REMOVAL

Scheme 12

Note. LHD model shown in illustration, RHD model similar.

1. Disconnect and isolate the negative battery cable.
2. On RHD models, remove the two push-pins and silencer panel from the passenger side of the instrument panel.
3. On RHD models, remove the glove box bin. Refer to «GLOVE BOX, INSTRUMENT PANEL, REMOVAL»(ref-612710-S04054333942014043000000) .
4. Disconnect the wire harness connector (1) from the blend door actuator (2) located on the left side of the HVAC air distribution housing (3).
5. Remove the two screws (4) that secure the blend door actuator to the air distribution housing and remove the actuator.

INSTALLATION

Note. LHD model shown in illustration, RHD model similar.

1. Position the blend door actuator (2) onto the left side of the HVAC air distribution housing (3). If necessary, rotate the actuator slightly to align the splines on the actuator output shaft with those in the blend air door linkage.
2. Install the two screws (4) that secure the blend door actuator to the air distribution housing. Tighten the screws to 2 N.m (17 in. lbs.).
3. Connect the wire harness connector (1) to the blend door actuator.
4. On RHD models, install the glove box bin. Refer to «GLOVE BOX, INSTRUMENT PANEL, INSTALLATION»(ref-612710-S23902858502014043000000) .
5. On RHD models, install the silencer panel and two push-pins.
6. Reconnect the negative battery cable.
7. Initiate the Actuator Calibration function using a scan tool. Refer to «STANDARD PROCEDURE»(ref-612755-S02530953942014043000000) .

Scheme 13

Note. LHD model shown in illustration, RHD model similar.

1. Disconnect and isolate the negative battery cable.
2. On LHD models, remove the two push-pins and silencer panel from the passenger side of the instrument panel.
3. On LHD models, remove the glove box bin. Refer to «GLOVE BOX, INSTRUMENT PANEL, REMOVAL»(ref-612710-S04054333942014043000000) .
4. Remove the floor distribution duct from the right side of the HVAC air distribution housing. Refer to «DUCT, FLOOR DISTRIBUTION, REMOVAL»(ref-612707-S16887996712014043000000) .
5. Remove the three screws (1) that secure the mode door actuator (2) to the bracket (4) located on the right side of the air distribution housing.
6. Disconnect the wire harness connector (3) from the mode door actuator and remove the actuator.

Note. LHD model shown in illustration, RHD model similar.

1. Position the mode door actuator (2) onto the bracket (4) located on the right side of the HVAC air distribution housing. If necessary, rotate the actuator slightly to align the splines on the actuator output shaft with those in the mode air door linkage.
2. Install the three screws (1) that secure the mode door actuator to the air distribution housing. Tighten the screws to 2 N.m (17 in. lbs.).
3. Connect the wire harness connector (3) to the mode door actuator.
4. Install the floor distribution duct onto the right side of the air distribution housing. Refer to «DUCT, FLOOR DISTRIBUTION, INSTALLATION»(ref-612707-S39352375902014043000000) .
5. On LHD models, install the glove box bin. Refer to «GLOVE BOX, INSTRUMENT PANEL, INSTALLATION»(ref-612710-S23902858502014043000000) .
6. On LHD models, install the silencer panel and two push-pins.
7. Reconnect the negative battery cable.
8. Initiate the Actuator Calibration function using a scan tool. Refer to «STANDARD PROCEDURE»(ref-612755-S02530953942014043000000) .

Note. Illustration shown with instrument panel removed for clarity.

Note. LHD model shown in illustration, RHD model similar.

Scheme 14

1. Disconnect and isolate the negative battery cable.
2. Remove the two push-pins and silencer panel from the passenger side of the instrument panel.
3. Remove the glove box bin. Refer to «GLOVE BOX, INSTRUMENT PANEL, REMOVAL»(ref-612710-S04054333942014043000000) .
4. Remove the two screws (1) that secure the recirculation door actuator (2) to the HVAC air inlet housing (3).
5. Disconnect the wire harness connector (4) from the recirculation door actuator and remove the actuator.

Note. Illustrations shown with instrument panel removed for clarity.

Note. LHD model shown in illustrations, RHD model similar.

Scheme 15

1. Install the recirculation door actuator (1) onto the HVAC air inlet housing (2). If necessary, rotate the actuator slightly to align the splines on the actuator output shaft (3) with those on the recirculation door pivot shaft adapter (4).
2. Install the screws (1) that secure the recirculation door actuator (2) to the air inlet housing (3). Tighten the screws to 2 N.m (17 in. lbs.).
3. Connect the wire harness connector (4) to the recirculation door actuator.
4. Install the glove box bin. Refer to «GLOVE BOX, INSTRUMENT PANEL, INSTALLATION»(ref-612710-S23902858502014043000000) .
5. Install the silencer panel and two push-pins.
6. Reconnect the negative battery cable.

Scheme 16

The Automatic Temperature Control (ATC) single zone heating-A/C system uses electrically operated controls. These controls provide the vehicle operator with a number of setting options to help control the climate and comfort within the vehicle.

The A/C-heater control (1) for the ATC single zone system automatically maintains the interior comfort level desired by the vehicle operator. The ATC system uses an infrared sensor located in the front overhead console to measure the surface temperature of the driver and front seat passengers. Based on the sensor input, the ATC system automatically adjusts air temperature, airflow volume, airflow distribution and amount of inside air recirculation to maintain occupant comfort, even under changing outside weather conditions. All controls are identified by International Standardization Organization (ISO) graphic symbols.

This ATC system offers several manual override features such as fan speed and airflow distribution. When the outside air contains smoke, odors, high humidity, or if rapid cooling is desired, the interior conditioned air can be recirculated within the vehicle.

The ATC A/C-heater control and integral computer is located in the instrument panel and contains

1. a rotary control for manual and automatic blower motor speed selection and for turning the heating-A/C system on and off (2). This control also contains a push button function for recirculating the conditioned air. The control contains an indicator lamp that illuminates when the heating-A/C system is in recirculation mode.
2. a rotary control for temperature control of the discharged air (3). This control also contains a push button function for manually turning the A/C system on and off. The control contains an indicator lamp that illuminates when the A/C system is in operation.
3. a rotary control for manual and automatic mode control of the discharged air (4). This control also contains a push button function for turning the rear window defogger system on and off. The control contains an indicator lamp that illuminates when the rear window defogger system is in operation.

The ATC A/C-heater control obtains vehicle speed, engine speed, engine coolant temperature, ambient temperature and refrigerant system head pressure data and is diagnosed using a scan tool. Refer to DIAGNOSIS AND TESTING .

Prior to replacing the A/C-heater control, check for any Diagnostic Trouble Codes (DTCs) related to the heating-A/C system and run the Actuator Calibration function using a scan tool to verify that the concern is not an air door calibration issue. Refer to STANDARD PROCEDURE .

The A/C-heater control cannot be adjusted or repaired and must be replaced if inoperative or damaged.

Scheme 17

The Manual Temperature Control (MTC) single zone heating-A/C system uses electrically operated controls. These controls provide the vehicle operator with a number of setting options to help control the climate and comfort within the vehicle.

The A/C-heater control (1) for the MTC single zone system allows one temperature setting for the entire vehicle. All controls are identified by International Standardization Organization (ISO) graphic symbols.

The MTC A/C-heater control and integral computer is located in the instrument panel and contains

1. a rotary control for fan speed selection and for turning the heating-A/C system on and off (2). This control also contains a push button function for recirculating the conditioned air. The control contains an indicator lamp that illuminates when the heating-A/C system is in recirculation mode.
2. a rotary control for temperature control of the discharged air (3). This control also contains a push button function for turning the A/C system on and off. The control contains an indicator lamp that illuminates when the A/C system is in operation.
3. a rotary control for mode control of the discharged air (4). This control also contains a push button function for turning the rear window defogger system on and off. The control contains an indicator lamp that illuminates when the rear window defogger system is in operation.

The MTC A/C-heater control is diagnosed using a scan tool. Refer to DIAGNOSIS AND TESTING .

Prior to replacing the A/C-heater control, check for any Diagnostic Trouble Codes (DTCs) related to the heating-A/C system and run the Actuator Calibration function using a scan tool to verify that the concern is not an air door calibration issue. Refer to STANDARD PROCEDURE .

The A/C-heater control cannot be adjusted or repaired and must be replaced if inoperative or damaged.

Note. Take the proper precautions to protect the front face of the center bezel from cosmetic damage while performing this procedure.

Scheme 18

Note. MTC A/C-heater control shown in illustration, ATC A/C-heater control similar.

1. Disconnect and isolate the negative battery cable.
2. Remove the instrument panel center bezel (3) and place it on a workbench. Refer to «BEZEL, INSTRUMENT PANEL, CENTER, REMOVAL»(ref-612710-S26057508262014043000000) .
3. Remove the four screws (1 and 4) that secure the A/C-heater control (2) to the back of the center bezel and remove the control.

Note. Take the proper precautions to protect the front face of the center bezel from cosmetic damage while performing this procedure.

Note. MTC A/C-heater control shown in illustration, ATC A/C-heater control similar.

1. Position the A/C-heater control (2) onto the back of the center bezel (3).
2. Install the four screws (1 and 4) that secure the A/C-heater control to the bezel. Tighten the screws to 2 N.m (17 in. lbs.).
3. Install the center bezel. Refer to «BEZEL, INSTRUMENT PANEL, CENTER, INSTALLATION»(ref-612710-S32150445952014043000000) .
4. Reconnect the negative battery cable. NOTE: When installing a new A/C-heater control, or reinstalling the original control, the A/C-heater control will automatically run the Actuator Calibration function when the ignition switch is initially turned to ON. However, the Actuator Calibration function must be manually initiated using a scan tool if the A/C-heater control was previously installed in another vehicle.
5. If required, initiate the Actuator Calibration function using a scan tool. Refer to «STANDARD PROCEDURE»(ref-612755-S02530953942014043000000) .

Note. ATC blower motor power module shown in illustration, MTC power module similar.

Scheme 19

1. Disconnect and isolate the negative battery cable.
2. If equipped, remove the two push-pins and silencer panel from the passenger side of the instrument panel.
3. Disconnect the wire harness connector (1) from the blower motor power module (2).
4. Remove the two screws (4) that secure the blower motor power module to the HVAC housing (3) and remove the power module.

Note. ATC blower motor power module shown in illustration, MTC power module similar.

1. Position the blower motor power module (2) into the HVAC housing (3).
2. Install the two screws (4) that secure the blower motor power module to the HVAC housing. Tighten the screws to 1.2 N.m (10 in. lbs.).
3. Connect the wire harness connector (1) to the blower motor power module.
4. If equipped, install the passenger side silencer panel and two push-pins.
5. Reconnect the negative battery cable.

Scheme 20

The ambient air temperature sensor is a variable resistor that monitors the air temperature outside of the vehicle. The ATC system uses the sensor data to maintain optimum passenger compartment temperature levels. The ambient air temperature sensor is mounted to the front bumper beam.

Scheme 21

Note. Illustration shown with air distribution housing removed for clarity.

Note. It is not necessary to remove and disassemble the HVAC housing to service the evaporator temperature sensor. The evaporator temperature sensor can be removed for service from underneath the instrument panel.

1. Disconnect and isolate the negative battery cable.
2. Reach up under the driver side of the instrument panel and disconnect the electrical connector for the evaporator temperature sensor (1) from the instrument panel wire harness.
3. Remove the evaporator temperature sensor electrical connector from the side of the HVAC housing (2).
4. Using needle nose pliers, carefully pull the evaporator temperature sensor straight out of the side of the HVAC housing.
5. Route the electrical connector and wire lead of the evaporator temperature sensor out from under the heater core tubes and remove the sensor from the vehicle.

Note. Illustration shown with air distribution housing removed for clarity.

1. Route the electrical connector and wire lead of the evaporator temperature sensor (1) under the heater core tubes located on the driver side of the HVAC housing (2).
2. Install the evaporator temperature sensor into the driver side of the HVAC housing. Make sure the retaining tabs (3) are fully engaged to the housing.
3. Connect the electrical connector for the evaporator temperature sensor to the instrument panel wire harness.
4. Reconnect the negative battery cable.

Scheme 22

Note. Typical infrared temperature sensor shown in illustration.

The infrared temperature sensor consists of an infrared transducer concealed behind a clear lens (2) located in a molded plastic housing with an integral wire connector receptacle (1) and a mounting tab (3).

The infrared sensor is used only on models equipped with the Automatic Temperature Control (ATC) heating-A/C system.

Note. Take the proper precautions to protect the front face of the overhead console from cosmetic damage while performing this procedure.

Scheme 23

1. Disconnect and isolate the negative battery cable.
2. Remove the overhead console (4) from the headliner and place it on a workbench.
3. Remove the screw (1) that secures the infrared sensor (3) to the back of the overhead console.
4. Disengage the infrared sensor from the retaining tabs (2) on the overhead console and remove the sensor.

Note. Take the proper precautions to protect the front face of the overhead console from cosmetic damage while performing this procedure.

1. Position the infrared sensor (3) onto the back of the overhead console (4). Align the slot on the sensor with the retaining tabs (2) on the console.
2. Install the screw (1) that secures the infrared sensor to the overhead console. Tighten the screw to 1.2 N.m (10 in. lbs).
3. Install the overhead console. Make sure the retaining tabs are fully engaged to the headliner.
4. Reconnect the negative battery cable.

Scheme 24

The A/C pressure transducer (1) is a switch that is installed on a fitting located on the A/C discharge line. An internally threaded fitting on the A/C pressure transducer connects it to the externally threaded Schrader-type fitting on the A/C discharge line. A rubber O-ring seals the connection between the A/C pressure transducer and the discharge line fitting. The A/C pressure transducer is connected to the vehicle electrical system by a molded plastic connector with three terminals.

Note. It is not necessary to discharge the refrigerant system to replace the A/C pressure transducer.

Scheme 25

Note. Typical A/C pressure transducer shown in illustration.

1. Disconnect and isolate the negative battery cable.
2. Carefully pull the top of the fascia forward to gain access to the A/C pressure transducer (2). Refer to «FASCIA, FRONT, REMOVAL»(ref-612698-S03953696392014043000000) .
3. Reach down through the opening between the A/C condenser and the front fascia and disconnect the wire harness connector (1) from the A/C pressure transducer located on the A/C discharge line (3).
4. Remove the A/C pressure transducer from the A/C discharge line and remove and discard the O-ring seal (4).

Note. Use only the specified O-ring as it is made of special material for R-134a. Use only refrigerant oil of the type required for the A/C compressor.

Note. Typical A/C pressure transducer shown in illustration.

1. Lubricate a new rubber O-ring seal (4) with clean refrigerant oil and install it onto the A/C discharge line (3).
2. Install the A/C pressure transducer (2) onto the A/C discharge line. Tighten the A/C pressure transducer securely.
3. Connect the wire harness connector (1) to the A/C pressure transducer.
4. Reinstall the top of the front fascia. Refer to «FASCIA, FRONT, INSTALLATION»(ref-612698-S00050582162014043000000) .
5. Reconnect the negative battery cable.

Note. Illustration shown with instrument panel removed from vehicle for clarity.

Note. LHD model shown in illustration, RHD model similar.

Scheme 26

1. Remove the upper and lower instrument panel cover. Refer to «COVER, INSTRUMENT PANEL, REMOVAL»(ref-612710-S21083385452014043000000) .
2. Disconnect the left and right demister hoses (1 and 3) from the defroster duct (2) and position the hoses out of the way.
3. Remove the defroster duct from the top of the instrument panel (4).

Note. Illustration shown with instrument panel removed from vehicle for clarity.

Note. LHD model shown in illustration, RHD model similar.

1. Position the defroster duct (2) into the top of the instrument panel (4).
2. Connect the left and right demister hoses (1 and 3) to the defroster duct.
3. Install the lower and upper instrument panel covers. Refer to «COVER, INSTRUMENT PANEL, INSTALLATION»(ref-612710-S22516109322014043000000) .

Note. LHD model shown in illustrations, RHD model similar.

Scheme 27

Note. Illustration shown with instrument panel removed for clarity.

1. On LHD models, remove the glove box bin. Refer to «GLOVE BOX, INSTRUMENT PANEL, REMOVAL»(ref-612710-S04054333942014043000000) .
2. Disconnect the right floor duct (1) from the right side of the HVAC housing (2) and remove the duct.

Scheme 28

Note. Illustration shown with instrument panel removed for clarity.

1. On RHD models, remove the glove box bin. Refer to «GLOVE BOX, INSTRUMENT PANEL, REMOVAL»(ref-612710-S04054333942014043000000) .
2. On LHD models, disconnect the shift interlock cable (3) from the left floor duct (1) and position the cable out of the way.
3. Remove the screw (4) that secures the left floor duct to the left side of the HVAC housing (2).
4. Disconnect the left floor duct from the HVAC housing and remove the duct.

Scheme 29

1. Remove the instrument panel. Refer to «PANEL, INSTRUMENT, REMOVAL»(ref-612710-S09852678672014043000000) .
2. Remove the rear seat floor ducts.
3. Disconnect the left rear floor distribution duct (1) and the right rear floor distribution duct (2) as required from the HVAC housing (3) and remove the duct(s).

Scheme 30

Note. Right side rear floor duct shown in illustration, Left side duct similar.

1. Remove the center floor console. Refer to «HOUSING, SHIFTER, REMOVAL»(ref-612710-S25259757692014043000000) .
2. Remove the front seat from the side of the vehicle being serviced. Refer to «SEAT, FRONT, REMOVAL»(ref-612710-S18188687162014043000000) .
3. Pull the carpet back to gain access to the rear seat floor duct (2). Refer to «CARPET, PASSENGER, REMOVAL»(ref-612710-S29347877022014043000000) .
4. Remove the screw (1) and disengage the retainer that secures the rear seat floor duct to the floor support (4).
5. Disconnect the rear seat floor duct from the rear floor distribution duct (3) and remove the rear seat duct(s).

Note. LHD model shown in illustrations, RHD model similar.

Note. LHD model shown in illustrations, RHD model similar.

Note. The driver side instrument panel duct is serviced only as an assembly with the inner driver side demister duct.

Scheme 31

Scheme 32

1. Remove the upper and lower instrument panel covers. Refer to «COVER, INSTRUMENT PANEL, REMOVAL»(ref-612710-S21083385452014043000000) .
2. Remove the four screws (2 and 7) that secure the driver side demister duct (3) and the instrument panel duct (6) to the instrument panel support.
3. Disconnect the driver side demister hose (4) from the demister duct.
4. Disconnect the driver side instrument panel duct from the passenger side instrument panel duct (5).
5. Remove the instrument panel and demister duct assembly from the instrument panel support.
6. If required, disconnect the outer demister duct (1) from the driver side demister duct.
7. Remove the screw (1) that secures the passenger side instrument panel duct (2) to the instrument panel support.
8. Remove the passenger side instrument panel duct from the instrument panel support.

Note. LHD model shown in illustrations, RHD model similar.

Note. The driver side instrument panel duct is serviced only as an assembly with the inner driver side demister duct.

1. Position the passenger side instrument panel duct (2) onto the top of the instrument panel support.
2. Install the screw (1) that secures the passenger side instrument panel duct to the instrument panel support. Tighten the screw to 2.2 N.m (20 in. lbs.).
3. If removed, connect the outer demister duct (1) to the driver side demister duct (3).
4. Position the driver side instrument panel duct (6) and demister duct to the instrument panel support and connect the driver side instrument panel duct to the passenger side instrument panel duct (5). Make sure the ducts are fully engaged to each other.
5. Connect the demister hose (4) to the driver side demister duct. Make sure the hose is fully engaged to the duct.
6. Install the four screws (2 and 7) that secure driver side instrument panel duct and demister duct to the instrument panel support. Tighten the screws to 2.2 N.m (20 in. lbs.).
7. Install the lower and upper instrument panel covers. Refer to «COVER, INSTRUMENT PANEL, INSTALLATION»(ref-612710-S22516109322014043000000) .

Note. LHD model shown in illustrations, RHD model similar.

Note. LHD model shown in illustrations, RHD model similar.

Note. LHD model shown in illustrations, RHD model similar.

Scheme 33

Note. Illustration shown with instrument panel removed for clarity.

Scheme 34

1. Remove the glove box bin. Refer to «GLOVE BOX, INSTRUMENT PANEL, REMOVAL»(ref-612710-S04054333942014043000000) .
2. Disengage the two retaining tabs (1) that secure the cabin air filter cover (2) to the passenger side of the HVAC housing (3) and remove the cover.
3. Remove the cabin air filter (1) from the HVAC housing (2) by pulling the filter element straight out of the housing.

Note. The cabin air filter is labeled with an arrow to indicate air flow direction through the filter. Make sure to properly install the cabin air filter. Failure to properly install the filter will result in the need to replace the filter sooner than required by design.

Note. LHD model shown in illustrations, RHD model similar.

Scheme 35

1. Install the cabin air filter (1) into the filter opening in the HVAC housing (2). Insert the cabin air filter directly into the housing with the arrow on the filter pointing to the floor.
2. Position the cabin air filter cover (2) to the HVAC housing (3) and engage the two retaining tabs (1) that secure the cover to the housing. Make sure the retaining tabs are fully engaged.
3. Install the glove box bin. Refer to «GLOVE BOX, INSTRUMENT PANEL, INSTALLATION»(ref-612710-S23902858502014043000000) .

Note. The blower motor is located on the bottom of the passenger side of the HVAC housing. The blower motor can be removed from the vehicle without having to remove the HVAC housing.

Scheme 36

Note. LHD model shown in illustration, RHD model similar.

1. Disconnect and isolate the negative battery cable.
2. If equipped, remove the silencer from below the passenger side of the instrument panel.
3. From underneath the instrument panel, disengage the connector lock and disconnect the instrument panel wire harness connector (1) from the blower motor (2).
4. Remove the three screws (3) that secure the blower motor and the wire lead bracket (4) (if equipped) to the bottom of the HVAC housing (5) and remove the blower motor.

Note. LHD model shown in illustration, RHD model similar.

1. Position the blower motor (2) into the bottom of the HVAC housing (5).
2. Install the three screws (3) that secure the blower motor and the wire lead bracket (4) (if equipped) to the HVAC housing. Tighten the screws to 1.2 N.m (10 in. lbs.).
3. Connect the instrument panel wire harness connector (1) to the blower motor and engage the connector lock.
4. If equipped, install the silencer below the passenger side of the instrument panel.
5. Reconnect the negative battery cable.

Note. Driver side air outlet shown in illustration, Other outlets similar.

Scheme 37

1. Depending on the air outlet being serviced, remove the instrument panel center bezel or the upper instrument panel cover. Refer to «BEZEL, INSTRUMENT PANEL, CENTER, REMOVAL»(ref-612710-S26057508262014043000000) or «COVER, INSTRUMENT PANEL, REMOVAL»(ref-612710-S21083385452014043000000) . NOTE: If the foam seal on the air outlet is deformed or damaged, it must be replaced.
2. Remove the three screws (1) that secure the air outlet (2) to the bezel or cover (3) and remove the outlet.

Note. Driver side air outlet shown in illustration, Other outlets similar.

Note. If the foam seal on the air outlet is deformed or damaged, it must be replaced.

1. Position the air outlet (2) onto the bezel or cover (3).
2. Install the three screws (1) that secure the air outlet. Tighten the screws to 2 N.m (17 in. lbs.).
3. Depending on the outlet being serviced, install the upper instrument panel cover or the instrument panel center bezel. Refer to «COVER, INSTRUMENT PANEL, INSTALLATION»(ref-612710-S22516109322014043000000) or «BEZEL, INSTRUMENT PANEL, CENTER, INSTALLATION»(ref-612710-S32150445952014043000000) .

Scheme 38

Scheme 39

Scheme 40

1. Disconnect and isolate the negative battery cable.
2. Recover the refrigerant from the refrigerant system. Refer to «PLUMBING, STANDARD PROCEDURE»(ref-612707-S15586852732014043000000) .
3. If equipped with the 2.2L diesel engine, remove the front fascia. Refer to «FASCIA, FRONT, REMOVAL»(ref-612698-S03953696392014043000000) .
4. If equipped with a gasoline engine, remove the upper radiator support and position it out of the way. Refer to «PANEL, CLOSURE, UPPER, REMOVAL»(ref-612710-S14614298932014043000000) .
5. On gasoline engine equipped models, carefully push the radiator (1) slightly rearward to gain access to the A/C condenser (2).
6. Remove the nut (3) that secures the A/C discharge line (4) to the right side of the A/C condenser and remove and discard the O-ring seal and gasket.
7. Install plugs in, or tape over the opened discharge line fitting and the condenser inlet port. NOTE: Illustration shown with front fascia removed for clarity.
8. Raise and support the vehicle. NOTE: On gasoline engine equipped models, reach up through the opening in the bottom of the front fascia located in the right front corner of the vehicle to gain access to the A/C liquid line.
9. Remove the nut (1) that secures the A/C liquid line (2) to the right side of the A/C condenser (3).
10. Disconnect the A/C liquid line from the A/C condenser and remove and discard the O-ring seal and gasket.
11. Install plugs in, or tape over the opened liquid line fitting and the condenser outlet port. NOTE: A/C condenser for late model year gasoline engine with automatic transaxle shown in illustration, Other models similar. NOTE: Illustration shown with front fascia and diesel engine charge air cooler (CAC) (when equipped) removed for clarity.
12. Remove the two bolts (3) that secure the lower condenser brackets to the radiator (5).
13. Lower the vehicle.
14. If equipped, disconnect the automatic transmission cooler lines (2) from the left side of the A/C condenser (1). Refer to «TUBES AND HOSES, TRANSMISSION OIL COOLER, STANDARD PROCEDURE»(ref-612716-S11628711922014043000000) .
15. If equipped with the 2.2L diesel engine, remove the charge air cooler (CAC).
16. Carefully lift the A/C condenser straight up and disengage the two upper condenser brackets (4) from the radiator and remove the condenser from the engine compartment.

Note. If the A/C condenser is being replaced, add 10 milliliters (0.3 fluid ounce) of refrigerant oil to the refrigerant system. If the A/C condenser is equipped with an A/C receiver/drier, be sure to add an addition 30 milliliters (1.0 fluid ounce) of refrigerant oil. When replacing multiple A/C system components, see the REFRIGERANT OIL CAPACITIES chart to determine how much oil should be added to the refrigerant system. Refer to OIL, REFRIGERANT, STANDARD PROCEDURE . Use only refrigerant oil of the type recommended for the A/C compressor in the vehicle.

Note. Replacement of the refrigerant line O-ring seals and gaskets is required anytime a refrigerant line is disconnected. Failure to replace the rubber O-ring seals and metal gaskets could result in a refrigerant system leak.

Note. A/C condenser for late model year gasoline engine with automatic transaxle shown in illustration, Other models similar.

Note. Illustration shown with front fascia and diesel engine charge air cooler (CAC) (when equipped) removed for clarity.

1. Carefully lower the A/C condenser (1) straight down in front of the radiator (5) and engage the upper condenser brackets (4) to the radiator.
2. If equipped with the 2.2L diesel engine, install the charge air cooler (CAC).
3. If equipped, connect the automatic transmission cooler lines (2) to the left side of the A/C condenser. Refer to «TUBES AND HOSES, TRANSMISSION OIL COOLER, STANDARD PROCEDURE»(ref-612716-S11628711922014043000000) .
4. Raise and support the vehicle.
5. Install the two bolts (3) that secure the lower condenser brackets to the radiator. Tighten the bolts to 4.5 N.m (40 in. lbs.). NOTE: Illustration shown with front fascia removed for clarity. NOTE: On gasoline engine equipped models, reach up through the opening in the bottom of the front fascia located in the right front corner of the vehicle to gain access to the A/C liquid line.
6. Remove the tape or plug from the liquid line fitting and the condenser outlet port.
7. Lubricate a new rubber O-ring seal with clean refrigerant oil and install it and a new gasket onto the liquid line fitting. Use only the specified O-ring as it is made of a special material for the R-134a system. Use only refrigerant oil of the type recommended for the A/C compressor in the vehicle.
8. Connect the A/C liquid line (2) to the A/C condenser (3) and install the retaining nut (1). Tighten the nut to 5 N.m (44 in. lbs.).
9. Lower the vehicle.
10. Remove the tape or plug from the discharge line fitting and the condenser inlet port.
11. Lubricate a new rubber O-ring seal with clean refrigerant oil and install it and a new gasket onto the discharge line fitting. Use only the specified O-ring as it is made of a special material for the R-134a system. Use only refrigerant oil of the type recommended for the A/C compressor in the vehicle.
12. On gasoline engine equipped models, carefully push the radiator (1) slightly rearward to gain access to the A/C condenser (2).
13. Connect the A/C discharge line (4) to the A/C condenser and install the retaining nut (3). Tighten the nut to 5 N.m (44 in. lbs.).
14. If equipped with a gasoline engine, reposition and install the upper radiator support. Refer to «PANEL, CLOSURE, UPPER, INSTALLATION»(ref-612710-S28066290942014043000000) .
15. If equipped with the 2.2L diesel engine, install the front fascia. Refer to «FASCIA, FRONT, INSTALLATION»(ref-612698-S00050582162014043000000) .
16. Reconnect the negative battery cable. CAUTION: Do NOT run the engine with a vacuum pump in operation or with a vacuum present within the A/C system. Failure to follow this caution will result in serious A/C compressor damage.
17. Evacuate the refrigerant system Refer to «PLUMBING, STANDARD PROCEDURE»(ref-612707-S15586852732014043000000) .
18. If the A/C condenser is being replaced, add 10 milliliters (0.3 fluid ounce) of refrigerant oil to the refrigerant system. If the A/C condenser is equipped with an A/C receiver/drier, be sure to add an addition 30 milliliters (1.0 fluid ounce) of refrigerant oil. When replacing multiple A/C system components, see the «REFRIGERANT OIL CAPACITIES»(ref-612707-S23794342422014043000000) chart to determine how much oil should be added to the refrigerant system. Refer to «OIL, REFRIGERANT, STANDARD PROCEDURE»(ref-612707-S11458285262014043000000) . Use only refrigerant oil of the type recommended for the A/C compressor in the vehicle.
19. Charge the refrigerant system. Refer to «PLUMBING, STANDARD PROCEDURE»(ref-612707-S15586852732014043000000) .

Note. The HVAC housing assembly must be removed from vehicle for service of the heater core.

Note. LHD model with A/C shown in illustration, RHD and heater-only models similar.

Scheme 41

1. Remove the HVAC housing assembly and place it on a workbench. Refer to «HOUSING, HVAC, REMOVAL»(ref-612707-S11526054142014043000000) .
2. Remove the left side front floor duct. Refer to «DUCT, FLOOR DISTRIBUTION, REMOVAL»(ref-612707-S16887996712014043000000) . NOTE: If the foam seal for the flange is deformed or damaged, it must be replaced.
3. Remove the foam seal (1) from the flange (2) located on the front of the HVAC housing (5).
4. Remove the screw (6) that secures the flange to the front of the HVAC housing and remove the flange.
5. On RHD models, remove the air distribution housing from the HVAC housing Refer to «HOUSING, HVAC, REMOVAL»(ref-612707-S11526054142014043000000) .
6. Carefully pull the heater core (4) out of the driver side of the air distribution housing (3).

Note. LHD model with A/C shown in illustration, RHD and heater-only models similar.

1. Carefully install the heater core (4) into the side of the air distribution housing (3).
2. On RHD models, install the air distribution housing onto the HVAC housing (5). Refer to «HOUSING, HVAC, INSTALLATION»(ref-612707-S06054315202014043000000) .
3. Install the flange (2) that secures the heater core tubes to the front of the HVAC housing.
4. Install the screw (6) that secures the flange to the HVAC housing. Tighten the screw to 1.2 N.m (10 in. lbs.). NOTE: If the foam seal for the flange is deformed or damaged, it must be replaced.
5. Install the foam seal (1) onto the flange.
6. Install the left side front floor duct. Refer to «DUCT, FLOOR DISTRIBUTION, INSTALLATION»(ref-612707-S39352375902014043000000) . NOTE: If the heater core is being replaced, flush the cooling system. Refer to «STANDARD PROCEDURE»(ref-612716-S12637819952014043000000) .
7. Install the HVAC housing assembly. Refer to «HOUSING, HVAC, INSTALLATION»(ref-612707-S06054315202014043000000) .

Scheme 42

Refrigerant system service ports are used to recover, recycle, evacuate, charge and test the A/C refrigerant system. Unique sizes are used on the two service ports for the R-134a refrigerant system to ensure the system is not accidentally contaminated with R-12 refrigerant or by service equipment used for R-12 refrigerant.

The high side service port (1) is located on the A/C discharge line (2) in front of the engine, below the upper radiator hose (3).

Scheme 43

The low side service port (1) is located on the A/C liquid line (2) near the right front strut tower (3). Both the high side and low side A/C service port valve cores are serviceable.

Note. The protective cap aids in service port sealing and helps protect the refrigerant system from contamination. Remember to always reinstall the protective cap onto the service port when refrigerant system service is complete.

Each of the service ports has a threaded plastic protective cap installed over it from the factory. The service port caps are serviceable components.

Scheme 44

Note. Typical A/C service port shown in illustration.

1. Remove the protective cap (1) from the service port (2).
2. Recover the refrigerant from the refrigerant system. Refer to «PLUMBING, STANDARD PROCEDURE»(ref-612707-S15586852732014043000000) .
3. Using a Schrader-type valve core tool, remove the valve core (3) from the service port.
4. Install a plug in, or tape over the opened service port(s).

Note. Typical A/C service port shown in illustration.

1. Lubricate the valve core (3) with clean refrigerant oil prior to installation. Use only refrigerant oil of the type recommended for the A/C compressor in the vehicle.
2. Remove the tape or plug from the service port (2). CAUTION: A valve core that is not fully seated in the A/C service port can result in damage to the valve during refrigerant system evacuation and charge. Such damage may result in a loss of system refrigerant while uncoupling the charge adapters.
3. Using a Schrader-type valve core tool, install and tighten the valve core into the service port(s). CAUTION: Do NOT run the engine with a vacuum pump in operation or with a vacuum present within the A/C system. Failure to follow this caution will result in serious A/C compressor damage.
4. Evacuate the refrigerant system. Refer to «PLUMBING, STANDARD PROCEDURE»(ref-612707-S15586852732014043000000) .
5. Charge the refrigerant system. Refer to «PLUMBING, STANDARD PROCEDURE»(ref-612707-S15586852732014043000000) . NOTE: The protective cap helps aid in service port sealing and helps protect the refrigerant system from contamination. Remember to always reinstall the protective cap onto the service port when refrigerant system service is complete.
6. Install the protective cap (1) onto the service port.

Note. LHD model shown in illustration, RHD model similar.

Scheme 45

1. Disconnect and isolate the negative battery cable.
2. Recover the refrigerant from the refrigerant system. Refer to «PLUMBING, STANDARD PROCEDURE»(ref-612707-S15586852732014043000000) .
3. Raise and support the vehicle.
4. Remove the right front wheel. Refer to «REMOVAL»(ref-612693-S04478050232014043000000) .
5. Position the front portion of the right front wheelhouse splash shield out of the way. Refer to «SHIELD, SPLASH, FRONT WHEELHOUSE, REMOVAL»(ref-612710-S08980961332014043000000) .
6. Remove the nut (2) that secures the A/C refrigerant line (1) to the A/C receiver/drier (5).
7. Disconnect the A/C liquid line from the A/C receiver/drier and remove and discard the O-ring seal and gasket.
8. Remove the bolt (3) that secures the liquid jumper line (4) to the A/C receiver/drier.
9. Disconnect the jumper line from the A/C receiver/drier and remove and discard the O-ring seal and gasket.
10. Remove the A/C suction line from the plastic bracket located on the A/C receiver/drier.
11. Remove the two bolts (6) that secure the A/C receiver/drier to the right front frame rail (7) and remove the receiver/drier.
12. Install plugs in, or tape over the opened refrigerant line fittings and receiver/drier ports.

Note. If only the A/C receiver/drier is being replaced, add 30 milliliters (1 fluid ounce) of refrigerant oil to the refrigerant system. Use only refrigerant oil of the type recommended for the A/C compressor in the vehicle.

Note. When replacing multiple A/C system components, see the REFRIGERANT OIL CAPACITIES chart to determine how much oil should be added to the refrigerant system. Refer to OIL, REFRIGERANT, STANDARD PROCEDURE .

Note. Replacement of the refrigerant line O-ring seals and gaskets is required anytime a refrigerant line is disconnected. Failure to replace the rubber O-ring seals and metal gaskets could result in a refrigerant system leak.

Note. LHD model shown in illustration, RHD model similar.

1. Position the A/C receiver/drier (5) to the right front frame rail (7) and install the retaining bolts (6). Tighten the bolts to 15 N.m (11 ft. lbs.).
2. Install the A/C suction line into the plastic bracket on the A/C receiver/drier.
3. Remove the tape or plugs from the refrigerant line fittings and the receiver/drier ports.
4. Lubricate new O-ring seals and gaskets with clean refrigerant oil and install them onto the refrigerant line fittings. Use only the specified O-ring seals and gaskets as they are made of a special material for the R-134a system. Use only refrigerant oil of the type recommended for the A/C compressor in the vehicle.
5. Connect the A/C liquid line (1) to the A/C receiver/drier and install the retaining nut (2). Tighten the nut to 5 N.m (44 in. lbs.).
6. Connect the liquid jumper line (4) to the A/C receiver/drier and install the retaining bolt (3). Tighten the bolt to 5 N.m (44 in. lbs.).
7. Reposition the right front wheel house splash shield to the body. Refer to «SHIELD, SPLASH, FRONT WHEELHOUSE, INSTALLATION»(ref-612710-S29185888482014043000000) .
8. Install the right front wheel. Refer to «INSTALLATION»(ref-612693-S31957631432014043000000) .
9. Lower the vehicle.
10. Reconnect the negative battery cable. CAUTION: Do NOT run the engine with a vacuum pump in operation or with a vacuum present within the A/C system when equipped with the Denso 6SEU16 variable displacement compressor. Failure to follow this caution will result in serious A/C compressor damage.
11. Evacuate the refrigerant system Refer to «PLUMBING, STANDARD PROCEDURE»(ref-612707-S15586852732014043000000) .
12. If the A/C receiver drier is being replaced, add 30 milliliters (1.0 fluid ounce) of refrigerant oil to the refrigerant system. When replacing multiple A/C system components, see the «REFRIGERANT OIL CAPACITIES»(ref-612707-S23794342422014043000000) chart to determine how much oil should be added to the refrigerant system. Refer to «OIL, REFRIGERANT, STANDARD PROCEDURE»(ref-612707-S11458285262014043000000) . Use only refrigerant oil of the type recommended for the A/C compressor in the vehicle.
13. Charge the A/C system. Refer to «PLUMBING, STANDARD PROCEDURE»(ref-612707-S15586852732014043000000) .

Scheme 46

Note. LHD model shown in illustration, RHD model similar.

The A/C evaporator (1) for the heating-A/C system is mounted in the HVAC housing, which is located behind the instrument panel. The A/C evaporator and its insulator (2) are positioned within the HVAC housing so that all air entering the housing must pass over the evaporator fins before it is distributed through the heating-A/C system ducts and outlets.

A tapping block (3) and O-ring seals (4) are used to connect and seal the A/C evaporator tubes (5) to the A/C expansion valve.

The A/C evaporator can only be serviced by removing and disassembling the HVAC housing assembly.

Note. The HVAC housing assembly must be removed from the vehicle and the air distribution housing removed for service of the A/C evaporator.

Note. LHD model shown in illustrations, RHD model similar.

Scheme 47

Scheme 48

1. Remove the HVAC housing assembly and place it on a workbench. Refer to «HOUSING, HVAC, REMOVAL»(ref-612707-S11526054142014043000000) .
2. Remove the two bolts that secure the A/C expansion valve (1) to the A/C evaporator and remove the valve. Refer to «VALVE, A/C EXPANSION, REMOVAL»(ref-612707-S07572827852014043000000) .
3. Remove and discard the O-ring seals and install plugs in, or tape over the opened expansion valve and evaporator tube ports. NOTE: If the foam seal or plastic flange is deformed or damaged, it must be replaced.
4. Remove the foam seal and plastic flange (2) from the front of the two halves of the HVAC housing (3). Carefully release the four retaining tabs located at the back of the flange and pull the flange off of the evaporator tubes. If the seal or flange is deformed or damaged, it must be replaced.
5. Remove any residual sealer from the flange area at the front of the two halves of the HVAC housing.
6. Remove the air distribution housing (2) from the HVAC housing (1). Refer to «HOUSING, HVAC, REMOVAL»(ref-612707-S11526054142014043000000) .
7. Using needle nose pliers (1), disengage the two retaining tabs (2) that secure the evaporator temperature sensor (3) to the driver side of the HVAC housing (4) and remove the sensor. NOTE: If the foam insulator around the A/C evaporator is deformed or damaged, the insulator must be replaced.
8. Carefully tip the top of the A/C evaporator (1) rearward and remove the evaporator from the back of the HVAC housing (2).

Note. When replacing multiple A/C system components, see the REFRIGERANT OIL CAPACITIES chart to determine how much oil should be added to the refrigerant system. Refer to OIL, REFRIGERANT, STANDARD PROCEDURE .

Note. If only the A/C evaporator is being replaced, add 20 milliliters (0.7 fluid ounce) of refrigerant oil to the refrigerant system. Use only refrigerant oil of the type recommended for the A/C compressor in the vehicle.

Note. Replacement of the refrigerant line O-ring seals and gaskets is required anytime a refrigerant line is disconnected. Failure to replace the rubber O-ring seals and metal gaskets could result in a refrigerant system leak.

Note. LHD model shown in illustrations, RHD model similar.

Scheme 49

Note. Make sure that the foam insulator is properly positioned around the A/C evaporator and in the HVAC housing.

1. Carefully install the A/C evaporator (1) into the HVAC housing (2).
2. Install the evaporator temperature sensor (1) into the driver side of the HVAC housing (2). Make sure the retaining tabs (3) are fully engaged to the housing.
3. Install the air distribution housing (2) onto the HVAC housing (1). Refer to «HOUSING, HVAC, INSTALLATION»(ref-612707-S06054315202014043000000) .
4. Install a bead of silicone sealer around the flange area at the front of the HVAC housing (3). NOTE: If the foam seal or plastic flange is deformed or damaged, it must be replaced.
5. Install the plastic flange and foam seal (2) over the evaporator tubes and onto the front of the HVAC housing. Make sure the four flange retaining tabs are fully engaged to the housing.
6. Remove the tape or plugs from the expansion valve and evaporator ports.
7. Lubricate new O-ring seals with clean refrigerant oil and install them onto the evaporator tube fittings. Use only the specified O-ring seals as they are made of a special material for the R-134a system. Use only refrigerant oil of the type recommended for the A/C compressor in the vehicle.
8. Install the A/C expansion valve (1) and the two retaining bolts. Tighten the bolts to 11 N.m (97 in. lbs.). Refer to «VALVE, A/C EXPANSION, INSTALLATION»(ref-612707-S17594552862014043000000) .
9. Install the HVAC housing. Refer to «HOUSING, HVAC, INSTALLATION»(ref-612707-S06054315202014043000000) .
10. If the A/C evaporator is being replaced, add 20 milliliters (0.7 fluid ounce) of refrigerant oil to the refrigerant system. When replacing multiple A/C system components, see the «REFRIGERANT OIL CAPACITIES»(ref-612707-S23794342422014043000000) chart to determine how much oil should be added to the refrigerant system. Refer to «OIL, REFRIGERANT, STANDARD PROCEDURE»(ref-612707-S11458285262014043000000) . Use only refrigerant oil of the type recommended for the A/C compressor in the vehicle.

Note. It is not necessary to remove the front fascia for A/C discharge line service.

Scheme 50

Note. Typical engine shown in illustration.

Scheme 51

1. Disconnect and isolate the negative battery cable.
2. Recover the refrigerant from the refrigerant system. Refer to «PLUMBING, STANDARD PROCEDURE»(ref-612707-S15586852732014043000000) .
3. On gasoline engine equipped models, raise and support the vehicle.
4. Remove the nut (1) that secures the A/C discharge line (2) to the A/C compressor (3).
5. Disconnect the A/C discharge line from the A/C compressor and remove and discard the O-ring seal and gasket.
6. Install plugs in, or tape over the opened discharge line fitting and the compressor port.
7. On gasoline engine equipped models, partially lower the vehicle.
8. On all models remove the upper radiator closure panel and carefully pull the top of the fascia forward to gain access to the A/C discharge line (3). Refer to «PANEL, CLOSURE, UPPER, REMOVAL»(ref-612710-S14614298932014043000000) .
9. Reach down through the opening between the radiator and the front fascia and disconnect the wire harness connector (1) from the A/C pressure transducer (2).
10. Remove the nut (5) that secures the A/C discharge line to the right side of the A/C condenser (4).
11. Disconnect the A/C discharge line from the A/C condenser and remove and discard the O-ring seal and gasket.
12. Install plugs in, or tape over the discharge line fitting and the condenser port.
13. If necessary, remove the A/C pressure transducer from the A/C discharge line.

Note. When replacing multiple A/C system components, see the REFRIGERANT OIL CAPACITIES chart to determine how much oil should be added to the refrigerant system. Refer to OIL, REFRIGERANT, STANDARD PROCEDURE .

Note. Replacement of the refrigerant line O-ring seals and gaskets is required anytime a refrigerant line is disconnected. Failure to replace the rubber O-ring seals and metal gaskets may result in a refrigerant system leak.

1. If removed, install the A/C pressure transducer (2) onto the A/C discharge line (3). Tighten the A/C pressure transducer securely.
2. Position the A/C discharge line into the engine compartment.
3. Remove the tape or plugs from the discharge line fitting and the condenser port.
4. Lubricate a new rubber O-ring seal with clean refrigerant oil and install it and a new gasket onto the discharge line fitting. Use only the specified O-ring as it is made of a special material for the R-134a system. Use only refrigerant oil of the type recommended for the A/C compressor in the vehicle.
5. Reach down through the opening between the radiator and the front fascia and connect the A/C discharge line to the A/C condenser (4).
6. Install the nut (5) that secures the A/C discharge line to the A/C condenser. Tighten the nut to 5 N.m (44 in. lbs.).
7. Connect the wire harness connector (1) to the A/C pressure transducer.
8. Install the upper radiator closure panel. Refer to «PANEL, CLOSURE, UPPER, INSTALLATION»(ref-612710-S28066290942014043000000) . NOTE: Typical engine shown in illustration.
9. On gasoline engine equipped models, raise and support the vehicle.
10. Remove the tape or plugs from the discharge line fitting and the compressor port.
11. Lubricate a new rubber O-ring seal with clean refrigerant oil and install it and a new gasket onto the discharge line fitting. Use only the specified O-ring as it is made of a special material for the R-134a system. Use only refrigerant oil of the type recommended for the A/C compressor in the vehicle.
12. Connect the A/C discharge line (2) to the A/C compressor (3).
13. Install the nut (1) that secures the A/C discharge line to the A/C compressor. Tighten the nut to 20 N.m (15 ft. lbs.).
14. On gasoline engine equipped models, lower the vehicle.
15. Reconnect the negative battery cable. CAUTION: Do NOT run the engine with a vacuum pump in operation or with a vacuum present within the A/C system when equipped with the Denso 6SEU16 variable displacement compressor. Failure to follow this caution will result in serious A/C compressor damage.
16. Evacuate the refrigerant system. Refer to «PLUMBING, STANDARD PROCEDURE»(ref-612707-S15586852732014043000000) .
17. Adjust the refrigerant oil level. Refer to «OIL, REFRIGERANT, STANDARD PROCEDURE»(ref-612707-S11458285262014043000000) .
18. Charge the refrigerant system. Refer to «PLUMBING, STANDARD PROCEDURE»(ref-612707-S15586852732014043000000) .

Note. Gasoline engine model shown in illustrations, Diesel engine model similar.

Note. LHD model shown in illustrations, RHD model similar.

Note. When replacing multiple A/C system components, see the REFRIGERANT OIL CAPACITIES chart to determine how much oil should be added to the refrigerant system. Refer to OIL, REFRIGERANT, STANDARD PROCEDURE .

Note. Replacement of the refrigerant line O-ring seals and gaskets is required anytime a refrigerant line is disconnected. Failure to replace the rubber O-ring seals and metal gaskets could result in a refrigerant system leak.

Note. Gasoline engine model shown in illustrations, Diesel engine model similar.

Note. LHD model shown in illustrations, RHD model similar.

Note. Gasoline engine model shown in illustrations, Diesel engine model similar.

Note. LHD model shown in illustrations, RHD model similar.

Note. When replacing multiple A/C system components, see the REFRIGERANT OIL CAPACITIES chart to determine how much oil should be added to the refrigerant system. Refer to OIL, REFRIGERANT, STANDARD PROCEDURE .

Note. Replacement of the refrigerant line O-ring seals and gaskets is required anytime a refrigerant line is disconnected. Failure to replace the rubber O-ring seals and metal gaskets could result in a refrigerant system leak.

Note. Gasoline engine model shown in illustrations, Diesel engine model similar.

Note. LHD model shown in illustrations, RHD model similar.

1. If removed, install the rubber grommet (3) onto the driver side front floor panel (4). Make sure the grommet is fully engaged to the floor panel.
2. Connect the condensation drain tube (2) onto the drain port located on the bottom of the HVAC housing (1).
3. Install the condensation drain tube into the rubber grommet.
4. Reinstall the floor carpet. Refer to «CARPET, PASSENGER, INSTALLATION»(ref-612710-S28599935712014043000000) .

Scheme 52

The A/C expansion valve controls the amount of refrigerant entering the A/C evaporator. The A/C expansion valve is of a thermostatic expansion valve (TXV) design and consists of an aluminum H-valve type body (1) with an inlet port (2), outlet port (3) and an integral thermal sensor (4).

The A/C expansion valve is located in the engine compartment at the dash panel, between the A/C refrigerant lines and the A/C evaporator.

Scheme 53

Scheme 54

1. Disconnect and isolate the negative battery cable.
2. Recover the refrigerant from the refrigerant system. Refer to «PLUMBING, STANDARD PROCEDURE»(ref-612707-S15586852732014043000000) .
3. Remove the nuts (1) that secure the heat shield (3) to the studs (2) located on the dash panel in the engine compartment and remove the heat shield.
4. Remove the bolt (1) that secures the A/C liquid and suction line assembly (2) to the A/C expansion valve (3).
5. Disconnect the A/C liquid and suction line assembly from the A/C expansion valve and remove and discard the O-ring seals.
6. Remove the two bolts (1) that secure the A/C expansion valve (2) to the evaporator tube tapping block (3).
7. Remove the A/C expansion valve from the tapping block and remove and discard the O-ring seals
8. Install plugs in, or tape over the opened refrigerant fittings and all expansion valve and evaporator tube ports.

Note. When replacing multiple A/C system components, see the REFRIGERANT OIL CAPACITIES chart to determine how much oil should be added to the refrigerant system. Refer to OIL, REFRIGERANT, STANDARD PROCEDURE .

Note. Replacement of the refrigerant line O-ring seals is required anytime a refrigerant line is disconnected from the expansion valve, or if the expansion valve is removed. Failure to replace the rubber O-ring seals may result in a refrigerant system leak.

Note. LHD model shown in illustrations, RHD model similar.

1. Remove the tape or plugs from the opened refrigerant line fittings and all expansion valve and evaporator ports.
2. Lubricate new O-ring seals with clean refrigerant oil and install them onto the refrigerant line and evaporator tube fittings. Use only the specified O-ring seals as they are made of a special material for the R-134a system. Use only refrigerant oil of the type recommended for the A/C compressor in the vehicle.
3. Install the A/C expansion valve (2) onto the evaporator tube tapping block (3)
4. Install the two bolts (1) that secure the A/C expansion valve to the evaporator tube tapping block. Tighten the bolts to 11 N.m (97 in. lbs.).
5. Connect the A/C liquid and suction line assembly (2) to the A/C expansion valve (3).
6. Install the bolt (1) that secures the A/C liquid and suction line assembly to the A/C expansion valve. Tighten the bolt to 25 N.m (18 ft. lbs.).
7. Position the heat shield (3) onto the studs (2) located on the dash panel in the engine compartment.
8. Install the nuts (1) that secure the heat shield to the dash panel. Tighten the nuts to 1 N.m (10 in. lbs.).
9. Reconnect the negative battery cable.
10. Evacuate the refrigerant system. Refer to «PLUMBING, STANDARD PROCEDURE»(ref-612707-S15586852732014043000000) .
11. Adjust the refrigerant oil level, if required. Refer to «OIL, REFRIGERANT, STANDARD PROCEDURE»(ref-612707-S11458285262014043000000) .
12. Charge the refrigerant system. Refer to «PLUMBING, STANDARD PROCEDURE»(ref-612707-S15586852732014043000000) .

Scheme 55

Two relays (1) are used for the electric Positive Temperature Coefficient (PTC) heater system when equipped with the 2.2L diesel engine. The relays are International Standards Organization (ISO)-type relays. Relays conforming to the ISO specifications have common physical dimensions, current capacities, terminal functions and patterns (2). The PTC relays are electromechanical devices that switch fused battery current directly to the heating elements of the PTC heater unit. The PTC relays are energized by control circuits of the Totally Integrated Power Module (TIPM).

The two PTC relays are located below the left front fender in the diesel accessory fuse/relay block.

Note. LHD model shown in illustration, RHD model similar.

Scheme 56

Note. Illustration shown with left front fender removed for clarity.

1. Disconnect and isolate the negative battery cable.
2. Remove the left front wheelhouse splash shield. Refer to «SHIELD, SPLASH, FRONT WHEELHOUSE, REMOVAL»(ref-612710-S08980961332014043000000) .
3. Open the cover (1) of the diesel accessory fuse/relay block (2) located on the left front frame rail (3).
4. Remove the positive temperature coefficient (PTC) relays as necessary from the fuse/relay block.

Note. LHD model shown in illustration, RHD model similar.

Note. Illustration shown with left front fender removed for clarity.

1. Position the positive temperature coefficient (PTC) relays as necessary into the proper receptacle of the diesel accessory fuse/relay block (2) located on the left front frame rail (3).
2. Align the PTC relay terminals with the terminal cavities in the fuse/relay block and push down firmly on each relay until the terminals are fully seated.
3. Close the cover (1) of the diesel accessory fuse/relay block.
4. Install the left front wheel house splash shield. Refer to «SHIELD, SPLASH, FRONT WHEELHOUSE, INSTALLATION»(ref-612710-S29185888482014043000000) .
5. Reconnect the negative battery cable.

Scheme 57

Note. LHD model shown in illustration, RHD model similar.

An electric Positive Temperature Coefficient (PTC) heater unit (1) is used on vehicles when equipped with the 2.2L diesel engine. The PTC heater unit aids in passenger compartment heating by compensating for the lower engine coolant temperatures produced by the diesel engine. The PTC heater unit is mounted in the HVAC air distribution housing, downstream of the heater core and is controlled by the diesel Engine Control Module (ECM) and the Totally Integrated Power Module (TIPM) through two relays in diesel accessory fuse/relay block located below the left front fender.

The PTC heater consists of a molded plastic mounting plate (2) with an integral wire connector receptacle (3). Concealed behind the mounting plate are four heating elements with fins (4) that transfer the heat produced by the PTC heater to the conditioned air flowing within the air distribution housing. Two retaining tabs (5) are molded onto the opposite end of the heater unit to support the heater unit inside the air distribution housing. The PTC heater unit is connected to the vehicle electrical system through the instrument panel wire harness.

The PTC heater unit is accessed for service by removing the instrument panel.

Scheme 58

Note. PTC heater shown in illustration removed from distribution housing for clarity.

Scheme 59

1. Disconnect and isolate the negative battery cable.
2. Remove the instrument panel. Refer to «PANEL, INSTRUMENT, REMOVAL»(ref-612710-S09852678672014043000000) . NOTE: To disconnect the wire harness connector from the heater unit, pull downward on the connector lock while pulling the connector away from the heater unit.
3. Disengage the wire connector lock (2) that secures the wire harness connector (1) to the positive temperature coefficient (PTC) heater unit (3) located on the left side of the HVAC air distribution housing and disconnect the connector from the heater. NOTE: LHD model shown in illustration, RHD model similar.
4. Remove the two screws (1) that secure the PTC heater unit (2) to the left side of the HVAC air distribution housing (3).
5. Carefully remove the PTC heater unit from the air distribution housing by pulling it straight out of the housing.

Note. LHD model shown in illustration, RHD model similar.

Scheme 60

1. Carefully install the positive temperature coefficient (PTC) heater unit (2) into the left side of the HVAC air distribution housing (3). Make sure to position the two locator tabs on the end of the heater unit into the molded locator indentations on the right side of the air distribution housing.
2. Install the two screws (1) that secure the PTC heater unit to the air distribution housing. Tighten the screws to 1.2 N.m (10 in. lbs.). NOTE: PTC heater shown in illustration removed from distribution housing for clarity.
3. Connect the wire harness connector (1) to the PTC heater unit (3) while pushing upward on the connector lock (2). Make sure the wire harness connector and lock are fully engaged.
4. Install the instrument panel. Refer to «PANEL, INSTRUMENT, INSTALLATION»(ref-612710-S16010864942014043000000) .
5. Reconnect the negative battery cable.
