HVAC Systems - Service Information: Removal & Installation Jeep Commander I

A/c Compressor 5 illustrations ~525 words

REMOVAL

WARNINGDisable the airbag system before attempting any steering wheel, steering column, or instrument panel component diagnosis or service. Disconnect and isolate the negative battery (ground) cable, then wait two minutes for the airbag system capacitor to discharge before performing further diagnosis or service. This is the only sure way to disable the airbag system. Failure to take the proper precautions could result in accidental airbag deployment and possible personal injury or death.

Note. The heater-A/C system is equipped with two mode door actuators. One for the air doors for the outlets in the instrument panel and one for the air door for the 2nd row/console outlets.

Scheme 8

Scheme 8: PANEL/DEFROST/DEMIST/FLOOR
Scheme 8: PANEL/DEFROST/DEMIST/FLOOR
  1. Disconnect and isolate the negative battery cable.
  2. On LHD models, remove the instrument panel silencer from the driver side of the instrument panel.
  3. On RHD models, remove the glove box from the instrument panel. Refer to «REMOVAL»(ref-288230-S13830454662008062000000) .
  4. Remove the three screws (1) that secure the mode door actuator (2) to the left side of the HVAC air distribution housing (3).
  5. Remove the mode door actuator from the air distribution housing and disconnect the HVAC wire harness connector (4) from the actuator.
  6. Remove the mode door actuator from the vehicle.

Scheme 9

Scheme 9: 2nd ROW/CONSOLE
Scheme 9: 2nd ROW/CONSOLE
  1. Disconnect and isolate the negative battery cable.
  2. Remove the instrument panel from the vehicle. Refer to «REMOVAL»(ref-288230-S41182796142008062000000) .
  3. Remove the two screws (1) that secure the mode door actuator (2) to the rear of the HVAC air distribution housing (3).
  4. Remove the mode door actuator from the air distribution housing and disconnect the HVAC wire harness connector (4) from the actuator.
  5. Remove the mode door actuator from the vehicle.

Scheme 10

Scheme 10: PANEL/DEFROST/DEMIST/FLOOR
Scheme 10: PANEL/DEFROST/DEMIST/FLOOR
  1. Position the mode door actuator (1) into the vehicle.
  2. Install the mode door actuator onto the left side of the HVAC air distribution housing (2). If necessary, rotate the actuator slightly to align the splines on the actuator output shaft (3) with those on the mode door cam (4).
  3. Install the screws (1) that secure the mode door actuator (2) to the left side of the air distribution housing (3). Tighten the screws to 2 N.m (17 in. lbs.).
  4. Connect the HVAC wire harness connector (4) to the mode door actuator.
  5. On LHD models, install the instrument panel silencer onto the driver side of the instrument panel.
  6. On RHD models, install the glove box into the instrument panel. Refer to «INSTALLATION»(ref-288230-S13258771922008062000000) .
  7. Reconnect the negative battery cable.

Scheme 11

Scheme 11: 2nd ROW/CONSOLE
Scheme 11: 2nd ROW/CONSOLE
  1. Position the mode door actuator (1) into the vehicle.
  2. Install the mode door actuator onto the rear of the HVAC air distribution housing (2). If necessary, rotate the actuator slightly to align the splines on the actuator output shaft (3) with those on the pivot shaft of the rear floor/console air door (4).
  3. Install the two screws (1) that secure the mode door actuator (2) to the rear of the air distribution housing (3). Tighten the screws to 2 N.m (17 in. lbs.).
  4. Connect the HVAC wire harness connector (4) to the mode door actuator.
  5. Install the instrument panel. Refer to «INSTALLATION»(ref-288230-S31311600622008062000000) .
  6. Reconnect the negative battery cable.
WARNINGDisable the airbag system before attempting any steering wheel, steering column, or instrument panel component diagnosis or service. Disconnect and isolate the battery negative (ground) cable, then wait two minutes for the airbag system capacitor to discharge before performing further diagnosis or service. This is the only sure way to disable the airbag system. Failure to take the proper precautions could result in accidental airbag deployment and possible personal injury or death.

Note. Take the proper precautions to protect the face of the instrument panel from cosmetic damage while performing this procedure.

Scheme 12

Scheme 12: FRONT FLOOR DUCTS
Scheme 12: FRONT FLOOR DUCTS

Note. Illustration shown with instrument panel, gear selector and console duct removed for clarity.

  1. Remove the instrument panel from the passenger compartment. Refer to «REMOVAL»(ref-288230-S41182796142008062000000) .
  2. Disconnect the right front floor duct (5) and the left front floor duct (6) from the rear of the air distribution housing (4) and remove the front floor ducts from the vehicle.
