SPECIFICATIONS
| Description | Nm |
|---|---|
| Camshaft position (CMP) sensor(s) retaining bolt | 10 |
| Heated oxygen sensor (H02S) | 48 |
| Catalyst monitor sensor | 48 |
| Crankshaft position (CKP) sensor retaining bolt | 10 |
| Knock sensor(s) (KS) retaining bolt | 20 |
| Fuel rail pressure (FRP) sensor | 32 |
| Manifold Absolute Pressure and Temperature (MAPT) Sensor | 5 |
| Engine Oil Level Sensor retaining bolts | 11 |
| Variable Valve Timing (VVT) Oil Control Solenoid(s) retaining bolts | 10 |
| Engine Control Module (ECM) retaining bolts | 7 |
| Fuse box retaining screws | 4 |
| Engine wiring harness connector bolt | 3 |
| Engine wiring harness retaining bracket bolts | 6 |
| ECM retaining bracket bolts | 7 |
TORQUE SPECIFICATIONS
Scheme 1
| Item Number | Description |
|---|---|
| 1 | MAFT (mass air flow and temperature) sensor |
| 2 | CMP (camshaft position) sensors |
| 3 | MAP (manifold absolute pressure) sensor |
| 4 | Knock sensors |
| 5 | CKP (crankshaft position) sensor |
| 6 | CMP sensors |
| 7 | MAFT sensor |
| 8 | ECT (engine coolant temperature) sensor (ECT 2) |
| 9 | Electronic throttle |
Scheme 2
| Item Number | Description |
|---|---|
| 1 | ECT sensor (ECT 1) |
| 2 | Upstream HO2S (heated oxygen sensor) |
| 3 | Downstream HO2S |
| 4 | Downstream HO2S |
| 5 | Upstream HO2S |
| 6 | ECM (engine control module) |
Scheme 3
| Item Number | Description |
|---|---|
| 1 | AAT (ambient air temperature) sensor |
| 2 | APP (accelerator pedal position) sensor |
