Air Conditioning: Removal & Installation Jaguar XKR II рестайлинг

REMOVAL

Note. Removal steps in this procedure may contain installation details.

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

1. Refer to «Battery Disconnect and Connect»(ref-574738) information.
2. Raise and support the vehicle.
3. Refer to «Air Conditioning (A/C) System Recovery, Evacuation and Charging»(ref-574736-S17516479282013082800000) information.
4. See figure.
5. Torque: 8 Nm.
6. Torque: 9 Nm.
7. See figure.
8. Torque: 25 Nm.

INSTALLATION

1. To install, reverse the removal procedure.

Scheme 10

1. Remove the passenger side footwell trim panel. Remove the 3 clips.
2. Remove the blower motor resistor. Disconnect the electrical connector. Remove the 2 screws.

1. Install the blower motor resistor. Install the screws. Connect the electrical connector.
2. Install the passenger side footwell trim panel. Carefully secure the clips.

Note. Removal steps in this procedure may contain installation details.

Scheme 11

Scheme 12

1. Refer to «Battery Disconnect and Connect»(ref-574738) information.
2. Refer to «Air Conditioning (A/C) System Recovery, Evacuation and Charging»(ref-574736-S17516479282013082800000) information.
3. Raise and support the vehicle.
4. Refer to «Radiator Splash Shield»(ref-574757-S25401044362013082800000) information.
5. Torque: 5 Nm.
6. See figure.
7. Torque: 8 Nm.
8. Torque: 7 Nm.

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

1. Refer to «Battery Disconnect and Connect»(ref-574738) information.
2. Refer to «Air Conditioning (A/C) System Recovery, Evacuation and Charging»(ref-574736-S17516479282013082800000) information.
3. Raise and support the vehicle.
4. Refer to «Radiator Splash Shield»(ref-574757-S25401044362013082800000) information.
5. Refer to «Radiator»(ref-574753-S12799220512013082800000) information.
6. Torque: 8 Nm.
7. Torque: 7 Nm.

1. To install, reverse the removal procedure.

Scheme 13

Scheme 14

Scheme 15

Scheme 16

1. Remove the cover and disconnect the battery ground cable. Refer to «Specifications»(ref-574769) information.
2. Raise and support the vehicle.
3. Remove the TXV assembly. See «Thermostatic Expansion Valve»(ref-574794-S19525220972013082800000) .
4. Remove the A/C pipes. Release the clamp. Remove the 2 screws. Release the clip. Release the foam pad and the upper section of the clamp.
5. Remove the coolant pipe clamp. Remove the screw.
6. Carefully separate the evaporator housing. Remove the 4 screws. Remove the 10 clips. Release the blower motor harness clip. Release the 2 evaporator housing clips.
7. Remove the evaporator core. Carefully remove the evaporator core temperature sensor.

1. Install the evaporator core. Carefully install the evaporator core temperature sensor.
2. Install the evaporator housing cover. Install the clips. Install the screws.
3. Install the coolant pipe clamp. Install the screw.
4. Install the A/C pipes. Install the foam pad. Install the clamp. Install the screws.
5. Install the TXV assembly. See «Thermostatic Expansion Valve»(ref-574794-S19525220972013082800000) .
6. Connect the battery ground cable and install the cover. Refer to «Specifications»(ref-574769) information.

Scheme 17

Scheme 18

1. Remove the cover and disconnect the battery ground cable. Refer to «Specifications»(ref-574769) information.
2. Recover the A/C refrigerant.
3. Remove the engine cover. Refer to «Engine Cover»(ref-574758) information.
4. Remove the air intake duct. Remove the bolt. Release the 2 clips.
5. Remove the pressure cutoff switch. Disconnect the electrical connector. Remove and discard the O-ring seal.

1. Install the pressure cutoff switch. Clean the components. Install a new O-ring seal. Tighten the cutoff switch to 10 Nm (7 lb.ft). Connect the electrical connector.
2. Install the air intake duct. Tighten the clips. Tighten the bolt to 10 Nm (7 lb.ft).
3. Recharge the A/C system.
4. Install the engine cover. Refer to «Engine Cover»(ref-574758) information.
5. Connect the battery ground cable and install the cover. Refer to «Specifications»(ref-574769) information.

Scheme 19

1. Remove the cover and disconnect the battery ground cable. Refer to «Specifications»(ref-574769) information.
2. Raise and support the vehicle.
3. Remove the heater and evaporator core housing. Refer to «Heater Core and Evaporator Core Housing»(ref-574823-S25060203252013082800000) information.
4. Remove the TXV assembly. Carefully cut and release the insulation for access. Remove the 2 Allen bolts. Remove and discard the 4 O-ring seals.

1. Install the TXV assembly. Install the new O-ring seals. Install and tighten the Allen bolts to 6 Nm (4 lb.ft). Replace the TXV insulation.
2. Install the heater and evaporator core housing. Refer to «Heater Core and Evaporator Core Housing»(ref-574823-S25060203252013082800000) information.
3. Connect the battery ground cable and install the cover. Refer to «Specifications»(ref-574769) information.

Note. Removal steps in this procedure may contain installation details.

Scheme 20

Scheme 21

1. Raise and support the vehicle.
2. Refer to «Air Conditioning (A/C) System Recovery, Evacuation and Charging»(ref-574736-S17516479282013082800000) information.
3. Refer to «Radiator Splash Shield»(ref-574757-S25401044362013082800000) information.
4. See figure.
5. Torque: 12 Nm.
6. See figure.

1. To install, reverse the removal procedure.
