Specifications
| Engine Description | Engine Capacity | Maximum Engine Torque (EEC) | Maximum Engine Power (EEC) | Maximum Engine Torque (SAE) | Maximum Engine Power (SAE) | Compression Ratio | Bore | Stroke |
|---|---|---|---|---|---|---|---|---|
| 90° 'Vee' 8 Cylinder 32 Valves | 4196 cm 3 | 560 Nm/413 lb/ft at 4000 RPM | 410 BHP/306 kW at 6250 RPM | 560 Nm/413 lb/ft at 4000 RPM | 420 BHP/313 kW at 6250 RPM | 9.1:1 ± 0.5:1 | 86.0 mm | 90.3 mm |
Engine Data
| Firing Order |
|---|
| 1 : 2 : 7 : 3 : 4 : 5 : 6 : 8 |
Engine Firing Order
| Intake Valve | Exhaust Valve |
|---|---|
| 0.18 - 0.22 mm | 0.23 - 0.27 mm |
Engine Valve Clearance (cold)
| Specification | Spark Plug Gap |
|---|---|
| AJ8 4575 | 0.9 - 1.0 mm |
Spark Plugs
| Description | Specification |
|---|---|
| Core plug and stub pipe retainer | WSK-M2G349-A4 |
| Engine oil, SAE 5W-30 | WSS-M2C-913B |
| Sealant | WSE-M4G323-A4 |
Lubricants, Fluids, Sealers and Adhesives
| Description | Liters |
|---|---|
| Engine oil, initial fill | 8.5 |
| Engine oil, service fill with oil filter change | 7.0 |
Capacities
| Item | Specification |
|---|---|
| Cylinder head maximum permitted warp (mm) | 0.125 |
| Valve guide inner diameter (mm) | 5.00 - 5.02 |
| Intake valve effective length (mm) | 88.87 - 89.17 |
| Exhaust valve effective length (mm) | 88.40 - 88.70 |
| Valve stem to guide clearance intake decimetrical (mm) | 0.022 - 0.057 |
| Valve stem to guide clearance exhaust decimetrical (mm) | 0.030 - 0.065 |
| Valve head diameter intake (mm) | 34.8 - 35.0 |
| Valve head diameter exhaust (mm) | 30.8 - 31.0 |
| Intake valve face angle (degrees) | 45° 15' 30" ± 7° 30' |
| Exhaust valve face angle (degrees) | 45° - 44° 45' |
| Valve stem diameter intake (mm) | 4.963 - 4.978 |
| Valve stem diameter exhaust (mm) | 4.955 - 4.970 |
| Valve spring free length (mm) | 43.5 MAX |
| Valve spring installed height (mm) | 33.20 |
| Camshaft lobe lift intake (mm) | 8.50 |
| Camshaft lobe lift exhaust (mm) | 8.50 |
| Camshaft journal to cylinder head bearing surface clearance diametrical (mm) | Front bearing 0.045 - 0.085 Other bearings 0.055 - 0.075 |
| Camshaft journal diameter standard runout limit (mm) | Center bearing to outer bearings 0.07 Other bearings to outer bearings 0.05 |
| Camshaft journal diameter standard out of round (mm) | 0.005 |
Cylinder head and Valvetrain
| Description | Nm |
|---|---|
| Accessory drive belt tensioner retaining bolt | 40 |
| Air conditioning compressor retaining bolts | 25 |
| Air conditioning compressor mounting bracket bolt | 25 |
| Camshaft bearing caps retaining bolts | 10 |
| Camshaft exhaust sprocket | A |
| Camshaft position sensor bolt | 7 |
| Connecting rod to bearing cap bolts | A |
| Coolant drain in engine block - plug M10 x 16 | 25 |
| Coolant pump bolt | 8 + 90° |
| Crankshaft damper pulley - bolt | 320 |
| Cylinder head - bolt | A |
| Engine cover (top) | 4 |
| Engine cover (top) mounting bracket - nut | 6 |
| Engine front cover retaining bolts | 12 |
| Engine mounting to engine mounting bracket - nut | 48 |
| Engine mounting to subframe - nut | 63 |
| Engine mounting bracket to engine - bolt | 40 |
| Engine wiring harness bracket - nut/bolt | 10 |
| Exhaust manifold - bolt | A |
| Exhaust manifold heat shield - bolt | 3 |
| Flexplate - bolt | A |
| Generator upper retaining bolts | 2 |
| Ignition coil retaining bolts | 5 |
| Intake manifold assembly retaining bolts | 21 |
| Intercoolers | 12 |
| Intercooler duct clamp plates | 21 |
| Knock sensor retaining nuts | 20 |
| Lifting eye (front) - bolt | 30 |
| Lifting eye (rear) - bolt | 40 |
| MAP sensor | 6 |
| Oil filter | 17 |
| Oil filter housing to engine - bolt | 21 |
| Oil level indicator tube - nut | 6 |
| Oil pan to oil pan body - bolt | A |
| Oil pan body to engine | A |
| Oil pan drain plug | 25 |
| Oil pump pick-up pipe to oil pan body - bolt | 12 |
| Oil pump to engine block - bolt | 12 |
| Oil pump to pick-up pipe - bolt | 12 |
| Piston cooling jet - bolt | 9 |
| Plug - M30 x 12 to engine block | 50 |
| Plug (flanged) - M30 - 1.5 x 20 to engine block | 50 |
| Power steering pump retaining bolts | 25 |
| Power steering pump bracket to engine - bolt | 28 |
| Primary timing chain tensioner - bolt | 12 |
| Primary timing chain tensioner, guide blade - bolt | 12 |
| Radio frequency interference suppressor to engine cover bracket - bolt | 10 |
| Secondary timing chain tensioner - bolt | 12 |
| Spark plugs | 27 |
| Starter motor retaining bolts | 43 |
| Supercharger | 21 |
| Supercharger outlet duct - bolt | 10 |
| Supercharger outlet duct - screw | 21 |
| Timing belt cover - bolt | A |
| Valve cover - bolt | A |
| Variable camshaft timing, oil control solenoid housing - bolt | 22 |
| Variable camshaft timing, oil control solenoid housing - nut | 11 |
| Variable camshaft timing sprocket - center bolt | A |
Torque Specifications
A = refer to procedure for correct torque sequence
