DRAINING

1. Remove the fuel pump fuse.
2. Remove the fuel filler cap.
3. Start the engine and allow it to idle until the engine stalls.
4. Crank the engine for approximately five seconds to make sure that the fuel rail pressure is released.

FUEL TANK DRAINING

Special Tools

Tool Illustration Tool Name Tool Number Fuel tank drain adaptor 310-154

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

1. Refer to «Diesel Fuel System Health and Safety Precautions»(ref-568389-S04180877442013072200000) information.
2. Refer to «Petrol and Petrol-Ethanol Fuel Systems Health and Safety Precautions»(ref-568389-S18838167962013072200000) information.
3. Release the pressure in the fuel system. Refer to: «Fuel System Pressure Release - 3.0L/4.2L»(ref-568404-S21260192772013072200000) .
4. Release the pressure in the fuel system. Refer to: «Fuel System Pressure Release - 5.0L»(ref-568404-S07557823782013072200000) . .
5. Remove the rear seat cushion. Refer to «Rear Seat Cushion»(ref-568428-S13803481932013072200000) information.
6. Detach and reposition the door opening weatherstrip.
7. Remove the scuff plate trim panel.
8. Detach and reposition the floor covering.
9. Detach and reposition the rear seat cushion insulation.
10. Remove the floor aperture cover.
11. Using a suitable tool, remove the top of the fuel tank drain port.
12. Using the special tool, drain the right-hand side of the fuel tank.
13. Remove the special tool.
14. Install a new fuel tank drain port sealing cap.
15. Using a suitable tool, remove the top of the fuel tank drain port.
16. Using the special tool, drain the left-hand side of the fuel tank.
17. Remove the special tool.
18. Install a new fuel tank drain port sealing cap.
19. Install the floor aperture cover.
20. Attach the rear seat cushion insulation.
21. Attach the floor covering.
22. Install the scuff plate trim panel.
23. Attach the door opening weatherstrip.
24. Install the rear seat cushion. Refer to «Rear Seat Cushion»(ref-568428-S13803481932013072200000) information.
