Glass, Frames and Mechanisms: Removal & Installation Jaguar XF I

INSTALLATION

1. To install, reverse the removal procedure.

Scheme 1

Scheme 2

1. To install, reverse the removal procedure.

1. To install, reverse the removal procedure.

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

1. Lower the rear door window glass.
2. Remove the rear door trim panel. Refer to «Rear Door Trim Panel»(ref-568405-S08079644482013072200000) information.

1. To install, reverse the removal procedure.
2. Tighten the Torx screws securing the fixed window glass after alignment of the bright external trim.

Scheme 15

1. Refer to: «Rear Door Fixed Window Glass»(ref-568438-S41470092542013072200000) .
2. Refer to: «Rear Door Window Regulator and Motor»(ref-568438-S42044856842013072200000) .

1. To install, reverse the removal procedure.

REMOVAL

Note. Removal steps in this procedure may contain installation details.

Scheme 16

Scheme 17

1. Remove the rear door speaker. Refer to «Rear Door Speaker»(ref-568413-S01207022602013072200000) information.
2. Torque: 7 Nm

1. To install, reverse the removal procedure.

Note. The following equipment is required: l Cutting wire and handles l Kent knife l Glazing knife l Windshield replacement kit l Sealant applicator gun l Suction cups l A felt covered table or stand to support glass

Scheme 18

Scheme 19

Scheme 20

Scheme 21

1. Refer to «C-Pillar Trim Panel»(ref-568405-S37189186262013072200000) information.
2. Remove the polyurethane (PU) adhesive cap and heat the PU adhesive for a minimum of 30 minutes.

Scheme 22

Scheme 23

Scheme 24

Scheme 25

1. Prepare the window glass, window glass flange and trimmed PU adhesive in accordance with the instructions included with the PU adhesive kit.
2. If water is used as a means for the leak check, then allow sealant to dry before testing. Spray water around the windshield glass, mark any area that leaks. Dry the windshield glass and sealant before applying additional sealant.
3. Refer to «C-Pillar Trim Panel»(ref-568405-S37189186262013072200000) information.

Note. Removal steps in this procedure may contain installation details.

Scheme 26

Scheme 27

Scheme 28

1. Refer to «Cowl Vent Screen»(ref-568406-S32289223332013072200000) information.
2. Refer to «A-Pillar Trim Panel»(ref-568405-S17127503202013072200000) information.
3. Refer to «Rain Sensor»(ref-568432-S23450846742013072200000) information.
4. Remove the polyurethane (PU) adhesive cap and heat the PU adhesive for a minimum of 30 minutes.

Scheme 29

Scheme 30

Scheme 31

Scheme 32

1. Prepare the window glass, window glass flange and trimmed PU adhesive in accordance with the instructions included with the PU adhesive kit.
2. If the ambient temperature falls below 10 degrees C, apply warm air (25 degrees C) continuously for 15 minutes.
3. If water is used as a means for the leak check, then allow sealant to dry before testing. Spray water around the windshield glass, mark any area that leaks. Dry the windshield glass and sealant before applying additional sealant.
4. Refer to «Rain Sensor»(ref-568432-S23450846742013072200000) information.
5. Refer to «A-Pillar Trim Panel»(ref-568405-S17127503202013072200000) information.
6. Refer to «Cowl Vent Screen»(ref-568406-S32289223332013072200000) information.
