SPECIFICATIONS
| Engine Description | Engine Capacity | Maximum Engine Torque (EEC) (SAE) | Maximum Engine Power (EEC) (SAE) | Compression Ratio | Bore | Stroke |
|---|---|---|---|---|---|---|
| 90° "Vee" 8 Cylinder 32 Valves | 4.999 ccm | 515 Nm at 3.500 RPM | 283 kW at 6.500 RPM | 11.5 ± 0.5 | 92.509 ± 0.009 mm | 93 ± 0.1 mm |
ENGINE DATA
| Firing Order |
|---|
| 1:2:7:3:4:5:6:8 |
ENGINE FIRING ORDER
| Intake Valve | Exhaust Valve |
|---|---|
| N/A | 0.25 mm ± 0.02 |
ENGINE VALVE CLEARANCE (COLD)
| Specification | Spark Plug Gap |
|---|---|
| ILKR6C-10 | 1 mm |
SPARK PLUGS
| Description | Specification |
|---|---|
| Engine Oil | WSS-M2C925-A |
| Sealant | WSE-M4G323-A6 |
| Core plug and stub pipe retainer | WSK-M2G349-A7 |
| Jaguar Premium Cooling System Fluid | WSS-M97B44-D |
LUBRICANTS, FLUIDS, SEALERS AND ADHESIVES
| Description | Liters |
|---|---|
| Engine oil, initial fill | 8.75 |
| Engine oil, service fill with oil filter change | 7.25 |
CAPACITIES
| Item | Specification |
|---|---|
| Cylinder head maximum permitted warp (mm) (flatness specification) | |
| Overall | 0.08 |
| Over 150x150 mm area | 0.05 |
| Over 25x25 mm area | 0.02 |
| Valve guide inner diameter (mm) | 5.51 ± 0.01 |
| Intake valve effective length (mm) (tip to gauge line) | 97.63 ± 0.1 |
| Exhaust valve effective length (mm) (tip to gauge line) | 94.39 ± 0.1 |
| Valve stem to guide clearance intake diametrical (mm) | 0.022 - 0.057 |
| Valve stem to guide clearance exhaust diametrical (mm) | 0.03 - 0.065 |
| Valve head diameter intake (mm) | 36 ± 0.1 |
| Valve head diameter exhaust (mm) | 30 ± 0.1 |
| Intake valve face angle (degrees) | 44.875 ± 0.125 |
| Exhaust valve face angle (degrees) | 44.875 ± 0.125 |
| Valve stem diameter intake (mm) | 5.4705 ± 0.0075 |
| Valve stem diameter exhaust (mm) | 5.4625 ± 0.0075 |
| Valve spring free length (mm) - inlet | 43.43 |
| Valve spring free length (mm) - exhaust | 46.1 |
| Valve spring installed height (mm) - inlet | 34.49 |
| Valve spring installed height (mm) - exhaust | 35.1 |
| Camshaft lobe lift intake (mm) | 5.5 (low) 10.53 (high) |
| Camshaft lobe lift exhaust (mm) | 9.36 |
| Camshaft journal to cylinder head bearing surface clearance diametrical (mm) | 0.025 - 0.065 |
| Camshaft journal diameter - all positions | 26.965 ± 0.01 |
| Bearing diameter - all positions | 27.01 ± 0.01 |
| Camshaft journal maximum run out limit (mm) | |
| Camshaft journals to end journals | 0.03 |
| Camshaft journals to adjacent journals | 0.015 |
| Camshaft journal maximum out of round (mm) - all journals | 0.005 |
CYLINDER HEAD AND VALVE TRAIN
Note. A = Refer to procedure for correct torque sequence.
| Description | Nm |
|---|---|
| Engine cover mounting bolts | 10 |
| Accessory drive belt tensioner retaining bolt | 40 |
| Accessory drive belt idler retaining bolt | 25 |
| Power steering pump pulley retaining bolts | 25 |
| Power steering pump retaining bolts | 25 |
| Power steering pump bracket to engine retaining bolts | 25 |
| Generator retaining bolts | 48 |
| Starter motor retaining bolts | 48 |
| Air conditioning compressor retaining bolts | 25 |
| Engine mounting to engine mounting bracket retaining nuts | 48 |
| Engine mounting to subframe retaining nuts | 63 |
| Engine mounting bracket to engine retaining bolts | 48 |
| Crankshaft damper pulley retaining LH threaded bolt | 200 + 270° |
| Flexplate retaining bolts | 45 + 90° |
| Exhaust manifold heat shield retaining bolts | A |
| Exhaust manifold retaining bolts | A |
| Engine wiring harness bracket retaining bolts | 10 |
| Intake manifold retaining bolts | 25 |
| Coolant outlet pipe | 10 |
| Oil Cooler retaining bolts | 13 |
| Knock sensor (KS) retaining bolt | 20 |
| Ignition coil retaining bolts | 8 |
| Spark plugs | 20 |
| Fuel rail retaining bolts | A |
| High Pressure fuel pipe retaining bolts | A |
| High pressure fuel pump retaining bolts | 12 |
| Oil filter housing assembly retaining bolts | 12 |
| Oil filter cap | 28 |
| Lifting eye bolts | 25 + 90° |
| CPS solenoid retaining bolts | 12 |
| Coolant pump retaining bolts | 12 |
| Variable valve timing (VVT) oil control solenoid retaining bolts | 10 |
| Camshaft position (CMP) sensor retaining bolts | 10 |
| Camshaft cover retaining bolts | 13 |
| Front upper timing cover retaining bolts | 12 |
| Front lower timing cover retaining bolts | A |
| Engine rear cover retaining bolts | A |
| VVT to camshaft retaining bolts | 32 |
| Camshaft bearing caps retaining bolts | 11 |
| Primary timing chain fixed guide retaining bolts | 12 |
| Primary timing chain tensioner retaining bolts | 12 |
| Primary timing chain tensioner guide blade retaining bolts | 25 |
| Auxiliary chain tensioner guide retaining bolts | 21 |
| Auxiliary chain fixed guide retaining bolt | 12 |
| Oil pump sprocket retaining bolt | 21 |
| Cylinder head retaining bolts | A |
| Engine oil level (EOL) sensor retaining bolt | 12 |
| Oil pan to oil sump body retaining bolts | 12 |
| Oil sump body to engine retaining bolts | 25 |
| Oil pan drain plug | 23 |
| Oil transfer tube to Oil pan body retaining bolts | 11 |
| Oil pump to engine block retaining bolts | 25 |
| Pick-up pipe to oil pump retaining bolts | 12 |
| Windage tray retaining bolts | 25 |
| Engine block coolant draining plug | 50 |
TORQUE SPECIFICATION
