Acceleration Control: Adjustments Jaguar XKR I рестайлинг

Accelerator Cable Adjustment - General Procedures

Special Tools Tool Illustration Tool Name Tool Number Accelerator cable adjustment tool 310-101

Note. Right-hand drive vehicles shown, left-hand drive vehicles similar.

Scheme 34

Scheme 35

Scheme 36

1. Make sure the kickdown plunger is fully seated to the retaining stud shoulder.
2. Remove the driver side bulkhead cover.
3. Open the accelerator pedal position (APP) sensor cover. Release the APP sensor cover retaining clip. Open the APP sensor cover.
4. Tension the accelerator cable. Remove the accelerator outer cable retaining clip. NOTE: Make sure 14 teeth are visible on the outer cable. Tension the accelerator cable
5. Install the accelerator outer cable retaining clip.
6. Install the special tool to the APP sensor.
7. Using the special tool adjust the accelerator cable. Slowly press the accelerator pedal through kickdown to the floor, and hold for five seconds.
8. Release the accelerator pedal.
9. Make sure the APP sensor cam is at the idle position.
10. Remove the special tool.
11. Close the APP sensor cover.
12. Install the driver side bulkhead cover.
