SPECIFICATIONS
| Item | Nm |
|---|
| Driver seat module (DSM) retaining bolts | 10 |
| Information and entertainment module retaining bolts | 6 |
Scheme 1
Scheme 1: COMPONENT LOCATION - MOST BUS
| Item Number | Description |
|---|
| 1 | Information and entertainment module |
| 2 | TSD (touch screen display) |
| 3 | Integrated audio module |
| 4 | Software download socket |
| 5 | Auxiliary USB (universal serial bus) unit |
| 6 | Cellular phone module |
| 7 | Navigation computer |
| 8 | SDARS/DAB (satellite digital audio radio service/digital audio broadcasting) module (where fitted) |
| 9 | Audio amplifier |
Scheme 2
Scheme 2: COMPONENT LOCATION - LIN AND PRIVATE CAN BUSES
| Item Number | Description |
|---|
| 1 | LH (left hand) temperature blend stepper motor |
| 2 | Face/Feet distribution stepper motor |
| 3 | RH (right hand) temperature blend stepper motor |
| 4 | Windshield distribution (defrost) stepper motor |
| 5 | Instrument cluster |
| 6 | Driver seat switch pack |
| 7 | Driver door module |
| 8 | Driver seat module |
| 9 | Passenger seat module |
| 10 | Passenger seat switch pack |
| 11 | ATC (automatic temperature control) module |
Scheme 3
Scheme 3: COMPONENT LOCATION - LIN BUS (CONTINUED)
| Item Number | Description |
|---|
| 1 | Adaptive speed control sensor |
| 2 | Battery backed sounder |
| 3 | Adaptive speed control module |
| 4 | Clockspring |
| 5 | Driver door switch pack |
| 6 | Engine start control module |
| 7 | Steering wheel audio switch module |
| 8 | Yaw rate/acceleration sensor |
| 9 | CJB (central junction box) |
| 10 | ABS (anti-lock brake system) module |
Scheme 4
Scheme 4: COMPONENT LOCATION - MEDIUM SPEED CAN BUS
| Item Number | Description |
|---|
| 1 | ATC module |
| 2 | Information and entertainment module |
| 3 | Integrated control panel |
| 4 | Instrument cluster |
| 5 | Seat climate control module |
| 6 | Keyless vehicle module |
| 7 | Driver door module |
| 8 | Diagnostic socket |
| 9 | Driver seat module |
| 10 | AJB (auxiliary junction box) |
| 11 | TPMS (tire pressure monitoring system) module |
| 12 | Convertible top control module (convertible vehicle only) |
| 13 | Passenger seat module |
| 14 | Passenger door module |
| 15 | CJB |
| 16 | Parking aid module |
Scheme 5
Scheme 5: COMPONENT LOCATION - HIGH SPEED CAN BUS
| Item Number | Description |
|---|
| 1 | ECM (engine control module) |
| 2 | Steering column lock |
| 3 | Adaptive front lighting module |
| 4 | Instrument cluster |
| 5 | Adaptive speed control module |
| 6 | Diagnostic socket |
| 7 | RCM (restraints control module) |
| 8 | ADCM (active damping control module) |
| 9 | EPB (electric park brake) module |
| 10 | DLM (differential locking module) |
| 11 | JaguarDrive selector module |
| 12 | Occupancy sensor module |
| 13 | TCM (transmission control module) |
| 14 | ABS module |
| 15 | Pedestrian protection system module |
