Supercharger Cooling: Overview Jaguar XKR II

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

1. Raise and support the vehicle.
2. Drain the coolant. Refer to «Cooling System Draining, Filling and Bleeding - Vehicles With: Supercharger»(ref-312545-S38638734802009041400000) article.
3. Remove the fan cowl. Remove the 15 clips.
4. Disconnect the 2 coolant hoses. Release the clip. Disconnect the quick release connector.
5. Release the coolant pump. Remove the bolt.
6. Remove the radiator splash shield. Refer to «Radiator Splash Shield»(ref-312542-S16146995052009041400000) article.
7. Remove the front bumper air ducting. Remove the 7 clips. Release the 4 clips.
8. Remove the coolant pump. Disconnect the electrical connector. Release the clips and disconnect the 2 coolant hoses.
