LUBRICATION SPECIFICATIONS
| Material | Condition | Specification |
|---|
| Engine Oil | Ambient Temperature Less Than 60°F (16°C) To Over -20°F (-29°C) | SAE 5W-30: API SH |
| Engine Oil | Ambient Temperature Above 0°F (-18°C) To Over 100°F (38°C) | SAE 10W-30: API SH |
| Automatic Transmission Fluid | 2.5L Engine | ATF+2 or ATF+2 Type 7176 |
| Automatic Transmission Fluid | 4.0L Engine | DEXRON III MERCON |
| Manual Transmission Fluid | All | SAE 75W-90 API-GL5 |
| Transfer Case Fluid | All | Dexron II,Dexron III, or Mercon |
| Front Axle Fluid (1) | All | SAE 75W-90 API GL5 |
| Rear Axle Fluid (1) | Non-Towing | SAE 75W-90 API GL5 |
| Rear Axle Fluid (1) | Towing | SAE 75W-140 |
| Rear Axle Fluid Additive | Equipped With Limited Slip Trac-Lok Differential | Mopar Hypoid Gear Oil Additive Friction Modifier |
| Brake Fluid | All | DOT 3 |
| Power Steering Fluid | All | Mopar Power Steering Fluid (2) |
| Engine Coolant | All | Ethylene-Glycol |
| Steering Linkage Lubrication | All | Mopar Multi-Purpose Lubricant or equivalent (labeled NLGI Grade 2 EP, GC-LB) |
| A/C Refrigerant | All | R134a |
| (1) Models equipped with a limited slip Trac-Lok differential require an additive. (2) Do not use ATF. |
| (1) | Models equipped with a limited slip Trac-Lok differential require an additive. |
LUBRICATION SPECIFICATIONS
FLUID CAPACITIES
| Item | Condition | Specification (1) |
|---|
| Engine Oil | 2.5L: Drained, With New Filter | 4.0 Qts. (3.8L) |
| Engine Oil | 4.0L: Drained, With New Filter | 6.0 Qts. (5.7L) |
| Automatic Transmission Fluid | 2.5L: Drained | 7.0 Qts. (6.6L) |
| Automatic Transmission Fluid | 4.0L: Drained | 8.5 Qts. (8.0L) |
| Manual Transmission Fluid | 2.5L w/ 2WD: Drained | 3.70 Qts. (3.5L) |
| Manual Transmission Fluid | 2.5L w/ 4WD: Drained | 3.49 Qts.(3.3L) |
| Manual Transmission Fluid | 4.0L w/ 2WD: Drained | 3.32 Qts. (3.2L) |
| Manual Transmission Fluid | 4.0L w/ 4WD: Drained | 3.27 Qts.(3.1L) |
| Transfer Case Fluid (2) | Selec-Trac:Drained | 1.43 Qts. (1.3L) |
| Transfer Case Fluid (2) | Command-Trac:Drained | 1.1 Qts.(1.0L) |
| Front Axle Fluid | All: Drained | 1.5 Qts. (1.5L) |
| Rear Axle Fluid (3) | Dana | 1.7 Qts. (1.6L) |
| Rear Axle Fluid (3) | Chrysler | 2.2 Qts. (2.0L) |
| Engine Coolant (4) | 2.5L: Drained | 10.0 Qts. (8.5L) |
| Engine Coolant (4) | 4.0L: Drained | 12.0 Qts. (11.4L) |
| A/C Refrigerant | All: Evacuated | 0.567 Kgs. (1.25 Lbs.) |
| Fuel Tank | Full Capacity | 20.0 Gal. (75.7L) |
| (1) Capacities are recommended or calculated levels. Always use dipstick (if available) to measure level. (2) The Selec-Trac system can be identified by five positions on the transfer case shift lever; the Command-Trac has only four positions. (3) Differential can be identified by a tag fastened on the housing by a cover bolt. The Dana has a 7.6" ring gear and is identified on the tag as a RBI 194. The Chrysler has a 8.25" ring gear and has its assembly number on the tag. (4) Includes 2.3 Qts. (2.2L) for coolant recovery bottle. |
| (1) | Capacities are recommended or calculated levels. Always use dipstick (if available) to measure level. |
| (2) | The Selec-Trac system can be identified by five positions on the transfer case shift lever; the Command-Trac has only four positions. |
| (3) | Differential can be identified by a tag fastened on the housing by a cover bolt. The Dana has a 7.6" ring gear and is identified on the tag as a RBI 194. The Chrysler has a 8.25" ring gear and has its assembly number on the tag. |
| (4) | Includes 2.3 Qts. (2.2L) for coolant recovery bottle. |
WHEEL TIGHTENING
Tighten the lug nuts firmly in a crisscross pattern (Scheme 1) Tighten per following specifications. Always position wheel locking nut opposite valve stem in position indicated. (Scheme 1)
Tighten lug nuts in crisscross pattern to 85-110 ft. lbs. (115-149 N.m).
Scheme 1
Scheme 1: WHEEL TIGHTENING
BATTERY SPECIFICATIONS
| CAUTION | When battery is disconnected, vehicles equipped with computers may lose memory data. When battery power is restored, driveability problems may exist on some vehicles. These vehicles may require a relearn procedure. See the COMPUTER RELEARN PROCEDURES article in the GENERAL INFORMATION section. |
All gasoline engine equipped models use BCI group 58 batteries with 390 to 500 Cold Cranking Amp rating.
