Multifunction Electronic Modules: Removal & Installation Jaguar XJ X351

Communication Devices 8 illustrations ~218 words

REMOVAL

Note. Removal steps in this procedure may contain installation details.

Scheme 28

Scheme 28: REMOVAL
Scheme 28: REMOVAL
  1. Refer to «Battery Disconnect and Connect»(ref-570102-S06137827622013080600000) information.
  2. Refer to «Front Door Trim Panel»(ref-570108-S21223716802013080600000) information.
  3. See figure.

INSTALLATION

  1. To install, reverse the removal procedure.
  2. If a new component has been installed, configure using Jaguar approved diagnostic tool.
WARNINGTo avoid accidental deployment, the restraints control module backup power supply must be depleted. Wait at least one minute after disconnecting the battery ground cable(s) before commencing any repair or adjustment to the supplemental restraint system (SRS), or any component(s) adjacent to the SRS sensors. Failure to follow these instructions may result in personal injury.
WARNINGAlways wear safety glasses when working on an air bag equipped vehicle and when handling an air bag module. Failure to follow this instruction may result in personal injury.
WARNINGTo minimize the possibility of premature deployment, do not use radio key code savers when working on the supplemental restraint system. Failure to follow this instruction may result in personal injury.
WARNINGTo minimize the possibility of injury in the event of premature deployment, always carry a live air bag module with the bag and trim cover pointed away from the body. Failure to follow this instruction may result in personal injury.
WARNINGTo minimize the possibility of premature deployment, live air bag modules must only be placed on work benches which have been ground bonded and with the trim cover facing up. Failure to follow these instructions may result in personal injury.
WARNINGNever probe the electrical connectors of air bag modules or any other supplemental restraint system component. Failure to follow this instruction may result in personal injury.
WARNINGPainting over the driver air bag module trim cover or instrument panel could lead to deterioration of the trim cover and air bags. Do not for any reason attempt to paint discolored or damaged air bag module trim covers or instrument panel. Install a new component. Failure to follow this instruction may result in personal injury.

Note. Some variation in the illustrations may occur, but the essential information is always correct.

Note. Removal steps in this procedure may contain installation details.

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34
  1. Refer to «Supplemental Restraint System (SRS) Health and Safety Precautions»(ref-570070-S23860894702013080600000) information.
  2. See figure.
  3. Torque: 47 Nm.
  4. See figure.
  5. Torque: 47 Nm.
  6. Reposition the front seat to the central position.
  7. See figure.
  8. Torque: 3 Nm.
  1. To install, reverse the removal procedure.
  2. If a new component has been installed, configure using Jaguar approved diagnostic equipment.

Note. Removal steps in this procedure may contain installation details.

  1. Refer to «Battery Disconnect and Connect»(ref-570102-S06137827622013080600000) information.
  2. Refer to «Front Door Trim Panel»(ref-570108-S21223716802013080600000) information.
  3. See figure.
  1. To install, reverse the removal procedure.
  2. If a new component has been installed, configure using Jaguar approved diagnostic tool.

Note. Removal steps in this procedure may contain installation details.

Scheme 35

Scheme 35: REMOVAL
Scheme 35: REMOVAL
  1. Refer to «Rear Door Trim Panel»(ref-570108-S14215828812013080600000) information.
  2. Torque: 1.5 Nm.
  1. To install, reverse the removal procedure.
