FUEL PUMP CAMSHAFT TIMING ADJUSTMENT

Special Tool(s)

303-1447 Timing Tool JLR-303-1613 Alignment Tool, Fuel Pump Camshaft Timing

Scheme 378

Scheme 379

Scheme 380

Scheme 381

Scheme 382

Scheme 383

1. Refer to «BATTERY DISCONNECT AND CONNECT»(ref-568400-S03532047432013072200000).
2. Raise and support the vehicle.
3. Refer to: Fuel Pump Camshaft Timing Check (303-01D Engine - V8 S/C 5.0L Petrol, General Procedures).
4. Refer to «LOWER TIMING COVER»(ref-568451-S30803134972013072200000). Refer to «LOWER TIMING COVER»(ref-568453-S00244452942013072200000).
5. Special Tool(s): JLR-303-1613 Torque: 12 Nm
6. Refer to «LOWER TIMING COVER»(ref-568451-S30803134972013072200000). Refer to «LOWER TIMING COVER»(ref-568453-S00244452942013072200000).
7. Remove the Special Tool(s): 303-1447
8. Torque: 10 Nm
9. Torque: 24 Nm
10. Refer to «BATTERY DISCONNECT AND CONNECT»(ref-568400-S03532047432013072200000).
11. Fill the engine with oil - for filling values on vehicles without supercharger: Refer to «SPECIFICATIONS»(ref-568451-S01081780402013072200000). Fill the engine with oil - for filling values on vehicles with supercharger: Refer to «SPECIFICATIONS»(ref-568453-S16635455332013072200000). Clean any residual engine oil from the oil filler cap area.
12. Follow the Steps 15-19 before starting the engine.
13. Start the engine and allow to run for 10 minutes, stop the engine. Check for leaks.
14. Turn the ignition on.
15. Scroll through the trip menu to access the engine oil level display.
16. Press the cruise control cancel button twice within 2 seconds.
17. The message center display will revert to the normal display in the trip computer. Scroll through the trip menu to access the engine oil level display. Check that the oil level display shows an oil level reading. Only after having started and run the engine for 10 minutes (as indicated in Step 14), switch off the engine, then stabilizing for 10 minutes, take a reading from the oil level display and, if necessary top up with engine oil.
18. Turn the ignition off.
19. Allow 10 minutes for the engine oil level to stabilize if there has been additional oil top up.
20. Turn the ignition on. Press and hold the cruise control cancel button for more than 2 seconds.
21. The message center display will revert to the normal display in the trip computer.
22. Turn the ignition off.
23. Turn the ignition on.
24. Scroll through the trip menu to access the engine oil level display. Make sure that the average oil level value has now been updated.
25. Refer to «AIR DEFLECTOR»(ref-568406-S42840487662013072200000).

Scheme 384

1. Refer to «BATTERY DISCONNECT AND CONNECT»(ref-568400-S03532047432013072200000) .
2. Raise and support the vehicle.
3. Refer to «VALVE COVER LH»(ref-568451-S20865882922013072200000) .
4. Refer to «Valve Cover RH»(ref-568451-S10149281132013072200000) .
5. Using feeler gauge check the gap between the tappet and the camshaft lobe and check against specifications table. Repeat for the remaining valve tappets.
