Specifications
| Item | Nm |
|---|
| Door glass into clamp - bolt | 8 |
| Door glass regulator motor to door - screw | 4 |
| Door glass regulator to door - nut/bolt | 8 |
| Door glass regulator to door - screw | 4 |
| Rear quarter glass, seal-carrier (coupe) - screw | 4 |
| Rear quarter glass, regulator motor (convertible) - nut | 9 |
Scheme 1
Scheme 1: COMPONENT LOCATION - WINDSHIELD AND BACKLIGHT
| Item Number | Description |
|---|
| A | Coupe |
| B | Convertible |
| 1 | Rain sensor mounting boss and interior mirror mounting button |
| 2 | Coupe backlight |
| 3 | Convertible backlight |
| 4 | Windshield |
Scheme 2
Scheme 2: COMPONENT LOCATION - DOOR GLASS AND REAR QUARTER GLASS MECHANISMS
| Item Number | Description |
|---|
| 1 | Passenger door module |
| 2 | Passenger window motor |
| 3 | Passenger door switch pack |
| 4 | RH quarter glass assembly (convertible only) |
| 5 | Auxiliary junction box |
| 6 | LH quarter glass assembly (convertible only) |
| 7 | Driver window motor |
| 8 | Driver door switch pack |
| 9 | Driver door module |
| 10 | Central Junction Box (CJB) |
Note. Convertible shown, coupe similar.
