FASTENER TORQUE

Description	N.m	Ft. Lbs.	In. Lbs.
All Screws NOT Listed Below	2		17
A/C Compressor to Engine Bolts	25	18
A/C Receiver/Drier to Frame Rail Bolts	15	11
A/C Expansion Valve to Evaporator Bolts	11		97
A/C Liquid Lines to A/C Receiver/Drier Nut/Bolt	5		44
A/C Suction Line Junction Block Nut	5		44
Air Distribution Housing Halves Screws	1.2		10
Air Distribution Housing to HVAC Housing Screws	1.2		10
Air Inlet Housing to HVAC Housing Screws	1.2		10
Blend Door Lever Screw	0.6		5
Blower Motor Screws	1.2		10
Center Duct Screws	2.2		20
Defroster Duct Support Screws	3		27
Defroster Duct Screws	2.2		20
Demister Duct Screws	2.2		20
Flange to HVAC Housing Screw	1.2		10
Heat Shield to Dash Panel Nuts	1		10
HVAC Housing Halves Screws	1.2		10
HVAC Housing to Dash Panel Nut	4.5		40
Lower Condenser Bracket to Radiator Bolts	4.5		40
Mode Door Cam Screw	0.6		5
PTC Heater Unit to Housing Screws	1.2		10
Rear Seat Floor Duct Screw	2.2		20
Refrigerant Lines to A/C Expansion Valve Bolt	25	18
Refrigerant Lines to A/C Compressor Nuts	20	15
Refrigerant Lines to A/C Condenser Nuts	5		44
Refrigerant Line Bracket to Strut Tower Nut	4.5		40

FASTENER TORQUE SPECIFICATIONS

Application	Capacity
All models	595 g (1.31 lbs.)

REFRIGERANT CHARGE CAPACITY

Scheme 1: REMOVAL

Pull back the floor carpet to gain access to the condensation drain tube (2) located on the left side of the vehicle at the front right of the foot well. Refer to «CARPET, PASSENGER, REMOVAL»(ref-612710-S29347877022014043000000) .
Disconnect the condensation drain tube from the bottom of the HVAC housing (1).
Remove the condensate drain tube from the rubber grommet (3) in the front floor panel (4).
If required, remove the rubber grommet from the floor panel.
