Engine Cooling: Maintenance Jaguar XKR II

Cooling System Draining, Filling and Bleeding - General Procedures

Scheme 47

Scheme 48

Scheme 49

1. Open the hood.
2. Raise and support the vehicle.
3. Release the cooling system pressure. Remove the coolant expansion tank cap.
4. Drain the coolant. Position a container to collect the fluid. Remove the drain plug.
5. Install the drain plug.
6. Loosen the coolant expansion tank bleed screw.
7. Refill the cooling system. When coolant runs from the expansion tank bleed point bubble-free, tighten the bleed screw.
8. Install the coolant expansion tank cap.
9. Set the heater controls to maximum.
10. Start the engine and idle until hot air is emitted at the face registers.
11. Switch the engine off and allow to cool.
12. Check and top-up the coolant if required.
13. Close the hood.

Cooling System Draining, Filling and Bleeding - General Procedures (Vehicles With: Supercharger)

Scheme 50

1. Open the hood.
2. Raise and support the vehicle.
3. Release the cooling system pressure. Remove the coolant expansion tank cap.
4. Drain the coolant. Position a container to collect the fluid. Remove the drain plug.
5. Install the drain plug.
6. Loosen the coolant expansion tank bleed screw.
7. Refill the cooling system. When coolant runs from the expansion tank bleed point bubble-free, tighten the bleed screw.
8. Install the coolant expansion tank cap.
9. Remove the engine cover. Refer to «Engine Cover»(ref-312547-S27687687872009041400000) article.
10. Remove the supercharger coolant filler plug. Remove and discard the sealing washer.
11. Switch the ignition on.
12. Allow the supercharger pump to run and top-up the coolant through the supercharger fill port. Switch the ignition off.
13. Install the supercharger coolant fill plug and tighten to 45 Nm (33 lb.ft). Clean the components. Install a new sealing washer.
14. Install the engine cover. Refer to «Engine Cover»(ref-312547-S27687687872009041400000) article.
15. Set the heater controls to maximum.
16. Start the engine and idle until hot air is emitted at the face registers.
17. Switch the engine off and allow to cool.
18. Check and top-up the coolant if required.
19. Close the hood.

Cooling System Draining and Vacuum Filling - General Procedures

Note. Vehicles fitted with supercharged engines shown, V8 NA and V6 engines similar.

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

1. Set the heater controls to maximum HOT.
2. Open the hood.
3. Remove the coolant expansion tank cap.
4. Raise and support the vehicle.
5. Remove the radiator undertray. Refer to «Radiator Splash Shield»(ref-312542-S16146995052009041400000) article.
6. Remove the coolant drain plug. Drain the coolant into a suitable container.
7. Disconnect the coolant lower hose from the supercharger radiator. Release the clip. Allow the coolant to drain.
8. Install the drain plug. Remove the drain tray.
9. Connect the supercharger radiator lower coolant hose.
10. Install the radiator undertray. Refer to «Radiator Splash Shield»(ref-312542-S16146995052009041400000) article.
11. Lower the vehicle.
12. Prepare a sufficient amount of coolant to the specified concentration.
13. Install the cooling system vacuum refill adaptor to the expansion tank.
14. Install the vacuum filler gauge to the cooling system vacuum refill adaptor.
15. Install the venturi tube assembly to the vacuum filler gauge.
16. Connect a regulated compressed air supply to the venturi tube assembly.
17. Position the evacuated air hose into a container.
18. Open the air supply valve.
19. Open the coolant supply valve for 2 seconds to prime the coolant supply hose.
20. Apply air pressure progressively until the arrow on the vacuum filler gauge reaches the green segment. Allow the vacuum to rebuild. Close the air supply valve. Allow one minute to check the vacuum is held.
21. Disconnect the compressed air supply line.
22. Open the coolant supply valve and allow the coolant to be drawn into the system.
23. Remove the vacuum filler gauge and cooling system vacuum refill adaptor assembly.
24. Install the coolant expansion tank cap.
25. Remove the engine cover. Refer to «Engine Cover»(ref-312547-S27687687872009041400000) article.
26. Remove the supercharger coolant fill plug. Remove and discard the sealing washer.
27. Switch the ignition on.
28. Allow the supercharger pump to run and top-up the coolant through the supercharger fill port. Switch the ignition off.
29. Install the supercharger coolant fill plug. Clean the components. Install a new sealing washer. Tighten to 45 Nm (33 lb.ft).
30. Install the engine cover. Refer to «Engine Cover»(ref-312547-S27687687872009041400000) article.
31. Start the engine and idle until hot air is emitted at the face registers.
32. Switch the engine off and allow to cool.
33. Check and top-up the coolant if required.
34. Close the hood.

Scheme 59

Scheme 60

1. Remove the air cleaner. Refer to «Intake Air Distribution and Filtering»(ref-312577) article.
2. Remove the air cleaner. Refer to «Intake Air Distribution and Filtering»(ref-312594) article.
3. Remove the thermostat. Refer to «Thermostat - Removal and Installation (Vehicles With: Supercharger)»(ref-312545-S37224791872009041400000) or «Thermostat - Removal and Installation (Vehicles Without: Supercharger)»(ref-312545-S09078879672009041400000) .
4. Detach the lower coolant hose from the radiator and position to one side.
5. Detach the upper coolant hose from the radiator. NOTE: To remove rust, sludge and other foreign material from the cooling system, use Premium Cooling System flush, meeting Jaguar specification EGR-M14P7-A, which is safe for use with aluminum cooling systems. This cleaning restores cooling system efficiency and helps prevent overheating. NOTE: In severe cases where cleaning solvents will not properly clean the cooling system, it will be necessary to use the pressure flushing method using Cooling System Flusher, 164-R3670 to restore efficient operation. NOTE: A pulsating or reversed direction of flushing water will loosen sediment more quickly than a steady flow in the normal coolant flow direction. NOTE: Dispose of old coolant and flushing water contaminated with coolant and cleaning chemicals in accordance with local, state and federal laws.
6. Connect a hose pipe to the radiator upper coolant hose connection using a suitable connector.
7. Flush the radiator using the hose pipe until the coolant flowing from the radiator lower coolant hose connection is clear.
8. Remove the hose pipe from the radiator upper coolant hose connection.
9. Connect a hose pipe to the upper coolant hose using a suitable connector.
10. Flush the engine using the hose pipe until the coolant flowing from the radiator lower coolant hose is clear.
11. Remove the hose pipe from the upper coolant hose connection.
12. Connect the upper coolant hose to the radiator.
13. Connect the lower coolant hose to the radiator.
14. Install the thermostat. Refer to «Thermostat - Removal and Installation (Vehicles With: Supercharger)»(ref-312545-S37224791872009041400000) .
15. Fill the cooling system. Refer to «Cooling System Draining, Filling and Bleeding - General Procedures»(ref-312545-S22371452422009041400000) .
16. Install the air cleaner. Refer to «Intake Air Distribution and Filtering»(ref-312577) article.
17. Install the air cleaner. Refer to «Intake Air Distribution and Filtering»(ref-312594) article.
