Uni-Body, Subframe and Mounting System: Other Jaguar XKR II рестайлинг 2

Frames, Subframes & Crossmembers 1 illustration

REAR SUBFRAME FRONT BUSHING

Special Tools

204-469 Forcing bolt 204-479 Remover support 204-481 Reciever-bush 204-482 Remover-bush 204-480 Support-bush 204-483 Installer-bush

Scheme 29

Scheme 29: REMOVAL
Scheme 29: REMOVAL
  1. Disconnect the battery ground cable. Refer to «Specifications»(ref-574738-S14876381072013082800000) information.
  2. Raise and support the vehicle.
  3. Remove the rear subframe assembly. Refer to «Rear Subframe - 4.2L»(ref-574796-S15097980072013082800000) . .
  4. Remove the rear subframe assembly. Refer to «Rear Subframe - 5.0L»(ref-574796-S01183477002013082800000) .
  5. Using the special tools, remove and discard the rear subframe front bushing.

REAR SUBFRAME REAR BUSHING

Special Tools

204-469 Forcing bolt 204-475 Reciever-bush 204-474 Replacer-bush 204-473 Remover bush 204-472 Remover support-bush
