Removal & Installation (Front Door Panel)
- Disconnect negative battery cable. Remove door panel screws. Using a trim stick, and starting at bottom of trim panel, gently pry around perimeter of trim panel.
- Lift door trim upwards and away from door to disengage top of panel from inner weather-stripping. Pull door trim panel out far enough to access inside door latch release and lock linkage rods near back of inside door remote controls.
- Disconnect ends of latch release and lock linkage rods and remove rod ends from inside door remote controls. Disconnect door module connectors. Remove door trim panel from door. To install, reverse removal procedure.
Removal & Installation (Rear Door Panel)
- Disconnect negative battery cable. Put window in down position. Remove door trim panel mounting screws. Using trim stick, beginning at bottom of door panel, gently pry around perimeter of trim panel.
- Pull trim panel outward and disconnect handle-to-latch rods. Disconnect power window wiring harness connector. Remove trim panel from door. To install, reverse removal procedure.
Removal & Installation
Door module is mounted to inside of front door trim panel. Remove front door trim panel. See DOOR TRIM PANEL . Remove screws securing door module to door trim panel. Remove door module from trim panel. To install, reverse removal procedure.
Removal & Installation (Front Window Motor)
- Disconnect negative battery cable. Remove front door trim panel. See «DOOR TRIM PANEL»(ref-1114-S42427777992000031300000). Pry up on weatherstrip corner and remove inner and outer weather-stripping. (Scheme 1) Put window in up position.
- Remove bolts securing glass to regulator assembly. Carefully lift glass upward and out of door. Loosen regulator assembly mounting bolts/nuts. (Scheme 2)
- Lift regulator assembly upward to release assembly from key hole slots. Remove regulator assembly through access hole in inner door panel. To install, reverse removal procedure.
Scheme 1
Scheme 2
Removal & Installation (Rear Window Motor)
- Disconnect negative battery cable. Remove rear door trim panel. See «DOOR TRIM PANEL»(ref-1114-S42427777992000031300000). Remove bolt securing glass to regulator assembly, and support glass. Remove lower regulator mounting bolts. (Scheme 3)
- Remove window motor nuts. Loosen upper regulator mounting bolt. Disconnect window motor connector. Remove regulator and window motor assembly. To install, reverse removal procedure.
Scheme 3
Removal & Installation (Rear Window Switch)
Disconnect negative battery cable. Remove rear door trim panel. See DOOR TRIM PANEL . Unsnap switch from receptacle in trim panel. To install, reverse removal procedure.
