Uni-Body, Subframe and Mounting System: Removal & Installation Jaguar XKR II рестайлинг 2

REMOVAL

Note. Removal steps in this procedure may contain installation details.

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

1. Refer to «BATTERY DISCONNECT AND CONNECT»(ref-574738-S14717774632013090500000) information.
2. Raise and support the vehicle.
3. Refer to «Radiator Splash Shield»(ref-574757-S25401044362013082800000) information.
4. Refer to «Air Deflector»(ref-574757-S24500562812013082800000) information.
5. Refer to «Wheel Knuckle»(ref-574795-S08999002432013082800000) information.
6. Torque: 45 Nm
7. Refer to «Steering Gear»(ref-574734-S20306494142013082800000) information.
8. Torque: 5 Nm
9. Lower the vehicle.
10. Secure the radiator assembly.
11. Engine Lifting Bracket Front (303-1435)
12. Support the engine. Engine support bracket (303-021) Support Beam Arm and Hook Assembly, Engine (303-662)
13. Raise and support the vehicle.
14. General Equipment: Powertrain Jack
15. Torque: Front retaining bolts Stage 1: 80 Nm Stage 2: 360° Rear retaining bolts Stage 1: 80 Nm Stage 2: 270°
16. Torque: 175 Nm
17. Torque: 175 Nm

INSTALLATION

1. To install, reverse the removal procedure.
2. Refer to «Four-Wheel Alignment»(ref-574800-S24129730952013082800000) information.

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

1. Raise and support the vehicle.
2. Refer to «Wheel and Tire»(ref-574735-S33552714542013082800000) information.
3. Refer to «Battery Disconnect and Connect»(ref-574738) information.
4. Refer to «Driveshaft - 5.0L»(ref-574748-S10655803592013082800000) information.
5. Torque: 10 Nm
6. Using the special tool, press and hold the brake pedal.
7. Torque: 35 Nm
8. Torque: M10 40 Nm M12 133 Nm
9. Torque: 133 Nm
10. General Equipment: Powertrain Jack Torque: Stage 1: 60 Nm Stage 2: 240°

1. To install, reverse the removal procedure.
2. Refer to «Brake System Bleeding»(ref-574801-S39987699602013082800000) information.
3. Refer to «Rear Toe Adjustment»(ref-574800-S26262565432013082800000) information.

All vehicles

Scheme 28

1. Using the special tools, Install the new front bushings.
2. Install the rear subframe. Refer to «Rear Subframe - 4.2L»(ref-574796-S15097980072013082800000) . .
3. Install the rear subframe. Refer to «Rear Subframe - 5.0L»(ref-574796-S01183477002013082800000) .
4. Connect the battery ground cable. Refer to «Specifications»(ref-574738-S14876381072013082800000) information.

1. Disconnect the battery ground cable. Refer to «Specifications»(ref-574738-S14876381072013082800000) information.
2. Raise and support the vehicle.
3. Remove the rear subframe assembly. Refer to «Rear Subframe - 4.2L»(ref-574796-S15097980072013082800000) . .
4. Remove the rear subframe assembly. Refer to «Rear Subframe - 5.0L»(ref-574796-S01183477002013082800000) .
5. Using the special tools, remove and discard the rear subframe rear bushing.

1. Using the special tools, Install the new rear bushings.
2. Install the rear subframe. Refer to «Rear Subframe - 4.2L»(ref-574796-S15097980072013082800000) . .
3. Install the rear subframe. Refer to «Rear Subframe - 5.0L»(ref-574796-S01183477002013082800000) .
4. Connect the battery ground cable. Refer to «Specifications»(ref-574738-S14876381072013082800000) information.
