Engine Ignition: Removal & Installation Jaguar XKR II

Ignition System 5 illustrations ~316 words

Installation

  1. Install the spark plugs. Tighten the spark plugs to 28 Nm (21 lb.ft).
  2. Install the remaining coil-on-plugs.
  3. Install the ignition coil-on-plug. See «Ignition Coil-On-Plug - Vehicles Without: Supercharger»(ref-312589-S34676377062009041400000) .
  4. Connect the battery ground cable and install the cover. Refer to «Specifications»(ref-312564-S31890761012009041400000) article.

Removal

  1. Remove the ignition coil-on-plugs. See «Ignition Coil-On-Plug - Vehicles With: Supercharger»(ref-312589-S14866751932009041400000) .
  2. Remove the remaining ignition coil-on-plugs.
  3. Clean the area surrounding the spark plugs.
  4. Remove the spark plugs.
  1. Install the spark plugs. Tighten the spark plugs to 25 Nm (18 lb.ft).
  2. Install the remaining coil-on-plugs.
  3. Install the ignition coil-on-plug. See «Ignition Coil-On-Plug - Vehicles With: Supercharger»(ref-312589-S14866751932009041400000) .

Scheme 3

Scheme 3: Removal

Scheme 4

Scheme 4

Scheme 5

Scheme 5

Scheme 6

Scheme 6
  1. Remove the cover and disconnect the battery ground cable. Refer to «Specifications»(ref-312564-S31890761012009041400000) article.
  2. Remove the engine cover. Refer to «Engine Cover»(ref-312547-S27687687872009041400000) article.
  3. Remove the dipstick.
  4. Remove the ignition coil cover. Release from the 2 clips.
  5. Disconnect the ignition coil-on-plug electrical connector.
  6. Remove the ignition coil-on-plug. Remove the bolt.
  1. Install the ignition coil-on-plug. Tighten the bolt to 6 Nm (4 lb.ft).
  2. Connect and secure the electrical connector.
  3. Install the ignition coil-on-plug cover. Position and secure the clips.
  4. Install the dipstick.
  5. Install the engine cover. Refer to «Engine Cover»(ref-312547-S27687687872009041400000) article.
  6. Connect the battery ground cable and install the cover. Refer to «Specifications»(ref-312564-S31890761012009041400000) article.

Scheme 7

Scheme 7: Removal
  1. Remove the engine cover. Refer to «Engine Cover»(ref-312547-S27687687872009041400000) article.
  2. Remove the intake air resonator. Refer to «Intake Air Resonator»(ref-312577-S29213660842009041400000) article.
  3. Remove the oil level indicator.
  4. Remove the ignition coil cover. Release from the 2 clips.
  5. Disconnect the ignition coil-on-plug electrical connector.
  6. Remove the ignition coil-on-plug. Remove the bolt.
  1. Install the ignition coil-on-plug. Tighten the bolt to 6 Nm (4 lb.ft). Connect the electrical connector.
  2. Install the ignition coil-on-plug cover. Position and secure the clips.
  3. Install the oil level indicator.
  4. Install the intake air resonator. Refer to «Intake Air Resonator»(ref-312577-S29213660842009041400000) article.
  5. Install the engine cover. Refer to «Engine Cover»(ref-312547-S27687687872009041400000) article.
