE DTC IS ACTIVE Ignition on, engine not running. With a scan tool, read Transmission DTCs. Are there any Input or Output Speed Sensor or Transmission Range Sensor (TRS) DTCs present? Yes Refer to the appropriate Transmission DTC and repair as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go To 3 .
3. CHECK THE TCM Disconnect the amp meter from the TIPM C10 harness connector and battery positive. Disconnect the TCM C1 harness connector. Connect the positive probe of an ammeter to battery positive and connect the negative probe to the (T16) Transmission Control Output circuit in the TIPM C10 harness connector. Read the amperage on the ammeter. Does the amperage read below 2.0 amps? Yes Using the schematics as a guide, check the Transmission Control Module (TCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. If no problems are found, replace the TCM per the Service Information. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Replace the Totally Integrated Control Module per the Service Information. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) .
4. INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test Complete.

Scheme 5

1. CHECK TO SEE IF THE DTC IS ACTIVE With the scan tool, read Transmission DTCs. Is the status Active for P161B? Yes Go To 3 . No Go To 2 .
2. CHECK FOR OTHER DTCS With the scan tool, read Transmission DTCs. Is the status Active for P0602 also? Yes Refer to the Transmission DTCs and perform diagnostic procedure for «P0602-CONTROL MODULE PROGRAMING ERROR/NOT PROGRAMMED»(ref-304346-S12973026872008110700000) . No Go To 3 .
3. CHECK THE TCM Has the TCM been flashed, a new TCM installed or the battery or TCM disconnected with the ignition in the On or Accessory position? Yes This is a normal condition. Cycle the ignition off for 4 seconds and turn the ignition back on. Erase DTCs and cycle the ignition off again for 4 seconds and turn the ignition back on. Read TCM DTCs. If the DTC resets and remains active - Go To 4 . If the DTC does not reset perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Using the schematics as a guide, check the Transmission Control Module (TCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. NOTE: A loss of the TCM Fused B(+), TCM ground, and/or the Transmission Control Output circuits can cause this fault to set. Check for any Service Bulletins for possible causes that may apply. If no problems are found, replace and program the TCM per the Service Information. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) .
4. CHECK IF THE RIGHT PART NUMBER IS USED With the scan tool, check the TCM part number and compare it to the vehicle configuration. Does the controller have the right part number? Yes Using the schematics as a guide, check the Transmission Control Module (TCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. NOTE: A loss of the TCM Fused B(+), TCM ground, and/or the Transmission Control Output circuits can cause this fault to set. Check for any Service Bulletins for possible causes that may apply. If no problems are found, replace and program the TCM per the Service Information. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Do to the configuration mismatch the controller will need to be replaced with the proper part number for the configuration of the vehicle. Replace and program the TCM per the Service Information. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) .

1. CHECK IF THE DTC IS ACTIVE With the scan tool, read Transmission DTCs. Is the status Active for this DTC? Yes Go To 2 . No Go To 4 .
2. CHECK FOR OTHER DTCS With the scan tool, read Transmission DTCs. Is the DTC U1146-LOST COMMUNICATION WITH EXTERNAL MEMORY also present? Yes Refer to the Transmission DTCs and perform diagnostics for «U1146-LOST COMMUNICATION WITH EXTERNAL MEMORY»(ref-304346-S16154098402008110700000) . No Go To 3 .
3. CHECK THE TCM Has the Transmission Control Module (TCM), the CV Transmission been replaced, or a Transmission relearn procedure been performed? Yes Cycle the ignition off for 5 seconds and then back on. Erase the DTC and cycle the ignition again. If the DTC still remains active, check the Transmission Control Module (TCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for any Service Bulletins for possible causes that may apply. If no problems are found, replace the TCM per the Service Information. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Using the schematics as a guide, check the Transmission Control Module (TCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for any Service Bulletins for possible causes that may apply. If no problems are found, replace the TCM per the Service Information. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) .
4. INTERMITTENT WIRING AND CONNECTORS If the DTC is not active, erase the DTC and perform the «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . Did the DTC P1679-CALIBRATION NOT LEARNED reset? Yes Go To 2 . No Test Complete.

1. PERFORM TCM RELEARN PROCEDURE View repair Repair This is an informational DTC indicating that the TCM, CV Transmission, or the CV Transmission internal controller (valve body) was replaced without being calibrated. With the scan tool perform a Re-initialize CVT procedure. Refer to «STANDARD PROCEDURE»(ref-304335-S25493952562008110700000) . Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) .

1. CHECK FOR TRANSMISSION DTC(s) With the scan tool, read Transmission DTCs. Are any of the following DTC(s) present P0842, P0843, P0847, or P0848? Yes Refer to the appropriate Transmission DTC and repair as necessary. No Go To 2 .
2. CHECK TO SEE IF THE DTC IS ACTIVE With the scan tool, read Transmission DTCs. Is the status Active for this DTC or is the STARTS SINCE SET counter 2 or less? Yes Go To 3 . No Go To 4 .
3. CHECK THE TCM Replace or repair (valve body) the CV Transmission per the Service Information. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . Did the DTC reset during the verification test? Yes Using the schematics as a guide, check the Transmission Control Module (TCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for any Service Bulletins for possible causes that may apply. If no problems are found, replace the TCM per the Service Information. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test Complete.
4. INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test Complete.

1. CHECK CUSTOMER DRIVING HABITS Check with the customer about how the vehicle is driven. Below are some conditions that can cause this DTC to set. Driving a steep upward slope with low vehicle speed. Accelerator pedal and brake pedal pressed simultaneously. Accelerator pedal pressed under drive train locked condition (Off-Road) View repair Repair As noted in the Theory Of Operation, this DTC is designed to protect the transmission from overheating. Explain to the customer that certain driving habits will cause this DTC to set. Continued overheating may cause Transmission failure. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) .

1. CHECK IF THE DTC IS ACTIVE With the scan tool, read Transmission DTCs. Is the status Active for this DTC? Yes Go to 2 . No Go to 6 .
2. CHECK FOR AWD MODULE DTCS With the scan tool, read DTCs. Does the AWD module have any DTCs present? Yes Refer to «DIAGNOSIS AND TESTING»(ref-304331-S17393280322008110700000) , and perform the appropriate symptom. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go to 3 .
3. CHECK FOR TIPM DTCS With the scan tool, read DTCs. Does the TIPM have any DTCs present? Yes Perform the appropriate symptom. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go to 4 .
4. REPLACE THE AWD MODULE Using the schematics as a guide, check the All Wheel Drive Module (AWD) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for any Service Bulletins for possible causes that may apply. If no problems are found, replace the AWD module per the Service Information. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . Did the DTC P198A reset? Yes Go to 5 . No Test complete.
5. REPLACE THE TIPM Using the schematics as a guide, check the Totally Integrated Control Module (TIPM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for any Service Bulletins for possible causes that may apply. If no problems are found, replace the TIPM per the Service Information. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . Did the DTC P198A reset? Yes Using the schematics as a guide, check the Transmission Control Module (TCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for any Service Bulletins for possible causes that may apply. If no problems are found, replace the TCM per the Service Information. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test complete.
6. CHECK THE WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. Check for any Service Bulletins that may apply. Were there any problems found? Yes Repair as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test Complete.

1. CHECK IF THE DTC IS ACTIVE With the scan tool, read Transmission DTCs. Is the status Active for this DTC or is the STARTS SINCE SET counter 2 or less? Yes Go To 2 . No Go To 4 .
2. CHECK FOR FCM/TIPM CAN BUS DTCS With the scan tool, read FCM/TIPM DTCs. Are there any FCM/TIPM CAN BUS DTCs present? Yes Refer to «DIAGNOSIS AND TESTING»(ref-304334-S10935475992008110700000) and perform the appropriate symptom(s). Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go To 3 .
3. CHECK IF ECM/PCM DTCS ARE PRESENT With the scan tool, read engine DTCs. Are there any engine DTCs present? Yes Refer to appropriate Engine ELECTRICAL DIAGNOSTICS article and perform the appropriate symptom(s). Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Using the schematics as a guide, check the Transmission Control Module (TCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for any Service Bulletins for possible causes that may apply. If no problems are found, replace the TCM per the Service Information. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) .
4. INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test Complete.

1. CHECK IF THE DTC IS ACTIVE With the scan tool, read Transmission DTCs. Is the status Active for this DTC or is the STARTS SINCE SET counter 2 or less? Yes Go to 2 . No Go to 4 .
2. CHECK FOR FCM/TIPM CAN BUS DTCS With the scan tool, read FCM DTCs. Are there any FCM/TIPM CAN BUS DTCs present? Yes Refer to «DIAGNOSIS AND TESTING»(ref-304334-S10935475992008110700000) and perform the appropriate symptom(s). Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go to 3 .
3. CHECK IF ENGINE DTCS ARE PRESENT With the scan tool, read engine DTCs. Are there any engine DTCs present? Yes Refer to appropriate Engine ELECTRICAL DIAGNOSTICS article and perform the appropriate symptom(s). Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Using the schematics as a guide, check the Transmission Control Module (TCM) pins, terminals, and connectors for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. If no problems are found, replace the TCM per the Service Information. Refer to «REMOVAL»(ref-304335-S26085521732008110700000) . Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) .
4. INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test Complete.

1. CHECK IF THE DTC IS ACTIVE With the scan tool, read Transmission DTCs. Is the status Active for this DTC? Yes Go To 2 . No Go To 5 .
2. CHECK FOR FCM/TIPM CAN BUS DTCS With the scan tool, read FCM/TIPM DTCs. Are there any FCM/TIPM CAN BUS DTCs present? Yes Refer to «DIAGNOSIS AND TESTING»(ref-304334-S10935475992008110700000) and perform the appropriate symptom(s). Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go To 3 .
3. CHECK IF ENGINE DTCS ARE PRESENT With the scan tool, read engine DTCs. Are there any engine DTCs present? Yes Refer to appropriate Engine ELECTRICAL DIAGNOSTICS article and perform the appropriate symptom(s). Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go To 4 .
4. CHECK THE PCM Replace and program the PCM per the Service Information. Refer to «REMOVAL»(ref-304335-S16452964842008110700000) . Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . Does the DTC reset? Yes Using the schematics as a guide, check the Transmission Control Module (TCM) pins, terminals, and connectors for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. If no problems are found, replace the TCM per the Service Information. Refer to «REMOVAL»(ref-304335-S26085521732008110700000) . Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test Complete.
5. INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test Complete.

1. CHECK IF THE DTC IS ACTIVE With the scan tool, read Transmission DTCs. Is the status Active for this DTC or is the STARTS SINCE SET counter 2 or less? Yes Go To 2 . No Go To 5 .
2. CHECK FOR FCM/TIPM CAN BUS DTCS With the scan tool, read FCM/TIPM DTCs. Are there any FCM/TIPM CAN BUS DTCs present? Yes Refer to «DIAGNOSIS AND TESTING»(ref-304334-S10935475992008110700000) and perform the appropriate symptom(s). Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go To 3 .
3. CHECK IF THE ECM/PCM WAS REPLACED Was the ECM/PCM replaced? Yes Check to make sure the right part number was used that correlates with the engine and transmission using the vehicle identification number. It may be necessary to flash the ECM/PCM to the proper configuration or replace the controller. With the scan tool perform a TCM relearn procedure. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go To 4 .
4. CHECK IF THE TCM WAS REPLACED Was the TCM replaced? Yes Check to make sure the right part number was used that correlates with engine and transmission using the vehicle identification number. It may be necessary to flash the PCM/TCM to the proper configuration or replace the TCM with the correct configuration. With the scan tool perform a TCM relearn procedure. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Using the schematics as a guide, check the Transmission Control Module (TCM) terminals for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. Check for any Service Bulletins for possible causes that may apply. If no problems are found, replace the TCM per the Service Information. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) .
5. INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test Complete.

1. CHECK MODULE PART NUMBERS TO VEHICLE IDENTIFICATION NUMBER View repair Repair This DTC is an indication of either the FCM/TIPM was replaced with the wrong configuration (improper tire size), or the TCM was replaced with the wrong configuration. If either controller was replaced, confirm the part numbers to the Vehicle Identification Number (VIN) and program or replace as necessary. With the scan tool perform a TCM relearn procedure. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) .

1. CHECK IF THE DTC IS ACTIVE With the scan tool, read Transmission DTCs. Is the status Active for this DTC or is the STARTS SINCE SET counter 2 or less? Yes Go To 2 . No Go To 4 .
2. CHECK FOR FCM/TIPM CAN BUS DTCS With the scan tool, read FCM DTCs. Are there any FCM/TIPM CAN BUS DTCs present? Yes Refer to «DIAGNOSIS AND TESTING»(ref-304334-S10935475992008110700000) and perform the appropriate symptom(s). Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go To 3 .
3. CHECK IF ABS DTCS ARE PRESENT With the scan tool, read ABS DTCs. Are there any ABS DTCs present? Yes Refer to «DIAGNOSIS AND TESTING»(ref-304326-S04170629762008110700000) and perform the appropriate symptom(s). Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Using the schematics as a guide, check the Transmission Control Module (TCM) pins, terminals, and connectors for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. If no problems are found, replace the TCM per the Service Information. Refer to «REMOVAL»(ref-304335-S26085521732008110700000) . Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) .
4. INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test Complete.

1. CHECK IF THE DTC IS ACTIVE With the scan tool, read Transmission DTCs. Is the status Active for this DTC? Yes Go To 2 . No Go To 5 .
2. CHECK FOR FCM/TIPM CAN BUS DTCS With the scan tool, read FCM/TIPM DTCs. Are there any FCM/TIPM CAN BUS DTCs present? Yes Refer to «DIAGNOSIS AND TESTING»(ref-304334-S10935475992008110700000) and perform the appropriate symptom(s). Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go To 3 .
3. CHECK IF ENGINE DTCS ARE PRESENT With the scan tool, read engine DTCs. Are there any engine DTCs present? Yes Refer to appropriate Engine ELECTRICAL DIAGNOSTICS article and perform the appropriate symptom(s). Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go To 4 .
4. CHECK THE PCM Replace and program the PCM per the Service Information. Refer to «REMOVAL»(ref-304335-S16452964842008110700000) . Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . Does the DTC reset? Yes Using the schematics as a guide, check the Transmission Control Module (TCM) pins, terminals, and connectors for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. If no problems are found, replace the TCM per the Service Information. Refer to «REMOVAL»(ref-304335-S26085521732008110700000) . Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test Complete.
5. INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test Complete.

1. CHECK IF THE DTC IS ACTIVE With the scan tool, read Transmission DTCs. Is the status Active for this DTC? Yes Go To 2 . No Go To 5 .
2. CHECK FOR FCM/TIPM CAN BUS DTCS With the scan tool, read FCM/TIPM DTCs. Are there any FCM/TIPM CAN BUS DTCs present? Yes Refer to «DIAGNOSIS AND TESTING»(ref-304334-S10935475992008110700000) and perform the appropriate symptom(s). Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go To 3 .
3. CHECK IF ENGINE DTCS ARE PRESENT With the scan tool, read engine DTCs. Are there any engine DTCs present? Yes Refer to appropriate Engine ELECTRICAL DIAGNOSTICS article and perform the appropriate symptom(s). Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go To 4 .
4. CHECK THE PCM Replace and program the PCM per the Service Information. Refer to «REMOVAL»(ref-304335-S16452964842008110700000) . Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . Does the DTC reset? Yes Using the schematics as a guide, check the Transmission Control Module (TCM) pins, terminals, and connectors for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. If no problems are found, replace the TCM per the Service Information. Refer to «REMOVAL»(ref-304335-S26085521732008110700000) . Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test Complete.
5. INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test Complete.

1. CHECK IF THE DTC IS ACTIVE With the scan tool, read Transmission DTCs. Is the status Active for this DTC? Yes Go To 2 . No Go To 5 .
2. CHECK FOR FCM/TIPM CAN BUS DTCS With the scan tool, read FCM/TIPM DTCs. Are there any FCM/TIPM CAN BUS DTCs present? Yes Refer to «DIAGNOSIS AND TESTING»(ref-304334-S10935475992008110700000) and perform the appropriate symptom(s). Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go To 3 .
3. CHECK IF ENGINE DTCS ARE PRESENT With the scan tool, read engine DTCs. Are there any engine DTCs present? Yes Refer to appropriate Engine ELECTRICAL DIAGNOSTICS article and perform the appropriate symptom(s). Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go To 4 .
4. CHECK THE PCM Replace and program the PCM per the Service Information. Refer to «REMOVAL»(ref-304335-S16452964842008110700000) . Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . Does the DTC reset? Yes Using the schematics as a guide, check the Transmission Control Module (TCM) pins, terminals, and connectors for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. If no problems are found, replace the TCM per the Service Information. Refer to «REMOVAL»(ref-304335-S26085521732008110700000) . Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test Complete.
5. INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test Complete.

1. CHECK IF THE DTC IS ACTIVE With the scan tool, read Transmission DTCs. Is the status Active for this DTC? Yes Go To 2 . No Go To 5 .
2. CHECK FOR FCM/TIPM CAN BUS DTCS With the scan tool, read FCM/TIPM DTCs. Are there any FCM/TIPM CAN BUS DTCs present? Yes Refer to «DIAGNOSIS AND TESTING»(ref-304334-S10935475992008110700000) and perform the appropriate symptom(s). Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go To 3 .
3. CHECK IF ENGINE DTCS ARE PRESENT With the scan tool, read engine DTCs. Are there any engine DTCs present? Yes Refer to appropriate Engine ELECTRICAL DIAGNOSTICS article and perform the appropriate symptom(s). Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go To 4 .
4. CHECK THE PCM Replace and program the PCM per the Service Information. Refer to «REMOVAL»(ref-304335-S16452964842008110700000) . Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . Does the DTC reset? Yes Using the schematics as a guide, check the Transmission Control Module (TCM) pins, terminals, and connectors for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. If no problems are found, replace the TCM per the Service Information. Refer to «REMOVAL»(ref-304335-S26085521732008110700000) . Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test Complete.
5. INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test Complete.

1. CHECK IF THE DTC IS ACTIVE With the scan tool, read Transmission DTCs. Is the status Active for this DTC? Yes Go To 2 . No Go To 5 .
2. CHECK FOR FCM/TIPM CAN BUS DTCS With the scan tool, read FCM/TIPM DTCs. Are there any FCM/TIPM CAN BUS DTCs present? Yes Refer to «DIAGNOSIS AND TESTING»(ref-304334-S10935475992008110700000) and perform the appropriate symptom(s). Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go To 3 .
3. CHECK IF ENGINE DTCS ARE PRESENT With the scan tool, read engine DTCs. Are there any engine DTCs present? Yes Refer to appropriate Engine ELECTRICAL DIAGNOSTICS article and perform the appropriate symptom(s). Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Go To 4 .
4. CHECK THE PCM Replace and program the PCM per the Service Information. Refer to «REMOVAL»(ref-304335-S16452964842008110700000) . Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . Does the DTC reset? Yes Using the schematics as a guide, check the Transmission Control Module (TCM) pins, terminals, and connectors for corrosion, damage, or terminal push out. Pay particular attention to all power and ground circuits. If no problems are found, replace the TCM per the Service Information. Refer to «REMOVAL»(ref-304335-S26085521732008110700000) . Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test Complete.
5. INTERMITTENT WIRING AND CONNECTORS The conditions necessary to set this DTC are not present at this time. Using the schematics as a guide, inspect the wiring and connectors specific to this circuit. Wiggle the wires while checking for shorted and open circuits. Were there any problems found? Yes Repair as necessary. Perform «CVT VERIFICATION TEST»(ref-304346-S20667500612008110700000) . No Test Complete.

CVT VERIFICATION TEST

Perform the following after completion of a diagnostic repair

1. Reconnect any disconnected components.
2. With the scan tool, erase all Transmission and Engine DTCs.
3. If the Transmission Control Module or the Transmission has been repaired or replaced, it is necessary to perform the scan tool Initialize CVT Re-learn Procedure. Refer to «STANDARD PROCEDURE»(ref-304335-S25493952562008110700000) .
4. With the scan tool, display Transmission Temperature. Start and run the engine until the transmission temperature is HOT, above 43° C or 110° F.
5. Check the transmission fluid and adjust if necessary. Refer to the Service Information for the Fluid Fill procedure. CAUTION: The CVT uses a specific transmission fluid type that is green in color. Do not use a standard ATF fluid. Doing so can damage the transmission. Make sure to follow the Service Information fluid type and fill procedure.
6. Road test the vehicle. With the scan tool, monitor the engine rpm and throttle angle. Drive the vehicle from a standing start to 45 mph with a constant throttle opening of 20 to 25 degrees with an engine speed above 450 rpm.
7. For a specific DTC, drive the vehicle to the Symptom's When Monitored/When Set condition to verify the DTC is repaired.
8. If equipped with AutoStick®, upshift and downshift several times using the AutoStick® feature during the road test. NOTE: Use the OBDII task manager to run a Good Trip. This will confirm the repair(s) made and to ensure the DTC has not re-matured.
9. Check for any Diagnostic Trouble Codes (DTCs) during and after the road test.

Did any Diagnostic Trouble Codes set during the road test?

Yes

1. Repair is not complete. Refer to the Transmission DTCs and perform the appropriate symptom(s). See «DIAGNOSIS AND TESTING»(ref-304346-S25968872092008110700000) .

No

1. Repair is complete.
