HVAC Systems - Service Information: Specifications Jeep Commander I

A/c Compressor 4 illustrations ~270 words

TORQUE

DescriptionN.mFt. Lbs.In. Lbs.
All Screws NOT Listed Below217
A/C Compressor to 3.7L/4.7L Engine Bolt (#3)4030
A/C Compressor to 3.7L/4.7L Engine Bolts (except #3)5541
A/C Compressor to 5.7L Engine Bolts5541
A/C Condenser to Radiator Bolts544
Compressor Shaft Bolt19168
Front A/C Expansion Valve to Evaporator Tube Tapping Block Bolts1197
Front Air Distribution Housing Halves Screws2.220
Front Air Distribution Housing to HVAC Housing Screws2.220
Front Blower Motor Screws2.220
Front HVAC Housing Halves Screws2.220
Front HVAC Housing to Dash Panel Bolts/Nut762
Front Heater Core and Tube Cover to HVAC Housing Screws2.220
Front Heater Core Tubes to Heater Core Bolt327
Front Heater Core Tube Retaining Bracket to HVAC Housing Screw2.220
Liquid Line Extension Tube to Underbody Liquid Line Nut2015
Rear A/C Expansion Valve to Rear Evaporator Tube Tapping Block Bolts1197
Rear HVAC Housing to Rear Quarter Panel Nut and Bolt327
Refrigerant Lines to Front A/C Expansion Valve Nut2015
Refrigerant Lines to A/C Compressor Nuts2015
Refrigerant Lines to A/C Condenser Nuts2015
Refrigerant Line to Receiver/drier Nut2015
Receiver/drier to Radiator/fan Shroud Screw544
Suction Line Extension Tube to Underbody Suction Line Nut2015
Underbody Refrigerant Lines to Rear A/C Expansion Valve Nut1197
ItemDescriptionNotes
A/C CompressorDenso 10S17ND-8 PAG oil
Freeze-up ControlEvaporator Temperature SensorHVAC housing mounted (front)
Low psi ControlA/C Pressure TransducerA/C Discharge line mounted - opens below 110 kPa (16 psi), closes above 221 kPa (32 psi)
High psi ControlA/C Pressure TransducerA/C Discharge line mounted - opens above 3219 kPa (476 psi), closed below 2937 kPa (426 psi)
R-134a Refrigerant Charge CapacitySingle Unit 0.68 kg (1.5 lbs.) Dual Unit 0.963 kg (2.125 lbs.)Also see A/C Underhood Specification Label located in the engine compartment
A/C Clutch Coil Draw3.3 amps@ 12V ± 0.5V @ 21° C (70° F)
A/C Clutch Coil Resistance3.6 ± 0.2 ohmsWhen measured across coil lead connector
A/C Clutch Air Gap0.35 - 0.60 mm (0.014 - 0.024 in.)

Scheme 1

Scheme 1: HEATING-A/C SYSTEM

Scheme 2

Scheme 2

Scheme 3

Scheme 3

Scheme 4

Scheme 4: ACTUATOR-BLEND DOOR

The blend door actuators (1) are reversible, 12 volt direct current (DC), servo motors. Models equipped with the MTC single zone heating-A/C system have a single blend-air door, which is controlled by a single blend door actuator. Models with the ATC dual zone heating-A/C system have two blend-air doors, which are controlled by two blend door actuators.

The blend door actuator for the single zone heating-A/C system is located on the driver side end of the HVAC air distribution housing, close to the dash panel.

For the dual zone heating-A/C system, the same blend door actuator used for the single zone system becomes the driver side blend door actuator, which is mechanically connected to only the driver side blend-air door. A second separate blend door actuator is also located on the passenger side of the HVAC air distribution housing which is mechanically connected to only the passenger side blend-air door.

The blend door actuators are interchangeable with each other, as well as with the actuators for the mode-air door and the recirculation-air door. Each actuator is contained within an identical black molded plastic housing with an integral wire connector receptacle (2). Each actuator also has an identical output shaft with splines (3) that connects it to its respective door linkage and three integral mounting tabs (4) that allow the actuator to be secured to the HVAC housing. The blend door actuators do not require mechanical indexing to the blend-air doors, as they are electronically calibrated by the A/C-heater control.
