Component Location Jaguar XFR I

Cooling Fan 3 illustrations

Component Location - Sheet 1 Of 2 (Naturally Aspirated Vehicles)

Scheme 1

Scheme 1: COMPONENT LOCATION
Item NumberDescription
1Coolant expansion tank
2Coolant supply/expansion hose
3Bleed screw
4Engine oil cooler
5Engine block heater (110 V version shown) or drain plug
6Engine vent hose
7Throttle
8Radiator upper hose
9Transmission fluid cooler
10Transmission fluid cooler supply and return hoses
11Heater core supply and return hoses
12Throttle body heater hose
13Heater manifold
14Cooling fan
15Radiator lower hose
16Thermostat
17Coolant pump
18Radiator
19Outlet tube

Component Location - Sheet 1 Of 2 (Supercharger Vehicles)

Scheme 2

Scheme 2
Item NumberDescription
1Engine vent hose
2Throttle
3Coolant expansion tank
4Bleed point
5Throttle body heater hose
6Engine oil cooler
7Engine block heater (110 V version shown) or drain plug
8Coolant supply/expansion hose
9Outlet tube
10Radiator upper hose
11Supercharger cooling system connecting hose
12Auxiliary radiator supply hose
13Auxiliary radiator return hose
14Auxiliary radiator
15Transmission fluid cooler supply and return hoses
16Transmission fluid cooler
17Heater core supply and return hoses
18Heater manifold
19Radiator lower hose
20Cooling fan
21Thermostat
22Coolant pump
23Radiator

Component Location - Sheet 2 Of 2

Scheme 3

Scheme 3
Item NumberDescription
1Engine block heater NOTE: 110 V ac version shown, 240 V ac version similar.
2Harness
3Connector
NOTE
110 V ac version shown, 240 V ac version similar.
