Filling: Overview Jaguar XFR I

1. Refer to: «Radiator Splash Shield»(ref-568406-S39527244732013072200000)
2. Lower the vehicle.
3. Fill the cooling system, keeping coolant to the upper level mark of the expansion tank until a steady stream of coolant is seen running from the coolant hose bleed point.
4. Continue to fill the coolant until the maximum level is reached.
5. Set the heater controls to maximum.
6. Start engine and increase speed to 2000 rpm for 2 minutes.
7. Continue to top-up with coolant with engine idling until hot air is emitted from face vents. When hot air is emitted from the vents, switch the heater off. Go to Step 10.
8. If no hot air is emitted, turn the engine off for 10 seconds and the start the engine and return to Step 7.
9. Continue to fill the coolant until the maximum level is reached.
10. Switch the heater off.
11. Raise the engine speed to 2000 rpm for eight minutes.
12. Switch the engine off and allow to cool.
13. Visually check the engine and cooling system for signs of coolant leakage.
14. Check and top-up the coolant if required.

Scheme 22

1. Raise and support the vehicle.
2. Refer to: «Secondary Bulkhead Center Panel»(ref-568406-S23451519502013072200000)
3. Refer to: «Air Deflector»(ref-568406-S42840487662013072200000)
4. Refer to: «Radiator Splash Shield»(ref-568406-S39527244732013072200000)
5. Torque: 2 Nm
6. Torque: 50 Nm
7. Carry out the procedure up to step 1 in the filling section three times, filling the cooling system with clean water at the first two drains. At the third refill, use a suitable measuring tool to make sure that the cooling system maintains a 50% mix.

Scheme 23

1. Fill the cooling system, keeping coolant to the upper level mark of the expansion tank until a steady stream of coolant is seen running from the coolant hose bleed point.
2. Continue to fill the coolant until the maximum level is reached.
3. Set the heater controls to maximum.
4. Start engine and increase speed to 2000 rpm for 2 minutes.
5. Continue to top-up with coolant with engine idling until hot air is emitted from face vents. When hot air is emitted from the vents, switch the heater off. Go to Step 10.
6. If no hot air is emitted, turn the engine off for 10 seconds and the start the engine and return to Step 7.
7. Continue to fill the coolant until the maximum level is reached.
8. Switch the heater off.
9. Raise the engine speed to 2000 rpm for eight minutes.
10. Switch the engine off and allow to cool.
11. Visually check the engine and cooling system for signs of coolant leakage.
12. Check and top-up the coolant system as required when cool.
13. Refer to: «Air Deflector»(ref-568406-S42840487662013072200000)
14. Refer to: «Radiator Splash Shield»(ref-568406-S39527244732013072200000)
15. Refer to: «Secondary Bulkhead Center Panel»(ref-568406-S23451519502013072200000)
