DOOR WINDOW GLASS ADJUSTMENT

Note. Final door glass alignment or adjustment, can be carried out without the need to remove the interior door trim panel.

Scheme 1

Scheme 2

Scheme 3

Scheme 4

1. Check the alignment of the front door glass.
2. Open the door.
3. Remove the 4 screw covers.
4. Using a 4mm Allen key, rotate the side adjusters clockwise until they reach the end of their travel. From this position, turn the adjuster screws counter-clockwise for 5 revolutions.
5. Make sure that the door window glass is aligned correctly to the seal as illustrated. If the alignment is incorrect, repeat Step 4 before carrying on with the procedure.
6. Using a extended 5mm Allen key, rotate the lower adjusters to adjust the glass height and achieve a parallel 8mm gap between the rear quarter and the door.
7. Install the screw covers.
8. Check the alignment of the front door glass.
9. When the window glass adjustment is complete the window motor will need to be calibrated, to do this power the window fully up and continue to hold the switch for a further 3 seconds.

Scheme 5

Scheme 6

1. Raise the window glass.
2. Remove the cover and disconnect the battery ground cable. Refer to «Specifications»(ref-574738-S14876381072013082800000) information.
3. Remove the front door trim panel. Refer to «Front Door Trim Panel»(ref-574758-S38218994702013082800000) information.
4. Remove the window regulator motor. Disconnect the electrical connector. Remove the 3 Torx screws.
5. Release the front door inner weathershield. Disconnect the 3 electrical connectors. Release the 9 wiring harness clips.
6. Remove the front door inner weathershield. Remove the 12 Torx bolts. Release the front door interior handle cable.
7. Remove the front door window glass. Remove the 2 Torx bolts. Collect the clamp and rubber washer.

Scheme 7

1. Install the front door window glass. Attach the clamp and rubber washer. Install the Torx bolts, but do not tighten fully at this stage.
2. Align the front door window glass longitudinally. Position the window, forwards or rearwards, glass edge should be 44mm from edge of door as shown in dimension 'A'. Tighten the Torx bolts to 8 Nm (6 lb.ft).
3. Align the front door window glass horizontally. Release the retaining nut. Align the glass to door, glass should be 12mm from door as shown in dimension 'B'. Tighten the retaining nut to 10 Nm (7 lb.ft).
4. Install the front door inner weathershield. Attach the front door interior handle cable. Tighten the Torx bolt to 10 Nm (7 lb.ft).
5. Secure the front door inner weathershield. Secure the wiring harness clips. Connect the electrical connectors.
6. Install the window regulator motor. Install and tighten the Torx screws. Connect the electrical connector.
7. Install the front door trim panel. Refer to «Front Door Trim Panel»(ref-574758-S38218994702013082800000) information.
8. Connect the battery ground cable and install the cover. Refer to «Specifications»(ref-574738-S14876381072013082800000) information.
