SPECIFICATIONS
General Specifications
| Item | Specification |
|---|---|
| Fuel tank gross capacity - all vehicles | 77 liters |
| Fuel tank capacity - vehicles with 3.0L, 4.2L, 2.7L Diesel | 69.5 (total) / 64 (usable) liters |
| Fuel tank capacity - vehicles with 3.0L Diesel | 71.1 (total) / 68.1 (usable) liters |
| Fuel tank capacity - vehicles with 5.0L | 71.1 (total) / 69.5 (useable) liters |
| Fuel tank capacity - when fuel gauge indicates empty - vehicles with 3.0L Diesel | 64 liters |
| Reserve capacity - when fuel gauge indicates empty - vehicles with 3.0L, 4.2L, 2.7L Diesel | 5.5 liters |
| Reserve capacity - when fuel gauge indicates empty - vehicles with 5.0L, 3.0L Diesel | 7 liters |
Scheme 26
Scheme 27
- Disconnect the battery ground cable. Refer to «Battery Disconnect»(ref-568400) information.
- Remove the engine cover.
- Disconnect the electrical connector.
- Disconnect the fuel rail feed pipe. Refer to: «Spring Lock Couplings»(ref-568404-S14100932032013072200000) .
- Install the special tool.
- Install the special tool.
- Install the special tool.
- Install the fuel pressure gauge.
- Connect the battery ground cable. Refer to «Battery Connect»(ref-568400) information.
- Carry out the fuel system pressure check. Refer to: «Fuel Charging And Controls - (4.2L)»(ref-568402-S39826780602013072200000) information. Refer to: «Fuel Charging And Controls (S/C 4.2L)»(ref-568401-S09078350382013072200000) information. Refer to: «Fuel Charging And Controls (5.0L)»(ref-568459-S12706201492013072200000) information. Refer to: «Fuel Charging And Controls (S/C 5.0L)»(ref-568461-S41758039732013072200000) information.
