Engine Cooling System: Removal & Installation Jeep Compass I рестайлинг 2

REMOVAL

1. Raise vehicle on hoist.
2. Remove belt splash shield.
3. Remove accessory drive belt (2). Refer to «BELT, SERPENTINE, REMOVAL»(ref-612716-S26668951772014043000000) .
4. Remove idler pulley mounting bolt. Remove idler pulley (5 or 9).

INSTALLATION

1. Position pulley (5 or 9) in mounting position. Install idler pulley mounting bolt. Tighten bolt to 48 N.m (35 ft. lbs.).
2. Install accessory drive belt (2). Refer to «BELT, SERPENTINE, INSTALLATION»(ref-612716-S36648552212014043000000) .
3. Install belt splash shield.
4. Lower vehicle.

ACCESSORY DRIVE BRACKET INSTALLATION - DIESEL ENGINE

1. If necessary, install the thermostat (2) to the accessory drive bracket (1).
2. Position the accessory drive bracket (1) to the engine.
3. Install the accessory drive bracket mounting bolts. Tighten the bolts to 9 N.m (80 in. lbs.).
4. Install the thermostat housing mounting bolts. Tighten the bolts to 9 N.m (80 in. lbs.).
5. Install the radiator hose (3) to the thermostat housing (2).
6. Install the coolant bypass hose to the thermostat housing (2).
7. Install the accessory drive belt tensioner. Refer to «TENSIONER, BELT, INSTALLATION»(ref-612716-S21520190062014043000000) .
8. Install the EGR cooler. Refer to «COOLER, EGR, INSTALLATION»(ref-612716-S26820380572014043000000) .
9. Install the generator. Refer to «GENERATOR, INSTALLATION»(ref-612723-S15110375682014043000000) .
10. Install the A/C compressor. Refer to «COMPRESSOR, A/C, INSTALLATION»(ref-612707-S19078228292014043000000) .
11. Install the A/C condenser. Refer to «CONDENSER, A/C, INSTALLATION»(ref-612707-S22313428592014043000000) .
12. Install the charge air cooler.
13. Install the coolant recovery bottle. Refer to «BOTTLE, COOLANT RECOVERY, INSTALLATION»(ref-612716-S10151046972014043000000) .
14. Install the water/power steering/vacuum pump assembly. Refer to «PUMP, WATER, INSTALLATION»(ref-612716-S10572020852014043000000) .
15. Install the negative battery cable.

1. Align draincock stem to radiator tank opening.
2. Push draincock (2) into the radiator tank opening.
3. Tighten the draincock (2) by turning clockwise until it stops.
4. Fill the cooling system. Refer to «STANDARD PROCEDURE»(ref-612716-S12637819952014043000000) .
5. Install front passenger side splash shield assembly to the wheelhouse area. Refer to «SHIELD, SPLASH, FRONT WHEELHOUSE, INSTALLATION»(ref-612710-S29185888482014043000000) N.
6. Install the front passenger side wheel. Refer to «INSTALLATION»(ref-612693-S31957631432014043000000) .

COOLING FAN - REMOVAL

Scheme 29

Scheme 30

Scheme 31

Scheme 32

1. Remove the air intake duct.
2. Disconnect negative cable from battery.
3. Drain the coolant just below the upper radiator hose.
4. Remove the upper radiator closure panel (2). Refer to «PANEL, CLOSURE, UPPER, REMOVAL»(ref-612710-S14614298932014043000000) .
5. Remove the hood latch cable.
6. Remove the upper core support seal push pins (3).
7. Remove radiator core support bolts (1).
8. Remove the upper radiator hose support bracket (2).
9. Remove the upper radiator hose from the radiator and position aside.
10. Remove the wiring harness from the fan shroud.
11. Disconnect radiator fan electrical connectors.
12. Remove radiator fan module (1) by lifting up from the engine compartment.
13. Remove the lower (8) shroud seal.
14. Remove the fan blade retaining nut (4) from the fan motor.
15. Remove the fan motor (5) assembly from the shroud.

DIESEL 2.2L - REMOVAL

Scheme 33

1. Remove the air intake duct.
2. Disconnect the negative battery cable.
3. Raise and support the vehicle. Refer to «HOISTING, STANDARD PROCEDURE»(ref-612692-S42044915732014043000000) .
4. Remove belly pan bolts.
5. Drain cooling system below upper radiator hose level.
6. Close off cooling system when the desired level is reached.
7. Install the belly pan.
8. Lower the vehicle.
9. Remove the upper radiator closure panel (2). Refer to «PANEL, CLOSURE, UPPER, REMOVAL»(ref-612710-S14614298932014043000000) .
10. Remove the hood latch cable.
11. Remove the power steering fluid reservoir (2) mounting bolt (1) and position aside.
12. Remove the upper core support seal push pins (3).
13. Remove radiator core support bolts (1).
14. Disconnect upper radiator hose from radiator.
15. Remove the wiring harness from the fan shroud.
16. Disconnect radiator fan wire harness connectors.
17. Remove radiator fan module (1) by lifting up from the engine compartment.
18. Remove the lower (8) shroud seal.
19. Remove the fan blade retaining nut (4) from the fan motor.
20. Remove the fan motor (5) assembly from the shroud.

COOLING FAN - INSTALLATION

1. Install the fan motor (5) onto shroud (3).
2. Install the fan (6) onto the motor.
3. Install the lower (8) shroud seal.
4. Install radiator fan module (1).
5. Connect the electrical connectors.
6. Install the wiring harness mounting retainers into fan shroud.
7. Install the upper radiator hose support bracket (2).
8. Install upper radiator hose to the radiator.
9. Install the upper radiator core support. Tighten outer bolts (1) to 23 N.m (17 ft. lbs.). Tighten the inner support bolts to 8 N.m (6 ft. lbs.).
10. Install the hood latch cable.
11. Install the core support seal (3).
12. Install radiator closure panel (2). Refer to «PANEL, CLOSURE, UPPER, INSTALLATION»(ref-612710-S28066290942014043000000) .
13. Connect the negative battery cable.
14. Fill the coolant to the proper level.
15. Run vehicle. Check for proper fan operation and coolant level.
16. Install the air intake duct.

DIESEL 2.2L - INSTALLATION

1. Install the fan motor (5) onto shroud (3).
2. Install the fan (6) onto the motor (5).
3. Install the lower shroud seal (8).
4. Install the radiator fan module (1).
5. Connect the radiator fan wire harness connectors.
6. Install upper radiator hose.
7. Install the wiring harness mounting retainers into fan shroud.
8. Install the upper radiator core support. Tighten outer bolts (1) to 23 N.m (17 ft. lbs.). Tighten the inner support bolts (1) to 8 N.m (6 ft. lbs.).
9. Install the hood latch cable.
10. Install the core support seal (3).
11. Install the power steering reservoir (2). Tighten bolt (1) to 12 N.m (9 in. lbs.).
12. Install radiator closure panel (2). Refer to «PANEL, CLOSURE, UPPER, INSTALLATION»(ref-612710-S28066290942014043000000) .
13. Top coolant off. Refer to «STANDARD PROCEDURE»(ref-612716-S12637819952014043000000) .

Scheme 34

The cartridge type block heater is mounted in a bore at the rear of the block under the coolant adapter. The block heater does not directly contact coolant. It heads the aluminum block.

The heater is powered by 110 Volt AC through a power cord and connector.

1. Thoroughly clean bore hole.
2. Insert block heater assembly into bore.
3. Install retaining clip.
4. Connect power cord to block heater.
5. Install air intake inlet.
6. Install engine cover.

Scheme 35

The water pump (3) on the world engine is attached to the water pump adapter on the front of the cylinder block.

The water pump is driven by the accessory drive belt. The water pump is connected to the water plenum by the return tube.

Turbocharger equipped engines use a smaller diameter water pump pulley then the naturally asperated engine. This allows increased coolant flow without pump cavation.

Scheme 36

The combination water/power steering pump (1) on this vehicle is attached to the lower corner of the cylinder block on the left hand side.

The water/power steering pump (1) cannot be disassembled or serviced separately.

The water/power steering pump (1) is driven by the accessory drive's serpentine belt.

Scheme 37

The water pump is turned on or off by vacuum. The Powertrain Control Module (PCM) actuates a switchover valve that turns vacuum supply to the water pump piston. A piston slides back and forth covering and uncovering a port used for coolant flow.

The controlling of the coolant flow helps manage temperature throughout the cooling system.

The water pump can be shut off if the following conditions exist

1. Engine speed is not achieved
2. The fuel injection quantity in not achieved
3. Intake air temperature is not reached
4. Coolant temperature is not reached
5. The A/C control unit does not request the heating mode

1. Inspect the O-ring for damage before installing the tube. Replace O-ring as necessary.
2. Lubricate O-rings with soapy water.
3. Install new water inlet gasket between tube and water pump housing (2).
4. Position water pump inlet tube (3) on water pump housing (2). Hand tighten nuts to aide in tube alignment.
5. Install secondary thermostat and coolant adapter. Refer to «THERMOSTAT, INSTALLATION»(ref-612716-S17147548682014043000000) .
6. Tighten coolant tube nuts (1) to 24 N.m (212 in. lbs.).
7. Fill cooling system. Refer to «STANDARD PROCEDURE»(ref-612716-S12637819952014043000000) .

Scheme 38

The automatic transmission cooler is located in the front of the radiator and behind the front fascia and is combined with the A/C condenser. The transmission cooler is a heat exchanger that allows heat in the transmission fluid to be transferred to the air passing over the cooler fins.

The Transmission oil cooler/A/C condenser assembly is equipped with quick connect fitting for the transmission oil cooler lines.

Scheme 39

1. On models equipped with A/C, refer to the A/C Condenser removal procedures. Refer to «CONDENSER, A/C, REMOVAL»(ref-612707-S42785509982014043000000) .
2. On non A/C equipped models, lift the vehicle and remove the lower closeout panel.
3. Using Tool (special tool #8875A, Disconnect, Transmission Cooler Line) disconnect the transmission cooler lines (1) from the transmission oil cooler (3). Refer to «TUBES AND HOSES, TRANSMISSION OIL COOLER, STANDARD PROCEDURE»(ref-612716-S11628711922014043000000) .
4. Remove the transmission oil cooler mounting bolts (2).
5. Remove the transmission oil cooler (3).

1. On models equipped with A/C, refer to the A/C Condenser installation procedure. Refer to «CONDENSER, A/C, INSTALLATION»(ref-612707-S22313428592014043000000) .
2. On non A/C equipped models, position the transmission oil cooler (3) to the radiator.
3. Install the transmission oil cooler mounting bolts (2). Tighten the bolts to 8 N.m (70 in. lbs.).
4. Connect the transmission cooler lines to the transmission oil cooler (1). Refer to «TUBES AND HOSES, TRANSMISSION OIL COOLER, STANDARD PROCEDURE»(ref-612716-S11628711922014043000000) .
5. Install the lower closeout panel.
6. Lower the vehicle.
7. Start engine and check transmission fluid level. Adjust level as necessary.

Scheme 40

1. Remove dust cap by pulling it straight back off of quick connect fitting
2. Place disconnect Special Tool (special tool #8875A, Disconnect, Transmission Cooler Line) onto a 3/8 inch transmission cooler lines or Special Tool (special tool #9546, Disconnect Tool) onto a 1/2 inch transmission cooler lines with the fingers of the tool facing the quick connect fitting.
3. Slide disconnect tool down the transmission line and engage the fingers of the tool into the retaining clip. When properly engaged in the clip, the tool will fit flush against the quick connect fitting.
4. Rotate the disconnect tool 60° to expand the retaining clip.
5. While holding the disconnect tool against the quick connect fitting, pull back on the transmission cooler line to remove.

Scheme 41

1. If removed, install the quick connect fitting into the transmission oil cooler or the transmission. Tighten the fitting to 15 N.m (132 in. lbs.).
2. Align the cooler line (3) with the quick connect fitting while pushing straight into the fitting.
3. Push in on the transmission cooler line until a click is heard or felt.
4. Slide the dust cap (4) down the transmission cooler line and snap it over the quick connect fitting until it is fully seated and rotates freely. The dust cap will only snap over the quick connect fitting when the transmission cooler line is properly installed.

Note. If the dust cap will not snap into place, repeat step 2.
