Acceleration Control: Removal & Installation Jaguar XKR I рестайлинг

Removal

Note. Right-hand drive vehicles shown, left-hand drive vehicles similar.

Scheme 37

Scheme 38

1. Remove and discard the accelerator cable retaining sleeve split pin.
2. Detach the accelerator cable. Remove the accelerator cable retaining sleeve. Detach the accelerator cable.
3. Remove the driver side bulkhead cover.
4. Open the accelerator pedal position (APP) sensor cover. Release the APP sensor cover retaining clip. Open the APP sensor cover.
5. Detach the accelerator cable.
6. Detach the accelerator inner cable.
7. Remove the accelerator cable.

Scheme 39

1. Install the accelerator cable.
2. Attach the accelerator inner cable.
3. Attach the accelerator cable.
4. Attach the accelerator cable retaining sleeve. Attach the accelerator cable. Install the accelerator cable retaining sleeve.
5. Install a new accelerator cable retaining sleeve split pin.
6. Adjust the accelerator cable. Refer to «Accelerator Cable Adjustment - General Procedures»(ref-311062-S08614496142009032300000) .

All vehicles

1. Remove and discard the accelerator cable retaining sleeve split pin.
2. Detach the accelerator cable. Remove the accelerator cable retaining sleeve. Detach the accelerator cable.

Right-hand drive vehicles

Scheme 40

1. Remove the accelerator pedal.

Left-hand drive vehicles

Scheme 41

1. Remove the kickdown plunger.
2. Remove the accelerator pedal retaining bolts. Reposition the floor covering to gain access to the accelerator pedal lower retaining bolt.
3. Remove the accelerator pedal. Reposition the floor covering to gain access to the accelerator pedal.

Installation

All vehicles

1. To install, reverse the removal procedure.

Right-hand drive vehicles

1. Tighten to 9 Nm.

Left-hand drive vehicles

1. Tighten to 9 Nm.

All vehicles

1. Adjust the accelerator cable. Refer to «Accelerator Cable Adjustment - General Procedures»(ref-311062-S08614496142009032300000) .
