Lubrication & Maintenance: Other Jeep Commander I

CHASSIS

PARTS & LUBRICATION RECOMMENDATIONS

BODY

PARTS & LUBRICATION RECOMMENDATIONS

GEAR LUBRICANTS

SAE ratings also apply to multigrade gear lubricants. In addition, API classification defines the lubricant's usage, such as API GL-5 and SAE 75W-90.

AXLE

Note. DaimlerChrysler recommends using Mopar® lubricants or lubricants of equal quality.

FRONT AXLE

1. 200MM - Mopar® Synthetic Gear Lubricant 75W-140

REAR AXLE

1. 213MM - Mopar® Synthetic Gear Lubricant 75W-140

Note. ELSD equipped axles require 118 ml (4 ounces) of Limited Slip Additive be added to the lubricant.

ENGINE OIL-GASOLINE ENGINES

When service is required, DaimlerChrysler Corporation recommends that only Mopar® brand parts, lubricants and chemicals be used. Mopar® provides the best engineered products for servicing DaimlerChrysler Corporation vehicles.

Only lubricants bearing designations defined by the following organization should be used.

1. Society of Automotive Engineers (SAE)
2. American Petroleum Institute (API)
3. National Lubricating Grease Institute (NLGI)
4. Association des Constructeurs Europeens d' Automobiles (European Automobile Manufacturers Association) (ACEA)

API SERVICE GRADE CERTIFIED

Use an engine oil that is API Certified. MOPAR® provides engine oils, that meet or exceed this requirement.

Scheme 3

An SAE viscosity grade is used to specify the viscosity of engine oil. Use only engine oils with multiple viscosities such as 5W-20 or 5W-30. These are specified with a dual SAE viscosity grade which indicates the cold-to-hot temperature viscosity range. For 3.7L/4.7L engines SAE 5W-20 engine oil is recommended for all operating temperatures. For 5.7L engines, SAE 5W-20 engine oil is recommended for all operating temperatures. Vehicles with 5.7L engines equipped with Multiple Displacement System, (MDS), must use SAE 5W-20 oil. Failure to do so may result in improper operation of the Multiple Displacement System (MDS). These engine oils improve low temperature starting and vehicle fuel economy. Refer to your engine oil filler cap for the recommended engine oil viscosity for your vehicle.

ACEA Categories

For countries that use the ACEA European Oil Categories for Service Fill Oils, use engine oils that meet the requirements of ACEA A1/B1, A2/B2, or A3/B3.

ENERGY CONSERVING OIL

An Energy Conserving type oil is recommended for gasoline engines. The designation of ENERGY CONSERVING is located on the label of an engine oil container.

Scheme 4

Standard engine oil identification notations have been adopted to aid in the proper selection of engine oil. The identifying notations are located on the front label of engine oil plastic bottles and the top of engine oil cans.

This symbol means that the oil has been certified by the American Petroleum Institute (API). DaimlerChrysler only recommends API Certified engine oils. Use Mopar® engine oil or equivalent.

SYNTHETIC ENGINE OILS

There are a number of engine oils being promoted as either synthetic or semi-synthetic. If you chose to use such a product, use only those oils that meet the American Petroleum Institute (API) and SAE viscosity standard. Follow the service schedule that describes your driving type.

ENGINE OIL ADDITIVES/SUPPLEMENTS

The manufacturer does not recommend the addition of any engine oil additives/supplements to the specified engine oil. Engine oil additives/supplements should not be used to enhance engine oil performance. Engine oil additives/supplements should not be used to extend engine oil change intervals. No additive is known to be safe for engine durability and can degrade emission components. Additives can contain undesirable materials that harm the long term durability of engines by

1. Doubling the level of phosphorus in the engine oil. The ILSAC (International Lubricant Standard Approval Committee) GF-2 and GF-3 standards require that engine oil contain no more than 0.10% phosphorus to protect the vehicles emissions performance. Addition of engine oil additives/supplements can poison, from the added sulfur and phosphorus, catalysts and hinder efforts to guarantee emissions performance to 80,000 miles.
2. Altering the viscosity characteristics of the engine oil so that it no longer meets the requirements of the specified viscosity grade.
3. Creating potential for an undesirable additive compatibility interaction in the engine crankcase. Generally it is not desirable to mix additive packages from different suppliers in the crankcase; there have been reports of low temperature engine failures caused by additive package incompatibility with such mixtures.

A/C REFRIGERANT

The refrigerant used in this air conditioning system is a HydroFluoroCarbon (HFC), type R-134a. Unlike R-12, which is a ChloroFluoroCarbon (CFC), R-134a refrigerant does not contain ozone-depleting chlorine. R-134a refrigerant is a non-toxic, non-flammable, clear and colorless liquefied gas.

The A/C refrigerant system is filled-for-life at the factory and requires no regular maintenance. Although not required at specific intervals, the charge level should be checked if system performance deteriorates or if a noise or leak is suspected. Refer to DIAGNOSIS AND TESTING .

ETHYLENE-GLYCOL MIXTURES

The required ethylene-glycol (antifreeze) and water mixture depends upon the climate and vehicle operating conditions. The recommended mixture of 50/50 ethylene-glycol and water will provide protection against freezing to -37° C (-35° F). The antifreeze concentration must always be a minimum of 44 percent, year-round in all climates. If percentage is lower than 44 percent, engine parts may be eroded by cavitation, and cooling system components may be severely damaged by corrosion. Maximum protection against freezing is provided with a 68 percent antifreeze concentration, which prevents freezing down to -67.7° C (-90° F). A higher percentage will freeze at a warmer temperature. Also, a higher percentage of antifreeze can cause the engine to overheat because the specific heat of antifreeze is lower than that of water.

Use of 100 percent ethylene-glycol will cause formation of additive deposits in the system, as the corrosion inhibitive additives in ethylene-glycol require the presence of water to dissolve. The deposits act as insulation, causing temperatures to rise to as high as 149° C (300° F). This temperature is hot enough to melt plastic and soften solder. The increased temperature can result in engine detonation. In addition, 100 percent ethylene-glycol freezes at 22° C (-8° F).

PROPYLENE-GLYCOL MIXTURES

It's overall effective temperature range is smaller than that of ethylene-glycol. The freeze point of 50/50 propylene-glycol and water is -32° C (-26° F). 5° C higher than ethylene-glycol's freeze point. The boiling point (protection against summer boil-over) of propylene-glycol is 125° C (257° F ) at 96.5 kPa (14 psi), compared to 128° C (263° F) for ethylene-glycol. Use of propylene-glycol can result in boil-over or freeze-up on a cooling system designed for ethylene-glycol. Propylene glycol also has poorer heat transfer characteristics than ethylene glycol. This can increase cylinder head temperatures under certain conditions.

Propylene-glycol/ethylene-glycol mixtures can cause the destabilization of various corrosion inhibitors, causing damage to the various cooling system components. Also, once ethylene-glycol and propylene-glycol based coolants are mixed in the vehicle, conventional methods of determining freeze point will not be accurate. Both the refractive index and specific gravity differ between ethylene glycol and propylene glycol.

TRANSFER CASE

Recommended lubricant for the NV140 transfer case is Mopar® ATF+4, Automatic Transmission Fluid. Recommended lubricant for the NV245 transfer case is Mopar® NV245/247 Transfer Case Fluid.

ENGINE OIL-DIESEL ENGINE

When service is required, DaimlerChrysler Corporation recommends that only Mopar ® brand parts, lubricants and chemicals be used. Mopar ® provides the best engineered products for servicing Chrysler LLC vehicles.

Only lubricants bearing designations defined by the following organization should be used.

1. Society of Automotive Engineers (SAE)
2. American Petroleum Institute (API)
3. National Lubricating Grease Institute (NLGI)
4. Association des Constructeurs Europeens d' Automobiles (European Automobile Manufacturers Association) (ACEA)

Use an engine oil that is API Certified. Mopar ® provides Synthetic engine oils, that meet or exceed this requirement.

SAE VISCOSITY GRADE

An SAE Synthetic engine oil that conforms to ACEA A3/B4/C3 that is approved to MB 229.31 is recommended for all operating temperatures. This engine oil is a low ash product that improves low temperature starting and vehicle fuel economy.

DISPOSING OF USED ENGINE OIL

Care should be taken in disposing of the used engine oil from your vehicle. Used oil, indiscriminately discarded, can present a problem to the environment. Contact your local authorized dealer, service station, or governmental agency for advice on how and where used oil can be safely discarded in your area.

The manufacturer does not recommend the addition of any engine oil additives/supplements to the specified engine oil. Engine oil additives/supplements should not be used to enhance engine oil performance. Engine oil additives/supplements should not be used to extend engine oil change intervals. No additive is known to be safe for engine durability and can degrade emission components. Additives can contain undesirable materials that harm the long term durability of engines by

1. Doubling the level of Phosphorus in the engine oil. The ILSAC (International Lubricant Standard Approval Committee) GF-2 and GF-3 standards require that engine oil contain no more than 0.10% Phosphorus to protect the vehicles emissions performance. Addition of engine oil additives/supplements can poison, from the added sulfur and phosphorus, catalysts and hinder efforts to guarantee emissions performance to 80,000 miles.
2. Altering the viscosity characteristics of the engine oil so that it no longer meets the requirements of the specified viscosity grade.
3. Creating potential for an undesirable additive compatibility interaction in the engine crankcase. Generally it is not desirable to mix additive packages from different suppliers in the crankcase; there have been reports of low temperature engine failures caused by additive package incompatibility with such mixtures.

DIESEL FUEL

Diesel fuels are available from most reputable fuel marketers. Fuel with a calculated Cetane Index of 45 or higher must be used. See your authorized dealer or distributor for further information regarding fuels availability.

In areas where diesel fuel is below the recommended quality levels (high levels of sulfur and water) it is critical to monitor the fuel filter for contamination and the "Water-In-Fuel" message in the Electronic Vehicle Information Center (EVIC). Failure to properly service the fuel system for these items can significantly reduce engine life and lead to major engine repair. More frequent service intervals of the fuel filter/water separator unit may be required under these conditions than those shown in " MAINTENANCE SCHEDULE A or B."

GAS ENGINES

The cooling system is designed around the coolant. The coolant must accept heat from engine metal, in the cylinder head area near the exhaust valves and engine block. Then coolant carries the heat to the radiator where the tube/fin radiator can transfer the heat to the air.

The use of aluminum cylinder blocks, cylinder heads, and water pumps requires special corrosion protection. Mopar® Antifreeze/Coolant, 5 Year/100,000 Mile Formula (MS-9769), or the equivalent ethylene glycol based coolant with hybrid organic corrosion inhibitors (called HOAT, for Hybrid Organic Additive Technology) is recommended. This coolant offers the best engine cooling without corrosion when mixed with 50% Ethylene Glycol and 50% distilled water to obtain a freeze point of -37°C (-35°F). If it loses color or becomes contaminated, drain, flush, and replace with fresh properly mixed coolant solution.

The green coolant MUST NOT BE MIXED with the orange or magenta coolants. When replacing coolant the complete system flush must be performed before using the replacement coolant.

DIESEL ENGINE

The cooling system is designed around the coolant. The coolant must accept heat from engine metal, in the cylinder head area near the exhaust valves and engine block. Then coolant carries the heat to the radiator where the tube/fin radiator can transfer the heat to the air.

The use of aluminum cylinder blocks, cylinder heads, and water pumps requires special corrosion protection. Glysantin G 30-91 Antifreeze/Coolant, 5 Year/150,000 Mile Formula (ASTM D3306), or the equivalent ethylene glycol based coolant. This coolant offers the best engine cooling without corrosion when mixed with 50% coolant and 50% distilled water to obtain a freeze point of -36°C (-34°F). It is dyed purple to distinguish it's unique chemistry from traditional green and yellow silicate coolants. If it loses color or becomes contaminated, drain, flush, and replace with fresh properly mixed coolant solution.

The purple coolant MUST NOT BE MIXED with the orange, green or magenta coolants. When replacing coolant the complete system flush must be performed before using the replacement coolant.

Schedule "A"

MAINTENANCE SCHEDULE "A" (1 OF 2)

MAINTENANCE SCHEDULE "A" (2 OF 2)

Inspection and service should be performed anytime a malfunction is observed or suspected. Retain all receipts. <-- The replacement of such component is requested when there is superficial wear, bearing clearance, or evident grease leak.

Schedule "B"

Follow schedule "B" if you usually operate your vehicle under one or more of the following conditions.

1. Day or night temperatures are below 0°C (32°F).
2. Stop and go driving.
3. Extensive engine idling.
4. Driving in dusty conditions.
5. Short trips of less than 16.2 km (10 miles).
6. More than 50% of your driving is at sustained high speeds during hot weather, above 32°C (90°F).
7. Trailer towing.
8. Taxi, police, or delivery service (commercial service).
9. Off-road or desert driving.

MAINTENANCE SCHEDULE "B" (1 OF 3)

MAINTENANCE SCHEDULE "B" (2 OF 3)

MAINTENANCE SCHEDULE "B" (3 OF 3)

<-- Applies only if vehicle is used for frequent trailer towing, or fleet/commercial service.

! The replacement of such component is requested when there is superficial wear, bearing clearance, or evident grease leak.

Inspection and service should be performed anytime a malfunction is observed or suspected. Retain all receipts.

MAINTENANCE SCHEDULE "A" (1 OF 4)

MAINTENANCE SCHEDULE "A" (2 OF 4)

MAINTENANCE SCHEDULE "A" (3 OF 4)

MAINTENANCE SCHEDULE "A" (4 OF 4)

Inspection and service should also be performed anytime a malfunction is observed or suspected. Retain all receipts.

<-- This maintenance is recommended by the manufacturer to the owner, but is not required to maintain emissions warranty.

Follow this schedule if you usually operate your vehicle under one or more of the following conditions.

1. Day or night temperatures are below 32°F (0°C)
2. Stop and go driving
3. Excessive engine idling
4. Driving in dusty conditions
5. Short trips of less than 10 miles (16.2 km)
6. More than 50% of your driving is at sustained high speeds during hot weather, above 90°F (32°C)
7. Trailer towing
8. Taxi, police, or delivery service (commercial service)
9. Off-road or desert driving
10. If equipped for and operated with E-85 (ethanol) fuel.

MAINTENANCE SCHEDULE "B" (1 OF 8)

MAINTENANCE SCHEDULE "B" (2 OF 8)

MAINTENANCE SCHEDULE "B" (3 OF 8)

MAINTENANCE SCHEDULE "B" (4 OF 8)

Applies only if vehicle is used for frequent trailer towing, or fleet/commercial service.

MAINTENANCE SCHEDULE "B" (5 OF 8)

MAINTENANCE SCHEDULE "B" (6 OF 8)

MAINTENANCE SCHEDULE "B" (7 OF 8)

MAINTENANCE SCHEDULE "B" (8 OF 8)

Note. Applies only if vehicle is used for frequent trailer towing, or fleet/commercial service.

Inspection and service should also be performed anytime a malfunction is observed or suspected. Retain all receipts.

<-- This maintenance is recommended by the manufacturer to the owner, but is not required to maintain emissions warranty.

MAINTENANCE SCHEDULE "B" (1 OF 8)

MAINTENANCE SCHEDULE "B" (2 OF 8)

MAINTENANCE SCHEDULE "B" (3 OF 8)

MAINTENANCE SCHEDULE "B" (4 OF 8)

MAINTENANCE SCHEDULE "B" (5 OF 8)

MAINTENANCE SCHEDULE "B" (6 OF 8)

MAINTENANCE SCHEDULE "B" (7 OF 8)

MAINTENANCE SCHEDULE "B" (8 OF 8)

Note. Applies only if vehicle is used for frequent trailer towing, or fleet/commercial service.

Inspection and service should also be performed anytime a malfunction is observed or suspected. Retain all receipts.

<-- This maintenance is recommended by the manufacturer to the owner, but is not required to maintain emissions warranty.

* This maintenance is not required if the belt was previously replaced.

MAINTENANCE SCHEDULE "A" (1 OF 5)

MAINTENANCE SCHEDULE "A" (2 OF 5)

MAINTENANCE SCHEDULE "A" (3 OF 5)

MAINTENANCE SCHEDULE "A" (4 OF 5)

MAINTENANCE SCHEDULE "A" (5 OF 5)

Inspection and service should also be performed anytime a malfunction is observed or suspected. Retain all receipts.

<-- This maintenance is recommended by the manufacturer to the owner, but is not required to maintain emissions warranty.

* This maintenance is not required if the belt was previously replaced.

Scheme 5

When properly positioned, a floor jack can be used to lift the vehicle (3 and 4). Support the vehicle in the raised position with jack stands at the front and rear ends of the frame rails (1 and 2).

HOIST

A vehicle can be lifted with

1. A single-post, frame-contact hoist.
2. A twin-post, chassis hoist.
3. A ramp-type, drive-on hoist.

Note. When a frame-contact type hoist is used, verify that the lifting pads are positioned properly (1 and 2).

JUMP STARTING

Scheme 6

1. Raise hood on disabled vehicle and visually inspect engine compartment for: Battery cable clamp condition, clean if necessary. Frozen battery. Yellow or bright color test indicator, if equipped. Low battery fluid level. Generator drive belt condition and tension. Fuel fumes or leakage, correct if necessary. CAUTION: If the cause of starting problem on disabled vehicle is severe, damage to booster vehicle charging system can result.
2. When using another vehicle as a booster source, park the booster vehicle within cable reach. Turn off all accessories, set the parking brake, place the automatic transmission in PARK or the manual transmission in NEUTRAL and turn the ignition OFF.
3. On disabled vehicle, place gear selector in park or neutral and set park brake. Turn off all accessories.
4. Connect jumper cables to booster battery. RED clamp to positive terminal (+). BLACK clamp to negative terminal (-). DO NOT allow clamps at opposite end of cables to touch, electrical arc will result. Review all warnings in this procedure.
5. On disabled vehicle, connect RED jumper cable clamp (2) to positive (+) terminal. Connect BLACK jumper cable clamp (1) to engine ground as close to the ground cable attaching point as possible.
6. Start the engine in the vehicle which has the booster battery, let the engine idle a few minutes, then start the engine in the vehicle with the discharged battery. CAUTION: Do not crank starter motor on disabled vehicle for more than 15 seconds, starter will overheat and could fail.
7. Allow battery (4) in disabled vehicle to charge to at least 12.4 volts (75% charge) before attempting to start engine. If engine does not start within 15 seconds, stop cranking engine and allow starter to cool (15 min.), before cranking again.

DISCONNECT CABLE CLAMPS AS FOLLOWS

1. Disconnect BLACK cable clamp (1) from engine ground on disabled vehicle.
2. When using a Booster vehicle, disconnect BLACK cable clamp from battery negative terminal. Disconnect RED cable clamp from battery positive terminal.
3. Disconnect RED cable clamp (2) from battery positive terminal on disabled vehicle.

Scheme 7

Some Jeep vehicles are equipped with front emergency tow hooks. The tow hooks should be used for EMERGENCY purposes only.

TOWING RECOMMENDATIONS

A vehicle equipped with SAE approved wheel lift type towing equipment can be used to tow WK/WH vehicles. When towing a 4WD vehicle using a wheel lift towing device, use tow dollies under the opposite end of the vehicle. A vehicle with a flatbed device can also be used to transport a disabled vehicle.

Scheme 8

1. Secure loose and protruding parts.
2. Always use a safety chain system that is independent of the lifting and towing equipment.
3. Do not allow towing equipment to contact the disabled vehicle's fuel tank.
4. Do not allow anyone under the disabled vehicle while it is lifted by the towing device.
5. Do not allow passengers to ride in a vehicle being towed.
6. Always observe state and local laws regarding towing regulations.
7. Do not tow a vehicle in a manner that could jeopardize the safety of the operator, pedestrians or other motorists.
8. Do not attach tow chains, T-hooks, or J-hooks to a bumper, steering linkage, drive shafts or a non-reinforced frame hole.
9. Do not tow a heavily loaded vehicle. Use a flatbed device to transport a loaded vehicle.

TWO WHEEL DRIVE VEHICLE TOWING

DaimlerChrysler Corporation recommends that a vehicle be towed with the rear end lifted, whenever possible.

TWO WHEEL DRIVE TOWING - REAR END LIFTED

2WD vehicles can be towed with the front wheels on the surface for extended distances at speeds not exceeding 48 km/h (30 mph).

1. Attach wheel lift device to rear wheels.
2. Place the transmission in neutral.
3. Raise vehicle to towing position.
4. Attach safety chains. Route chains so not to interfere with tail pipe when vehicle is lifted.
5. Turn the ignition switch to the OFF position to unlock the steering wheel. CAUTION: Do not use steering column lock to secure steering wheel during towing operation.
6. Secure steering wheel in straight ahead position with a clamp device designed for towing.
7. Place transmission in park.

TWO WHEEL DRIVE TOWING - FRONT END LIFTED

1. Attach wheel lift device to rear wheels.
2. Place the transmission in neutral.
3. Raise the rear of the vehicle off the ground and install tow dollies under rear wheels.
4. Attach wheel lift device to front wheels and raise vehicle to towing position.
5. Attach the safety chains. CAUTION: Do not use steering column lock to secure steering wheel during towing operation.
6. Turn the ignition switch to the OFF position to unlock the steering wheel.
7. Secure steering wheel in straight ahead position with a clamp device designed for towing.
8. Place transmission in park.

FOUR WHEEL DRIVE VEHICLE TOWING

DaimlerChrysler Corporation recommends that a 4WD vehicle be transported on a flat bed device. A wheel lift device can be used provided the trailing wheels are off the ground and positioned in tow dollies.

FOUR WHEEL DRIVE TOWING - REAR END LIFTED

1. Attach wheel lift device to front wheels.
2. Place the transmission in neutral.
3. Raise the front of the vehicle off the ground and install tow dollies under front wheels.
4. Attach wheel lift device to rear wheels and raise vehicle to towing position.
5. Attach safety chains. Route chains so not to interfere with tail pipe when vehicle is lifted.
6. Turn the ignition switch to the OFF position to unlock the steering wheel. CAUTION: Do not use steering column lock to secure steering wheel during towing operation.
7. Secure steering wheel in straight ahead position with a clamp device designed for towing.
8. Place transmission in park.

FOUR WHEEL DRIVE TOWING - FRONT END LIFTED

1. Attach wheel lift device to rear wheels.
2. Place the transmission in neutral.
3. Raise the rear of the vehicle off the ground and install tow dollies under rear wheels.
4. Attach wheel lift device to front wheels and raise vehicle to towing position.
5. Attach the safety chains. CAUTION: Do not use steering column lock to secure steering wheel during towing operation.
6. Turn the ignition switch to the OFF position to unlock the steering wheel.
7. Secure steering wheel in straight ahead position with a clamp device designed for towing.
8. Place transmission in park.

Towing - 2WD Models

Towing - Quadra-Trac I (Single-Speed Transfer Case) 4WD Models

Towing - Quadra-Trac II /Quadra-Drive II 4WD Models

Shifting Into Neutral (N)

1. Depress brake pedal.
2. Shift transmission into N (Neutral).
3. Shift transfer case lever into N (Neutral). Refer to "Four Wheel Drive «OPERATION»(ref-288217-S30306151932008062000000) ". Start engine.
4. Shift transmission into D (Drive).
5. Release brake pedal and ensure that there is no vehicle movement.
6. Shut the engine OFF and place the ignition key into the unlocked OFF position.
7. Shift transmission into "P" (Park).
8. Apply parking brake.
9. Attach vehicle to the tow vehicle with tow bar.
10. Release parking brake.

Shifting Out Of Neutral (N)

Use the following procedure to prepare the vehicle for normal usage.

1. Turn the ignition key to the unlocked OFF position.
2. Shift transmission into "N" (Neutral).
3. Shift transfer case lever to desired position. Refer to "Four Wheel Drive «OPERATION»(ref-288217-S30306151932008062000000) ".
4. Shift transmission into "P" (Park).
5. Start the engine.
6. Shift transmission into "D" (Drive).

Note. When shifting out of transfer case "N" (Neutral), turning the engine OFF may be required to avoid gear clash.
