Specifications
| Description | Specification |
|---|---|
| Jaguar Premium Cooling System Fluid | WSS M97B44-D |
| Jaguar Premium Cooling System Flush | EGR-M14P7-A |
| Jaguar Premium Cooling System Flush | 164-R3670 |
Lubricants, Fluids, Sealers and Adhesives
| Engine | Capacity |
|---|---|
| 4.2L - Vehicles without supercharger | 9.5 Liters |
| 4.2L - Vehicles with supercharger | 11.5 Liters |
Cooling System Refill Capacities
| Description | Nm |
|---|---|
| Coolant expansion tank retaining nut | 3 |
| Cooling fan motor and shroud retaining nuts | 4 |
| Thermostat housing retaining bolts | 9 |
| Water pump retaining bolts | A |
| Water pump drive pulley retaining bolts | A |
| Radiator drain plug | 1 |
| Radiator retaining bracket | 10 |
| Filler plug - Vehicles with supercharger | 45 |
| A = refer to the procedure for the correct torque sequence |
Torque Specifications
Scheme 1
| Item | Description |
|---|---|
| 1 | Cooling fan motors and shroud |
| 2 | Thermostat housing |
| 3 | Water pump |
| 4 | Throttle body |
| 5 | Heater water pump |
| 6 | Heater core |
| 7 | Water valve |
| 8 | Expansion tank |
| 9 | Degas bottle |
| 10 | Radiator |
Engine cooling is via a low volume, high velocity system which achieves a very fast warm up. The temperature of the combustion chambers is reduced along with a more even temperature distribution. The temperature of the bores is increased.
From the pump, coolant flows into each bank of the cylinder block. In each bank, approximately 50% of the coolant cools the cylinder bores and the remainder is diverted through the bypass gallery to the cylinder head.
With the thermostat closed, coolant returns directly to the pump through the bypass on the thermostat housing.
With the thermostat open, coolant returns to the pump via the radiator.
The cooling system uses a mixture of soft water and Jaguar Anti-Freeze/Inhibitor (WSS M97B44-D).
